RamDisk.h File Reference

Go to the source code of this file.

Classes
struct	_EFI_RAM_DISK_PROTOCOL

Macros
#define	EFI_RAM_DISK_PROTOCOL_GUID    { 0xab38a0df, 0x6873, 0x44a9, { 0x87, 0xe6, 0xd4, 0xeb, 0x56, 0x14, 0x84, 0x49 }};

Typedefs
typedef struct _EFI_RAM_DISK_PROTOCOL	EFI_RAM_DISK_PROTOCOL
typedef EFI_STATUS(EFIAPI *	EFI_RAM_DISK_REGISTER_RAMDISK) (IN UINT64 RamDiskBase, IN UINT64 RamDiskSize, IN EFI_GUID *RamDiskType, IN EFI_DEVICE_PATH *ParentDevicePath OPTIONAL, OUT EFI_DEVICE_PATH_PROTOCOL **DevicePath)
typedef EFI_STATUS(EFIAPI *	EFI_RAM_DISK_UNREGISTER_RAMDISK) (IN EFI_DEVICE_PATH_PROTOCOL *DevicePath)

Variables
EFI_GUID	gEfiRamDiskProtocolGuid

Detailed Description

This file defines the EFI RAM Disk Protocol.

Copyright (c) 2016, Intel Corporation. All rights reserved.
This program and the accompanying materials are licensed and made available under the terms and conditions of the BSD License which accompanies this distribution. The full text of the license may be found at http://opensource.org/licenses/bsd-license.php

THE PROGRAM IS DISTRIBUTED UNDER THE BSD LICENSE ON AN "AS IS" BASIS, WITHOUT WARRANTIES OR REPRESENTATIONS OF ANY KIND, EITHER EXPRESS OR IMPLIED.

Revision Reference:

This Protocol is introduced in UEFI Specification 2.6

Macro Definition Documentation

EFI_RAM_DISK_PROTOCOL_GUID

#define EFI_RAM_DISK_PROTOCOL_GUID    { 0xab38a0df, 0x6873, 0x44a9, { 0x87, 0xe6, 0xd4, 0xeb, 0x56, 0x14, 0x84, 0x49 }};

Typedef Documentation

EFI_RAM_DISK_PROTOCOL

typedef struct _EFI_RAM_DISK_PROTOCOL EFI_RAM_DISK_PROTOCOL

EFI_RAM_DISK_REGISTER_RAMDISK

typedef EFI_STATUS(EFIAPI * EFI_RAM_DISK_REGISTER_RAMDISK) (IN UINT64 RamDiskBase, IN UINT64 RamDiskSize, IN EFI_GUID *RamDiskType, IN EFI_DEVICE_PATH *ParentDevicePath OPTIONAL, OUT EFI_DEVICE_PATH_PROTOCOL **DevicePath)

Register a RAM disk with specified address, size and type.

Parameters

[in]	RamDiskBase	The base address of registered RAM disk.
[in]	RamDiskSize	The size of registered RAM disk.
[in]	RamDiskType	The type of registered RAM disk. The GUID can be any of the values defined in section 9.3.6.9, or a vendor defined GUID.
[in]	ParentDevicePath	Pointer to the parent device path. If there is no parent device path then ParentDevicePath is NULL.
[out]	DevicePath	On return, points to a pointer to the device path of the RAM disk device. If ParentDevicePath is not NULL, the returned DevicePath is created by appending a RAM disk node to the parent device path. If ParentDevicePath is NULL, the returned DevicePath is a RAM disk device path without appending. This function is responsible for allocating the buffer DevicePath with the boot service AllocatePool().

Return values

EFI_SUCCESS	The RAM disk is registered successfully.
EFI_INVALID_PARAMETER	DevicePath or RamDiskType is NULL. RamDiskSize is 0.
EFI_ALREADY_STARTED	A Device Path Protocol instance to be created is already present in the handle database.
EFI_OUT_OF_RESOURCES	The RAM disk register operation fails due to resource limitation.

EFI_RAM_DISK_UNREGISTER_RAMDISK

typedef EFI_STATUS(EFIAPI * EFI_RAM_DISK_UNREGISTER_RAMDISK) (IN EFI_DEVICE_PATH_PROTOCOL *DevicePath)

Unregister a RAM disk specified by DevicePath.

Parameters

[in]

DevicePath

A pointer to the device path that describes a RAM Disk device.

Return values

EFI_SUCCESS	The RAM disk is unregistered successfully.
EFI_INVALID_PARAMETER	DevicePath is NULL.
EFI_UNSUPPORTED	The device specified by DevicePath is not a valid ramdisk device path and not supported by the driver.
EFI_NOT_FOUND	The RAM disk pointed by DevicePath doesn't exist.

Variable Documentation

gEfiRamDiskProtocolGuid

EFI_GUID gEfiRamDiskProtocolGuid

extern

RAM Disk Protocol GUID variable.
