This graph shows which files directly or indirectly include this file:

Classes
struct	s_pxe_hw_undi

struct	s_pxe_sw_undi

union	u_pxe_undi

struct	s_pxe_cdb

union	u_pxe_ip_addr

union	pxe_device

struct	s_pxe_cpb_start_30

struct	s_pxe_cpb_start_31

struct	s_pxe_db_get_init_info

struct	s_pxe_pci_config_info

struct	s_pxe_pcc_config_info

union	u_pxe_db_get_config_info

struct	s_pxe_cpb_initialize

struct	s_pxe_db_initialize

struct	s_pxe_cpb_receive_filters

struct	s_pxe_db_receive_filters

struct	s_pxe_cpb_station_address

struct	s_pxe_dpb_station_address

struct	s_pxe_db_statistics

struct	s_pxe_cpb_mcast_ip_to_mac

struct	s_pxe_db_mcast_ip_to_mac

struct	s_pxe_cpb_nvdata_sparse

union	u_pxe_cpb_nvdata_bulk

struct	s_pxe_db_nvdata

struct	s_pxe_db_get_status

struct	s_pxe_cpb_fill_header

struct	s_pxe_cpb_fill_header_fragmented

struct	s_pxe_cpb_transmit

struct	s_pxe_cpb_transmit_fragments

struct	s_pxe_cpb_receive

struct	s_pxe_db_receive

Macros
#define	PXE_BUSTYPE(a, b, c, d)

#define	PXE_BUSTYPE_PXE PXE_BUSTYPE ('!', 'P', 'X', 'E')

#define	PXE_BUSTYPE_PCI PXE_BUSTYPE ('P', 'C', 'I', 'R')

#define	PXE_BUSTYPE_PC_CARD PXE_BUSTYPE ('P', 'C', 'C', 'R')

#define	PXE_BUSTYPE_USB PXE_BUSTYPE ('U', 'S', 'B', 'R')

#define	PXE_BUSTYPE_1394 PXE_BUSTYPE ('1', '3', '9', '4')

#define	PXE_SWAP_UINT16(n) ((((PXE_UINT16) (n) & 0x00FF) << 8) \| (((PXE_UINT16) (n) & 0xFF00) >> 8))

#define	PXE_SWAP_UINT32(n)

#define	PXE_SWAP_UINT64(n)

#define	PXE_CPBSIZE_NOT_USED 0
	zero

#define	PXE_DBSIZE_NOT_USED 0
	zero

#define	PXE_CPBADDR_NOT_USED (PXE_UINT64) 0
	zero

#define	PXE_DBADDR_NOT_USED (PXE_UINT64) 0
	zero

#define	PXE_CONST CONST

#define	PXE_VOLATILE volatile

#define	PXE_FALSE 0
	zero

#define	PXE_TRUE (!PXE_FALSE)

