Acpi10.h File Reference
#include <IndustryStandard/AcpiAml.h>
Include dependency graph for Acpi10.h:
This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes

struct  EFI_ACPI_COMMON_HEADER

struct  EFI_ACPI_DESCRIPTION_HEADER

struct  EFI_ACPI_END_TAG_DESCRIPTOR

struct  EFI_ACPI_1_0_ROOT_SYSTEM_DESCRIPTION_POINTER

struct  EFI_ACPI_1_0_FIXED_ACPI_DESCRIPTION_TABLE

struct  EFI_ACPI_1_0_FIRMWARE_ACPI_CONTROL_STRUCTURE

struct  EFI_ACPI_1_0_MULTIPLE_APIC_DESCRIPTION_TABLE_HEADER

struct  EFI_ACPI_1_0_PROCESSOR_LOCAL_APIC_STRUCTURE

struct  EFI_ACPI_1_0_IO_APIC_STRUCTURE

struct  EFI_ACPI_1_0_INTERRUPT_SOURCE_OVERRIDE_STRUCTURE

struct  EFI_ACPI_1_0_NON_MASKABLE_INTERRUPT_SOURCE_STRUCTURE

struct  EFI_ACPI_1_0_LOCAL_APIC_NMI_STRUCTURE

struct  EFI_ACPI_1_0_SMART_BATTERY_DESCRIPTION_TABLE


Macros

#define ACPI_SMALL_ITEM_FLAG   0x00

#define ACPI_LARGE_ITEM_FLAG   0x01

#define ACPI_SMALL_IRQ_DESCRIPTOR_NAME   0x04

#define ACPI_SMALL_DMA_DESCRIPTOR_NAME   0x05

#define ACPI_SMALL_START_DEPENDENT_DESCRIPTOR_NAME   0x06

#define ACPI_SMALL_END_DEPENDENT_DESCRIPTOR_NAME   0x07

#define ACPI_SMALL_IO_PORT_DESCRIPTOR_NAME   0x08

#define ACPI_SMALL_FIXED_IO_PORT_DESCRIPTOR_NAME   0x09

#define ACPI_SMALL_VENDOR_DEFINED_DESCRIPTOR_NAME   0x0E

#define ACPI_SMALL_END_TAG_DESCRIPTOR_NAME   0x0F

#define ACPI_LARGE_24_BIT_MEMORY_RANGE_DESCRIPTOR_NAME   0x01

#define ACPI_LARGE_VENDOR_DEFINED_DESCRIPTOR_NAME   0x04

#define ACPI_LARGE_32_BIT_MEMORY_RANGE_DESCRIPTOR_NAME   0x05

#define ACPI_LARGE_32_BIT_FIXED_MEMORY_RANGE_DESCRIPTOR_NAME   0x06

#define ACPI_LARGE_DWORD_ADDRESS_SPACE_DESCRIPTOR_NAME   0x07

#define ACPI_LARGE_WORD_ADDRESS_SPACE_DESCRIPTOR_NAME   0x08

#define ACPI_LARGE_EXTENDED_IRQ_DESCRIPTOR_NAME   0x09

#define ACPI_LARGE_QWORD_ADDRESS_SPACE_DESCRIPTOR_NAME   0x0A

#define ACPI_IRQ_NOFLAG_DESCRIPTOR   0x22

#define ACPI_IRQ_DESCRIPTOR   0x23

#define ACPI_DMA_DESCRIPTOR   0x2A

#define ACPI_START_DEPENDENT_DESCRIPTOR   0x30

#define ACPI_START_DEPENDENT_EX_DESCRIPTOR   0x31

#define ACPI_END_DEPENDENT_DESCRIPTOR   0x38

#define ACPI_IO_PORT_DESCRIPTOR   0x47

#define ACPI_FIXED_LOCATION_IO_PORT_DESCRIPTOR   0x4B

#define ACPI_END_TAG_DESCRIPTOR   0x79

#define ACPI_24_BIT_MEMORY_RANGE_DESCRIPTOR   0x81

#define ACPI_32_BIT_MEMORY_RANGE_DESCRIPTOR   0x85

#define ACPI_32_BIT_FIXED_MEMORY_RANGE_DESCRIPTOR   0x86

#define ACPI_DWORD_ADDRESS_SPACE_DESCRIPTOR   0x87

#define ACPI_WORD_ADDRESS_SPACE_DESCRIPTOR   0x88

#define ACPI_EXTENDED_INTERRUPT_DESCRIPTOR   0x89

#define ACPI_QWORD_ADDRESS_SPACE_DESCRIPTOR   0x8A

#define ACPI_ADDRESS_SPACE_DESCRIPTOR   0x8A

#define ACPI_ADDRESS_SPACE_TYPE_MEM   0x00

#define ACPI_ADDRESS_SPACE_TYPE_IO   0x01

#define ACPI_ADDRESS_SPACE_TYPE_BUS   0x02

#define ACPI_TIMER_FREQUENCY   3579545

#define EFI_ACPI_RESERVED_BYTE   0x00

#define EFI_ACPI_RESERVED_WORD   0x0000

#define EFI_ACPI_RESERVED_DWORD   0x00000000

#define EFI_ACPI_RESERVED_QWORD   0x0000000000000000

#define EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_READ_WRITE   (1 << 0)