#define	PXE_OPCODE_GET_STATE 0x0000

#define	PXE_OPCODE_START 0x0001

#define	PXE_OPCODE_STOP 0x0002

#define	PXE_OPCODE_GET_INIT_INFO 0x0003

#define	PXE_OPCODE_GET_CONFIG_INFO 0x0004

#define	PXE_OPCODE_INITIALIZE 0x0005

#define	PXE_OPCODE_RESET 0x0006

#define	PXE_OPCODE_SHUTDOWN 0x0007

#define	PXE_OPCODE_INTERRUPT_ENABLES 0x0008

#define	PXE_OPCODE_RECEIVE_FILTERS 0x0009

#define	PXE_OPCODE_STATION_ADDRESS 0x000A

#define	PXE_OPCODE_STATISTICS 0x000B

#define	PXE_OPCODE_MCAST_IP_TO_MAC 0x000C

#define	PXE_OPCODE_NVDATA 0x000D

#define	PXE_OPCODE_GET_STATUS 0x000E

#define	PXE_OPCODE_FILL_HEADER 0x000F

#define	PXE_OPCODE_TRANSMIT 0x0010

#define	PXE_OPCODE_RECEIVE 0x0011

#define	PXE_OPCODE_LAST_VALID 0x0011

#define	PXE_OPFLAGS_NOT_USED 0x0000

#define	PXE_OPFLAGS_INITIALIZE_CABLE_DETECT_MASK 0x0001

#define	PXE_OPFLAGS_INITIALIZE_DETECT_CABLE 0x0000

#define	PXE_OPFLAGS_INITIALIZE_DO_NOT_DETECT_CABLE 0x0001

#define	PXE_OPFLAGS_RESET_DISABLE_INTERRUPTS 0x0001

#define	PXE_OPFLAGS_RESET_DISABLE_FILTERS 0x0002

#define	PXE_OPFLAGS_INTERRUPT_OPMASK 0xC000

#define	PXE_OPFLAGS_INTERRUPT_ENABLE 0x8000

#define	PXE_OPFLAGS_INTERRUPT_DISABLE 0x4000

#define	PXE_OPFLAGS_INTERRUPT_READ 0x0000

#define	PXE_OPFLAGS_INTERRUPT_RECEIVE 0x0001

#define	PXE_OPFLAGS_INTERRUPT_TRANSMIT 0x0002

#define	PXE_OPFLAGS_INTERRUPT_COMMAND 0x0004

#define	PXE_OPFLAGS_INTERRUPT_SOFTWARE 0x0008

#define	PXE_OPFLAGS_RECEIVE_FILTER_OPMASK 0xC000

#define	PXE_OPFLAGS_RECEIVE_FILTER_ENABLE 0x8000

#define	PXE_OPFLAGS_RECEIVE_FILTER_DISABLE 0x4000

#define	PXE_OPFLAGS_RECEIVE_FILTER_READ 0x0000

#define	PXE_OPFLAGS_RECEIVE_FILTER_RESET_MCAST_LIST 0x2000

#define	PXE_OPFLAGS_RECEIVE_FILTER_UNICAST 0x0001

#define	PXE_OPFLAGS_RECEIVE_FILTER_BROADCAST 0x0002

#define	PXE_OPFLAGS_RECEIVE_FILTER_FILTERED_MULTICAST 0x0004

#define	PXE_OPFLAGS_RECEIVE_FILTER_PROMISCUOUS 0x0008

#define	PXE_OPFLAGS_RECEIVE_FILTER_ALL_MULTICAST 0x0010

#define	PXE_OPFLAGS_STATION_ADDRESS_READ 0x0000

#define	PXE_OPFLAGS_STATION_ADDRESS_WRITE 0x0000

#define	PXE_OPFLAGS_STATION_ADDRESS_RESET 0x0001

#define	PXE_OPFLAGS_STATISTICS_READ 0x0000

#define	PXE_OPFLAGS_STATISTICS_RESET 0x0001

#define	PXE_OPFLAGS_MCAST_IP_TO_MAC_OPMASK 0x0003

#define	PXE_OPFLAGS_MCAST_IPV4_TO_MAC 0x0000

#define	PXE_OPFLAGS_MCAST_IPV6_TO_MAC 0x0001

#define	PXE_OPFLAGS_NVDATA_OPMASK 0x0001

#define	PXE_OPFLAGS_NVDATA_READ 0x0000

#define	PXE_OPFLAGS_NVDATA_WRITE 0x0001

#define	PXE_OPFLAGS_GET_INTERRUPT_STATUS 0x0001

#define	PXE_OPFLAGS_GET_TRANSMITTED_BUFFERS 0x0002

#define	PXE_OPFLAGS_GET_MEDIA_STATUS 0x0004

#define	PXE_OPFLAGS_FILL_HEADER_OPMASK 0x0001

#define	PXE_OPFLAGS_FILL_HEADER_FRAGMENTED 0x0001