#define EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_READ_ONLY   (0 << 0)

#define EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_NON_CACHEABLE   (0 << 1)

#define EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_CACHEABLE   (1 << 1)

#define EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_CACHEABLE_WRITE_COMBINING   (2 << 1)

#define EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_CACHEABLE_PREFETCHABLE   (3 << 1)

#define EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_ADDRESS_RANGE_MEMORY   (0 << 3)

#define EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_ADDRESS_RANGE_RESERVED   (1 << 3)

#define EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_ADDRESS_RANGE_ACPI   (2 << 3)

#define EFI_APCI_MEMORY_RESOURCE_SPECIFIC_FLAG_ADDRESS_RANGE_NVS   (3 << 3)

#define EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_TYPE_TRANSLATION   (1 << 5)

#define EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_TYPE_STATIC   (0 << 5)

#define EFI_ACPI_IRQ_SHARABLE_MASK   0x10

#define EFI_ACPI_IRQ_SHARABLE   0x10

#define EFI_ACPI_IRQ_POLARITY_MASK   0x08

#define EFI_ACPI_IRQ_HIGH_TRUE   0x00

#define EFI_ACPI_IRQ_LOW_FALSE   0x08

#define EFI_ACPI_IRQ_MODE   0x01

#define EFI_ACPI_IRQ_LEVEL_TRIGGERED   0x00

#define EFI_ACPI_IRQ_EDGE_TRIGGERED   0x01

#define EFI_ACPI_DMA_SPEED_TYPE_MASK   0x60

#define EFI_ACPI_DMA_SPEED_TYPE_COMPATIBILITY   0x00

#define EFI_ACPI_DMA_SPEED_TYPE_A   0x20

#define EFI_ACPI_DMA_SPEED_TYPE_B   0x40

#define EFI_ACPI_DMA_SPEED_TYPE_F   0x60

#define EFI_ACPI_DMA_BUS_MASTER_MASK   0x04

#define EFI_ACPI_DMA_BUS_MASTER   0x04

#define EFI_ACPI_DMA_TRANSFER_TYPE_MASK   0x03

#define EFI_ACPI_DMA_TRANSFER_TYPE_8_BIT   0x00

#define EFI_ACPI_DMA_TRANSFER_TYPE_8_BIT_AND_16_BIT   0x01

#define EFI_ACPI_DMA_TRANSFER_TYPE_16_BIT   0x10

#define EFI_ACPI_IO_DECODE_MASK   0x01

#define EFI_ACPI_IO_DECODE_16_BIT   0x01

#define EFI_ACPI_IO_DECODE_10_BIT   0x00

#define EFI_ACPI_MEMORY_WRITE_STATUS_MASK   0x01

#define EFI_ACPI_MEMORY_WRITABLE   0x01

#define EFI_ACPI_MEMORY_NON_WRITABLE   0x00

#define EFI_ACPI_1_0_ROOT_SYSTEM_DESCRIPTION_TABLE_REVISION   0x01

#define EFI_ACPI_1_0_FIXED_ACPI_DESCRIPTION_TABLE_REVISION   0x01

#define EFI_ACPI_1_0_INT_MODE_DUAL_PIC   0

#define EFI_ACPI_1_0_INT_MODE_MULTIPLE_APIC   1

#define EFI_ACPI_1_0_WBINVD   BIT0

#define EFI_ACPI_1_0_WBINVD_FLUSH   BIT1

#define EFI_ACPI_1_0_PROC_C1   BIT2

#define EFI_ACPI_1_0_P_LVL2_UP   BIT3

#define EFI_ACPI_1_0_PWR_BUTTON   BIT4

#define EFI_ACPI_1_0_SLP_BUTTON   BIT5

#define EFI_ACPI_1_0_FIX_RTC   BIT6

#define EFI_ACPI_1_0_RTC_S4   BIT7

#define EFI_ACPI_1_0_TMR_VAL_EXT   BIT8

#define EFI_ACPI_1_0_DCK_CAP   BIT9

#define EFI_ACPI_1_0_S4BIOS_F   BIT0

#define EFI_ACPI_1_0_MULTIPLE_APIC_DESCRIPTION_TABLE_REVISION   0x01

#define EFI_ACPI_1_0_PCAT_COMPAT   BIT0

#define EFI_ACPI_1_0_PROCESSOR_LOCAL_APIC   0x00

#define EFI_ACPI_1_0_IO_APIC   0x01

#define EFI_ACPI_1_0_INTERRUPT_SOURCE_OVERRIDE   0x02

#define EFI_ACPI_1_0_NON_MASKABLE_INTERRUPT_SOURCE   0x03

#define EFI_ACPI_1_0_LOCAL_APIC_NMI   0x04

#define EFI_ACPI_1_0_LOCAL_APIC_ENABLED   BIT0

#define EFI_ACPI_1_0_ROOT_SYSTEM_DESCRIPTION_POINTER_SIGNATURE   SIGNATURE_64('R', 'S', 'D', ' ', 'P', 'T', 'R', ' ')

#define EFI_ACPI_1_0_APIC_SIGNATURE   SIGNATURE_32('A', 'P', 'I', 'C')

#define EFI_ACPI_1_0_DIFFERENTIATED_SYSTEM_DESCRIPTION_TABLE_SIGNATURE   SIGNATURE_32('D', 'S', 'D', 'T')

#define EFI_ACPI_1_0_FIRMWARE_ACPI_CONTROL_STRUCTURE_SIGNATURE   SIGNATURE_32('F', 'A', 'C', 'S')

#define EFI_ACPI_1_0_FIXED_ACPI_DESCRIPTION_TABLE_SIGNATURE   SIGNATURE_32('F', 'A', 'C', 'P')

#define EFI_ACPI_1_0_PERSISTENT_SYSTEM_DESCRIPTION_TABLE_SIGNATURE   SIGNATURE_32('P', 'S', 'D', 'T')

#define EFI_ACPI_1_0_ROOT_SYSTEM_DESCRIPTION_TABLE_SIGNATURE   SIGNATURE_32('R', 'S', 'D', 'T')

#define EFI_ACPI_1_0_SMART_BATTERY_SPECIFICATION_TABLE_SIGNATURE   SIGNATURE_32('S', 'B', 'S', 'T')

#define EFI_ACPI_1_0_SECONDARY_SYSTEM_DESCRIPTION_TABLE_SIGNATURE   SIGNATURE_32('S', 'S', 'D', 'T')


Typedefs

struct {

   UINT8   Desc

   UINT16   Len

   UINT8   ResType

   UINT8   GenFlag

   UINT8   SpecificFlag

   UINT64   AddrSpaceGranularity

   UINT64   AddrRangeMin

   UINT64   AddrRangeMax

   UINT64   AddrTranslationOffset

   UINT64   AddrLen

} EFI_ACPI_ADDRESS_SPACE_DESCRIPTOR

union {

   UINT8   Byte

   struct {

      UINT8   Length: 3

      UINT8   Name: 4

      UINT8   Type: 1

   }   Bits

} ACPI_SMALL_RESOURCE_HEADER

struct {

   union {

      UINT8   Byte

      struct {

         UINT8   Name: 7

         UINT8   Type: 1

      }   Bits

   }   Header

   UINT16   Length

} ACPI_LARGE_RESOURCE_HEADER

struct {

   ACPI_SMALL_RESOURCE_HEADER   Header

   UINT16   Mask

} EFI_ACPI_IRQ_NOFLAG_DESCRIPTOR

struct {

   ACPI_SMALL_RESOURCE_HEADER   Header

   UINT16   Mask

   UINT8   Information

} EFI_ACPI_IRQ_DESCRIPTOR

struct {

   ACPI_SMALL_RESOURCE_HEADER   Header

   UINT8   ChannelMask

   UINT8   Information

} EFI_ACPI_DMA_DESCRIPTOR

struct {

   ACPI_SMALL_RESOURCE_HEADER   Header

   UINT8   Information

   UINT16   BaseAddressMin

   UINT16   BaseAddressMax

   UINT8   Alignment

   UINT8   Length

} EFI_ACPI_IO_PORT_DESCRIPTOR

struct {

   ACPI_SMALL_RESOURCE_HEADER   Header

   UINT16   BaseAddress

   UINT8   Length

} EFI_ACPI_FIXED_LOCATION_IO_PORT_DESCRIPTOR

struct {

   ACPI_LARGE_RESOURCE_HEADER   Header

   UINT8   Information

   UINT16   BaseAddressMin

   UINT16   BaseAddressMax

   UINT16   Alignment

   UINT16   Length

} EFI_ACPI_24_BIT_MEMORY_RANGE_DESCRIPTOR

struct {

   ACPI_LARGE_RESOURCE_HEADER   Header

   UINT8   Information

   UINT32   BaseAddressMin

   UINT32   BaseAddressMax

   UINT32   Alignment

   UINT32   Length

} EFI_ACPI_32_BIT_MEMORY_RANGE_DESCRIPTOR

struct {

   ACPI_LARGE_RESOURCE_HEADER   Header

   UINT8   Information

   UINT32   BaseAddress

   UINT32   Length

} EFI_ACPI_32_BIT_FIXED_MEMORY_RANGE_DESCRIPTOR

struct {

   ACPI_LARGE_RESOURCE_HEADER   Header

   UINT8   ResType

   UINT8   GenFlag

   UINT8   SpecificFlag

   UINT64   AddrSpaceGranularity

   UINT64   AddrRangeMin

   UINT64   AddrRangeMax

   UINT64   AddrTranslationOffset

   UINT64   AddrLen

} EFI_ACPI_QWORD_ADDRESS_SPACE_DESCRIPTOR

struct {

   ACPI_LARGE_RESOURCE_HEADER   Header

   UINT8   ResType

   UINT8   GenFlag

   UINT8   SpecificFlag

   UINT32   AddrSpaceGranularity

   UINT32   AddrRangeMin

   UINT32   AddrRangeMax

   UINT32   AddrTranslationOffset

   UINT32   AddrLen

} EFI_ACPI_DWORD_ADDRESS_SPACE_DESCRIPTOR

struct {

   ACPI_LARGE_RESOURCE_HEADER   Header

   UINT8   ResType

   UINT8   GenFlag

   UINT8   SpecificFlag

   UINT16   AddrSpaceGranularity

   UINT16   AddrRangeMin

   UINT16   AddrRangeMax

   UINT16   AddrTranslationOffset

   UINT16   AddrLen

} EFI_ACPI_WORD_ADDRESS_SPACE_DESCRIPTOR

struct {

   ACPI_LARGE_RESOURCE_HEADER   Header

   UINT8   InterruptVectorFlags

   UINT8   InterruptTableLength

   UINT32   InterruptNumber [1]

} EFI_ACPI_EXTENDED_INTERRUPT_DESCRIPTOR


Detailed Description

ACPI 1.0b definitions from the ACPI Specification, revision 1.0b

Copyright (c) 2006 - 2018, Intel Corporation. All rights reserved.
This program and the accompanying materials are licensed and made available under the terms and conditions of the BSD License that accompanies this distribution. The full text of the license may be found at http://opensource.org/licenses/bsd-license.php.

THE PROGRAM IS DISTRIBUTED UNDER THE BSD LICENSE ON AN "AS IS" BASIS, WITHOUT WARRANTIES OR REPRESENTATIONS OF ANY KIND, EITHER EXPRESS OR IMPLIED.

Macro Definition Documentation

◆ ACPI_24_BIT_MEMORY_RANGE_DESCRIPTOR

#define ACPI_24_BIT_MEMORY_RANGE_DESCRIPTOR   0x81

◆ ACPI_32_BIT_FIXED_MEMORY_RANGE_DESCRIPTOR

#define ACPI_32_BIT_FIXED_MEMORY_RANGE_DESCRIPTOR   0x86

◆ ACPI_32_BIT_MEMORY_RANGE_DESCRIPTOR

#define ACPI_32_BIT_MEMORY_RANGE_DESCRIPTOR   0x85

◆ ACPI_ADDRESS_SPACE_DESCRIPTOR

#define ACPI_ADDRESS_SPACE_DESCRIPTOR   0x8A

◆ ACPI_ADDRESS_SPACE_TYPE_BUS

#define ACPI_ADDRESS_SPACE_TYPE_BUS   0x02

◆ ACPI_ADDRESS_SPACE_TYPE_IO

#define ACPI_ADDRESS_SPACE_TYPE_IO   0x01

◆ ACPI_ADDRESS_SPACE_TYPE_MEM

#define ACPI_ADDRESS_SPACE_TYPE_MEM   0x00

◆ ACPI_DMA_DESCRIPTOR

#define ACPI_DMA_DESCRIPTOR   0x2A

◆ ACPI_DWORD_ADDRESS_SPACE_DESCRIPTOR

#define ACPI_DWORD_ADDRESS_SPACE_DESCRIPTOR   0x87

◆ ACPI_END_DEPENDENT_DESCRIPTOR

#define ACPI_END_DEPENDENT_DESCRIPTOR   0x38

◆ ACPI_END_TAG_DESCRIPTOR

#define ACPI_END_TAG_DESCRIPTOR   0x79

◆ ACPI_EXTENDED_INTERRUPT_DESCRIPTOR

#define ACPI_EXTENDED_INTERRUPT_DESCRIPTOR   0x89

◆ ACPI_FIXED_LOCATION_IO_PORT_DESCRIPTOR

#define ACPI_FIXED_LOCATION_IO_PORT_DESCRIPTOR   0x4B

◆ ACPI_IO_PORT_DESCRIPTOR

#define ACPI_IO_PORT_DESCRIPTOR   0x47

◆ ACPI_IRQ_DESCRIPTOR

#define ACPI_IRQ_DESCRIPTOR   0x23

◆ ACPI_IRQ_NOFLAG_DESCRIPTOR

#define ACPI_IRQ_NOFLAG_DESCRIPTOR   0x22

◆ ACPI_LARGE_24_BIT_MEMORY_RANGE_DESCRIPTOR_NAME

#define ACPI_LARGE_24_BIT_MEMORY_RANGE_DESCRIPTOR_NAME   0x01

◆ ACPI_LARGE_32_BIT_FIXED_MEMORY_RANGE_DESCRIPTOR_NAME

#define ACPI_LARGE_32_BIT_FIXED_MEMORY_RANGE_DESCRIPTOR_NAME   0x06

◆ ACPI_LARGE_32_BIT_MEMORY_RANGE_DESCRIPTOR_NAME

#define ACPI_LARGE_32_BIT_MEMORY_RANGE_DESCRIPTOR_NAME   0x05

◆ ACPI_LARGE_DWORD_ADDRESS_SPACE_DESCRIPTOR_NAME

#define ACPI_LARGE_DWORD_ADDRESS_SPACE_DESCRIPTOR_NAME   0x07

◆ ACPI_LARGE_EXTENDED_IRQ_DESCRIPTOR_NAME

#define ACPI_LARGE_EXTENDED_IRQ_DESCRIPTOR_NAME   0x09

◆ ACPI_LARGE_ITEM_FLAG

#define ACPI_LARGE_ITEM_FLAG   0x01

◆ ACPI_LARGE_QWORD_ADDRESS_SPACE_DESCRIPTOR_NAME

#define ACPI_LARGE_QWORD_ADDRESS_SPACE_DESCRIPTOR_NAME   0x0A

◆ ACPI_LARGE_VENDOR_DEFINED_DESCRIPTOR_NAME

#define ACPI_LARGE_VENDOR_DEFINED_DESCRIPTOR_NAME   0x04

◆ ACPI_LARGE_WORD_ADDRESS_SPACE_DESCRIPTOR_NAME

#define ACPI_LARGE_WORD_ADDRESS_SPACE_DESCRIPTOR_NAME   0x08

◆ ACPI_QWORD_ADDRESS_SPACE_DESCRIPTOR

#define ACPI_QWORD_ADDRESS_SPACE_DESCRIPTOR   0x8A

◆ ACPI_SMALL_DMA_DESCRIPTOR_NAME

#define ACPI_SMALL_DMA_DESCRIPTOR_NAME   0x05

◆ ACPI_SMALL_END_DEPENDENT_DESCRIPTOR_NAME

#define ACPI_SMALL_END_DEPENDENT_DESCRIPTOR_NAME   0x07

◆ ACPI_SMALL_END_TAG_DESCRIPTOR_NAME

#define ACPI_SMALL_END_TAG_DESCRIPTOR_NAME   0x0F

◆ ACPI_SMALL_FIXED_IO_PORT_DESCRIPTOR_NAME

#define ACPI_SMALL_FIXED_IO_PORT_DESCRIPTOR_NAME   0x09

◆ ACPI_SMALL_IO_PORT_DESCRIPTOR_NAME

#define ACPI_SMALL_IO_PORT_DESCRIPTOR_NAME   0x08

◆ ACPI_SMALL_IRQ_DESCRIPTOR_NAME

#define ACPI_SMALL_IRQ_DESCRIPTOR_NAME   0x04

◆ ACPI_SMALL_ITEM_FLAG

#define ACPI_SMALL_ITEM_FLAG   0x00

◆ ACPI_SMALL_START_DEPENDENT_DESCRIPTOR_NAME

#define ACPI_SMALL_START_DEPENDENT_DESCRIPTOR_NAME   0x06

◆ ACPI_SMALL_VENDOR_DEFINED_DESCRIPTOR_NAME

#define ACPI_SMALL_VENDOR_DEFINED_DESCRIPTOR_NAME   0x0E

◆ ACPI_START_DEPENDENT_DESCRIPTOR

#define ACPI_START_DEPENDENT_DESCRIPTOR   0x30

◆ ACPI_START_DEPENDENT_EX_DESCRIPTOR

#define ACPI_START_DEPENDENT_EX_DESCRIPTOR   0x31

◆ ACPI_TIMER_FREQUENCY

#define ACPI_TIMER_FREQUENCY   3579545

Power Management Timer frequency is fixed at 3.579545MHz.

◆ ACPI_WORD_ADDRESS_SPACE_DESCRIPTOR

#define ACPI_WORD_ADDRESS_SPACE_DESCRIPTOR   0x88

◆ EFI_ACPI_1_0_APIC_SIGNATURE

#define EFI_ACPI_1_0_APIC_SIGNATURE   SIGNATURE_32('A', 'P', 'I', 'C')

"APIC" Multiple APIC Description Table.

◆ EFI_ACPI_1_0_DCK_CAP

#define EFI_ACPI_1_0_DCK_CAP   BIT9

◆ EFI_ACPI_1_0_DIFFERENTIATED_SYSTEM_DESCRIPTION_TABLE_SIGNATURE

#define EFI_ACPI_1_0_DIFFERENTIATED_SYSTEM_DESCRIPTION_TABLE_SIGNATURE   SIGNATURE_32('D', 'S', 'D', 'T')

"DSDT" Differentiated System Description Table.

◆ EFI_ACPI_1_0_FIRMWARE_ACPI_CONTROL_STRUCTURE_SIGNATURE

#define EFI_ACPI_1_0_FIRMWARE_ACPI_CONTROL_STRUCTURE_SIGNATURE   SIGNATURE_32('F', 'A', 'C', 'S')

"FACS" Firmware ACPI Control Structure.

◆ EFI_ACPI_1_0_FIX_RTC

#define EFI_ACPI_1_0_FIX_RTC   BIT6

◆ EFI_ACPI_1_0_FIXED_ACPI_DESCRIPTION_TABLE_REVISION

#define EFI_ACPI_1_0_FIXED_ACPI_DESCRIPTION_TABLE_REVISION   0x01

FADT Version (as defined in ACPI 1.0b specification).

◆ EFI_ACPI_1_0_FIXED_ACPI_DESCRIPTION_TABLE_SIGNATURE

#define EFI_ACPI_1_0_FIXED_ACPI_DESCRIPTION_TABLE_SIGNATURE   SIGNATURE_32('F', 'A', 'C', 'P')

"FACP" Fixed ACPI Description Table.

◆ EFI_ACPI_1_0_INT_MODE_DUAL_PIC

#define EFI_ACPI_1_0_INT_MODE_DUAL_PIC   0

◆ EFI_ACPI_1_0_INT_MODE_MULTIPLE_APIC

#define EFI_ACPI_1_0_INT_MODE_MULTIPLE_APIC   1

◆ EFI_ACPI_1_0_INTERRUPT_SOURCE_OVERRIDE

#define EFI_ACPI_1_0_INTERRUPT_SOURCE_OVERRIDE   0x02

◆ EFI_ACPI_1_0_IO_APIC

#define EFI_ACPI_1_0_IO_APIC   0x01

◆ EFI_ACPI_1_0_LOCAL_APIC_ENABLED

#define EFI_ACPI_1_0_LOCAL_APIC_ENABLED   BIT0

Local APIC Flags. All other bits are reserved and must be 0.

◆ EFI_ACPI_1_0_LOCAL_APIC_NMI

#define EFI_ACPI_1_0_LOCAL_APIC_NMI   0x04

◆ EFI_ACPI_1_0_MULTIPLE_APIC_DESCRIPTION_TABLE_REVISION

#define EFI_ACPI_1_0_MULTIPLE_APIC_DESCRIPTION_TABLE_REVISION   0x01

MADT Revision (as defined in ACPI 1.0b specification).

◆ EFI_ACPI_1_0_NON_MASKABLE_INTERRUPT_SOURCE

#define EFI_ACPI_1_0_NON_MASKABLE_INTERRUPT_SOURCE   0x03

◆ EFI_ACPI_1_0_P_LVL2_UP

#define EFI_ACPI_1_0_P_LVL2_UP   BIT3

◆ EFI_ACPI_1_0_PCAT_COMPAT

#define EFI_ACPI_1_0_PCAT_COMPAT   BIT0

Multiple APIC Flags All other bits are reserved and must be set to 0.

◆ EFI_ACPI_1_0_PERSISTENT_SYSTEM_DESCRIPTION_TABLE_SIGNATURE

#define EFI_ACPI_1_0_PERSISTENT_SYSTEM_DESCRIPTION_TABLE_SIGNATURE   SIGNATURE_32('P', 'S', 'D', 'T')

"PSDT" Persistent System Description Table.

◆ EFI_ACPI_1_0_PROC_C1

#define EFI_ACPI_1_0_PROC_C1   BIT2

◆ EFI_ACPI_1_0_PROCESSOR_LOCAL_APIC

#define EFI_ACPI_1_0_PROCESSOR_LOCAL_APIC   0x00

◆ EFI_ACPI_1_0_PWR_BUTTON

#define EFI_ACPI_1_0_PWR_BUTTON   BIT4

◆ EFI_ACPI_1_0_ROOT_SYSTEM_DESCRIPTION_POINTER_SIGNATURE

#define EFI_ACPI_1_0_ROOT_SYSTEM_DESCRIPTION_POINTER_SIGNATURE   SIGNATURE_64('R', 'S', 'D', ' ', 'P', 'T', 'R', ' ')

"RSD PTR " Root System Description Pointer.

◆ EFI_ACPI_1_0_ROOT_SYSTEM_DESCRIPTION_TABLE_REVISION

#define EFI_ACPI_1_0_ROOT_SYSTEM_DESCRIPTION_TABLE_REVISION   0x01

RSDT Revision (as defined in ACPI 1.0b specification).

◆ EFI_ACPI_1_0_ROOT_SYSTEM_DESCRIPTION_TABLE_SIGNATURE

#define EFI_ACPI_1_0_ROOT_SYSTEM_DESCRIPTION_TABLE_SIGNATURE   SIGNATURE_32('R', 'S', 'D', 'T')

"RSDT" Root System Description Table.

◆ EFI_ACPI_1_0_RTC_S4

#define EFI_ACPI_1_0_RTC_S4   BIT7

◆ EFI_ACPI_1_0_S4BIOS_F

#define EFI_ACPI_1_0_S4BIOS_F   BIT0

Firmware Control Structure Feature Flags. All other bits are reserved and must be set to 0.

◆ EFI_ACPI_1_0_SECONDARY_SYSTEM_DESCRIPTION_TABLE_SIGNATURE

#define EFI_ACPI_1_0_SECONDARY_SYSTEM_DESCRIPTION_TABLE_SIGNATURE   SIGNATURE_32('S', 'S', 'D', 'T')

"SSDT" Secondary System Description Table.

◆ EFI_ACPI_1_0_SLP_BUTTON

#define EFI_ACPI_1_0_SLP_BUTTON   BIT5

◆ EFI_ACPI_1_0_SMART_BATTERY_SPECIFICATION_TABLE_SIGNATURE

#define EFI_ACPI_1_0_SMART_BATTERY_SPECIFICATION_TABLE_SIGNATURE   SIGNATURE_32('S', 'B', 'S', 'T')

"SBST" Smart Battery Specification Table.

◆ EFI_ACPI_1_0_TMR_VAL_EXT

#define EFI_ACPI_1_0_TMR_VAL_EXT   BIT8

◆ EFI_ACPI_1_0_WBINVD

#define EFI_ACPI_1_0_WBINVD   BIT0

◆ EFI_ACPI_1_0_WBINVD_FLUSH

#define EFI_ACPI_1_0_WBINVD_FLUSH   BIT1

◆ EFI_ACPI_DMA_BUS_MASTER

#define EFI_ACPI_DMA_BUS_MASTER   0x04

◆ EFI_ACPI_DMA_BUS_MASTER_MASK

#define EFI_ACPI_DMA_BUS_MASTER_MASK   0x04

◆ EFI_ACPI_DMA_SPEED_TYPE_A

#define EFI_ACPI_DMA_SPEED_TYPE_A   0x20

◆ EFI_ACPI_DMA_SPEED_TYPE_B

#define EFI_ACPI_DMA_SPEED_TYPE_B   0x40

◆ EFI_ACPI_DMA_SPEED_TYPE_COMPATIBILITY

#define EFI_ACPI_DMA_SPEED_TYPE_COMPATIBILITY   0x00

◆ EFI_ACPI_DMA_SPEED_TYPE_F

#define EFI_ACPI_DMA_SPEED_TYPE_F   0x60

◆ EFI_ACPI_DMA_SPEED_TYPE_MASK

#define EFI_ACPI_DMA_SPEED_TYPE_MASK   0x60

◆ EFI_ACPI_DMA_TRANSFER_TYPE_16_BIT

#define EFI_ACPI_DMA_TRANSFER_TYPE_16_BIT   0x10

◆ EFI_ACPI_DMA_TRANSFER_TYPE_8_BIT

#define EFI_ACPI_DMA_TRANSFER_TYPE_8_BIT   0x00

◆ EFI_ACPI_DMA_TRANSFER_TYPE_8_BIT_AND_16_BIT

#define EFI_ACPI_DMA_TRANSFER_TYPE_8_BIT_AND_16_BIT   0x01

◆ EFI_ACPI_DMA_TRANSFER_TYPE_MASK

#define EFI_ACPI_DMA_TRANSFER_TYPE_MASK   0x03

◆ EFI_ACPI_IO_DECODE_10_BIT

#define EFI_ACPI_IO_DECODE_10_BIT   0x00

◆ EFI_ACPI_IO_DECODE_16_BIT

#define EFI_ACPI_IO_DECODE_16_BIT   0x01

◆ EFI_ACPI_IO_DECODE_MASK

#define EFI_ACPI_IO_DECODE_MASK   0x01

◆ EFI_ACPI_IRQ_EDGE_TRIGGERED

#define EFI_ACPI_IRQ_EDGE_TRIGGERED   0x01

◆ EFI_ACPI_IRQ_HIGH_TRUE

#define EFI_ACPI_IRQ_HIGH_TRUE   0x00

◆ EFI_ACPI_IRQ_LEVEL_TRIGGERED

#define EFI_ACPI_IRQ_LEVEL_TRIGGERED   0x00

◆ EFI_ACPI_IRQ_LOW_FALSE

#define EFI_ACPI_IRQ_LOW_FALSE   0x08

◆ EFI_ACPI_IRQ_MODE

#define EFI_ACPI_IRQ_MODE   0x01

◆ EFI_ACPI_IRQ_POLARITY_MASK

#define EFI_ACPI_IRQ_POLARITY_MASK   0x08

◆ EFI_ACPI_IRQ_SHARABLE

#define EFI_ACPI_IRQ_SHARABLE   0x10

◆ EFI_ACPI_IRQ_SHARABLE_MASK

#define EFI_ACPI_IRQ_SHARABLE_MASK   0x10

◆ EFI_ACPI_MEMORY_NON_WRITABLE

#define EFI_ACPI_MEMORY_NON_WRITABLE   0x00

◆ EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_ADDRESS_RANGE_ACPI

#define EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_ADDRESS_RANGE_ACPI   (2 << 3)

◆ EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_ADDRESS_RANGE_MEMORY

#define EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_ADDRESS_RANGE_MEMORY   (0 << 3)

◆ EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_ADDRESS_RANGE_RESERVED

#define EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_ADDRESS_RANGE_RESERVED   (1 << 3)

◆ EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_CACHEABLE

#define EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_CACHEABLE   (1 << 1)

◆ EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_CACHEABLE_PREFETCHABLE

#define EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_CACHEABLE_PREFETCHABLE   (3 << 1)

◆ EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_CACHEABLE_WRITE_COMBINING

#define EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_CACHEABLE_WRITE_COMBINING   (2 << 1)

◆ EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_NON_CACHEABLE

#define EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_NON_CACHEABLE   (0 << 1)

◆ EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_READ_ONLY

#define EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_READ_ONLY   (0 << 0)

◆ EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_READ_WRITE

#define EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_READ_WRITE   (1 << 0)

◆ EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_TYPE_STATIC

#define EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_TYPE_STATIC   (0 << 5)

◆ EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_TYPE_TRANSLATION

#define EFI_ACPI_MEMORY_RESOURCE_SPECIFIC_FLAG_TYPE_TRANSLATION   (1 << 5)

◆ EFI_ACPI_MEMORY_WRITABLE

#define EFI_ACPI_MEMORY_WRITABLE   0x01

◆ EFI_ACPI_MEMORY_WRITE_STATUS_MASK

#define EFI_ACPI_MEMORY_WRITE_STATUS_MASK   0x01

◆ EFI_ACPI_RESERVED_BYTE

#define EFI_ACPI_RESERVED_BYTE   0x00

◆ EFI_ACPI_RESERVED_DWORD

#define EFI_ACPI_RESERVED_DWORD   0x00000000

◆ EFI_ACPI_RESERVED_QWORD

#define EFI_ACPI_RESERVED_QWORD   0x0000000000000000

◆ EFI_ACPI_RESERVED_WORD

#define EFI_ACPI_RESERVED_WORD   0x0000

◆ EFI_APCI_MEMORY_RESOURCE_SPECIFIC_FLAG_ADDRESS_RANGE_NVS

#define EFI_APCI_MEMORY_RESOURCE_SPECIFIC_FLAG_ADDRESS_RANGE_NVS   (3 << 3)

Typedef Documentation

◆ [struct]

typedef PACKED struct { ... } ACPI_LARGE_RESOURCE_HEADER

◆ [union]

typedef PACKED union { ... } ACPI_SMALL_RESOURCE_HEADER

◆ [struct]

typedef PACKED struct { ... } EFI_ACPI_24_BIT_MEMORY_RANGE_DESCRIPTOR

24-Bit Memory Range Descriptor

◆ [struct]

typedef PACKED struct { ... } EFI_ACPI_32_BIT_FIXED_MEMORY_RANGE_DESCRIPTOR

Fixed 32-Bit Fixed Memory Range Descriptor

◆ [struct]

typedef PACKED struct { ... } EFI_ACPI_32_BIT_MEMORY_RANGE_DESCRIPTOR

32-Bit Memory Range Descriptor

◆ [struct]

typedef PACKED struct { ... } EFI_ACPI_ADDRESS_SPACE_DESCRIPTOR

The commond definition of QWORD, DWORD, and WORD Address Space Descriptors.

◆ [struct]

typedef PACKED struct { ... } EFI_ACPI_DMA_DESCRIPTOR

DMA Descriptor.

◆ [struct]

typedef PACKED struct { ... } EFI_ACPI_DWORD_ADDRESS_SPACE_DESCRIPTOR

DWORD Address Space Descriptor

◆ [struct]

typedef PACKED struct { ... } EFI_ACPI_EXTENDED_INTERRUPT_DESCRIPTOR

Extended Interrupt Descriptor

◆ [struct]

typedef PACKED struct { ... } EFI_ACPI_FIXED_LOCATION_IO_PORT_DESCRIPTOR

Fixed Location I/O Port Descriptor.

◆ [struct]

typedef PACKED struct { ... } EFI_ACPI_IO_PORT_DESCRIPTOR

I/O Port Descriptor

◆ [struct]

typedef PACKED struct { ... } EFI_ACPI_IRQ_DESCRIPTOR

IRQ Descriptor.

◆ [struct]

typedef PACKED struct { ... } EFI_ACPI_IRQ_NOFLAG_DESCRIPTOR

IRQ Descriptor.

◆ [struct]

typedef PACKED struct { ... } EFI_ACPI_QWORD_ADDRESS_SPACE_DESCRIPTOR

QWORD Address Space Descriptor

◆ [struct]

typedef PACKED struct { ... } EFI_ACPI_WORD_ADDRESS_SPACE_DESCRIPTOR

WORD Address Space Descriptor

Variable Documentation

◆ AddrLen

UINT16 AddrLen

◆ AddrRangeMax

UINT16 AddrRangeMax

◆ AddrRangeMin

UINT16 AddrRangeMin

◆ AddrSpaceGranularity

UINT16 AddrSpaceGranularity

◆ AddrTranslationOffset

UINT16 AddrTranslationOffset

◆ Alignment

UINT32 Alignment

◆ BaseAddress

UINT32 BaseAddress

◆ BaseAddressMax

UINT32 BaseAddressMax

◆ BaseAddressMin

UINT32 BaseAddressMin

◆ [struct]

PACKED struct { ... } Bits

◆ Byte

UINT8 Byte

◆ ChannelMask

UINT8 ChannelMask

◆ Desc

UINT8 Desc

◆ GenFlag

UINT8 GenFlag

◆ Header

ACPI_LARGE_RESOURCE_HEADER Header

◆ Information

UINT8 Information

◆ InterruptNumber

UINT32 InterruptNumber[1]

◆ InterruptTableLength

UINT8 InterruptTableLength

◆ InterruptVectorFlags

UINT8 InterruptVectorFlags

◆ Len

UINT16 Len

◆ Length

UINT32 Length

◆ Mask

UINT16 Mask

◆ Name

UINT8 Name

◆ ResType

UINT8 ResType

◆ SpecificFlag

UINT8 SpecificFlag

◆ Type

UINT8 Type
Generated by doxygen 1.9.8