#define	PXE_OPFLAGS_FILL_HEADER_WHOLE 0x0000

#define	PXE_OPFLAGS_SWUNDI_TRANSMIT_OPMASK 0x0001

#define	PXE_OPFLAGS_TRANSMIT_BLOCK 0x0001

#define	PXE_OPFLAGS_TRANSMIT_DONT_BLOCK 0x0000

#define	PXE_OPFLAGS_TRANSMIT_OPMASK 0x0002

#define	PXE_OPFLAGS_TRANSMIT_FRAGMENTED 0x0002

#define	PXE_OPFLAGS_TRANSMIT_WHOLE 0x0000

#define	PXE_STATFLAGS_INITIALIZE 0x0000

#define	PXE_STATFLAGS_STATUS_MASK 0xC000

#define	PXE_STATFLAGS_COMMAND_COMPLETE 0xC000

#define	PXE_STATFLAGS_COMMAND_FAILED 0x8000

#define	PXE_STATFLAGS_COMMAND_QUEUED 0x4000

#define	PXE_STATFLAGS_GET_STATE_MASK 0x0003

#define	PXE_STATFLAGS_GET_STATE_INITIALIZED 0x0002

#define	PXE_STATFLAGS_GET_STATE_STARTED 0x0001

#define	PXE_STATFLAGS_GET_STATE_STOPPED 0x0000

#define	PXE_STATFLAGS_CABLE_DETECT_MASK 0x0001

#define	PXE_STATFLAGS_CABLE_DETECT_NOT_SUPPORTED 0x0000

#define	PXE_STATFLAGS_CABLE_DETECT_SUPPORTED 0x0001

#define	PXE_STATFLAGS_GET_STATUS_NO_MEDIA_MASK 0x0002

#define	PXE_STATFLAGS_GET_STATUS_NO_MEDIA_NOT_SUPPORTED 0x0000

#define	PXE_STATFLAGS_GET_STATUS_NO_MEDIA_SUPPORTED 0x0002

#define	PXE_STATFLAGS_INITIALIZED_NO_MEDIA 0x0001

#define	PXE_STATFLAGS_RESET_NO_MEDIA 0x0001

#define	PXE_STATFLAGS_INTERRUPT_RECEIVE 0x0001

#define	PXE_STATFLAGS_INTERRUPT_TRANSMIT 0x0002

#define	PXE_STATFLAGS_INTERRUPT_COMMAND 0x0004

#define	PXE_STATFLAGS_RECEIVE_FILTER_UNICAST 0x0001

#define	PXE_STATFLAGS_RECEIVE_FILTER_BROADCAST 0x0002

#define	PXE_STATFLAGS_RECEIVE_FILTER_FILTERED_MULTICAST 0x0004

#define	PXE_STATFLAGS_RECEIVE_FILTER_PROMISCUOUS 0x0008

#define	PXE_STATFLAGS_RECEIVE_FILTER_ALL_MULTICAST 0x0010

#define	PXE_STATFLAGS_GET_STATUS_INTERRUPT_MASK 0x000F
	/ UNDI MCast IP to MAC. / / No additional StatFlags.

#define	PXE_STATFLAGS_GET_STATUS_NO_INTERRUPTS 0x0000

#define	PXE_STATFLAGS_GET_STATUS_RECEIVE 0x0001

#define	PXE_STATFLAGS_GET_STATUS_TRANSMIT 0x0002

#define	PXE_STATFLAGS_GET_STATUS_COMMAND 0x0004

#define	PXE_STATFLAGS_GET_STATUS_SOFTWARE 0x0008

#define	PXE_STATFLAGS_GET_STATUS_TXBUF_QUEUE_EMPTY 0x0010

#define	PXE_STATFLAGS_GET_STATUS_NO_TXBUFS_WRITTEN 0x0020

#define	PXE_STATFLAGS_GET_STATUS_NO_MEDIA 0x0040

#define	PXE_STATCODE_INITIALIZE 0x0000

#define	PXE_STATCODE_SUCCESS 0x0000

#define	PXE_STATCODE_INVALID_CDB 0x0001

#define	PXE_STATCODE_INVALID_CPB 0x0002

#define	PXE_STATCODE_BUSY 0x0003

#define	PXE_STATCODE_QUEUE_FULL 0x0004

#define	PXE_STATCODE_ALREADY_STARTED 0x0005

#define	PXE_STATCODE_NOT_STARTED 0x0006

#define	PXE_STATCODE_NOT_SHUTDOWN 0x0007

#define	PXE_STATCODE_ALREADY_INITIALIZED 0x0008

#define	PXE_STATCODE_NOT_INITIALIZED 0x0009

#define	PXE_STATCODE_DEVICE_FAILURE 0x000A

#define	PXE_STATCODE_NVDATA_FAILURE 0x000B

#define	PXE_STATCODE_UNSUPPORTED 0x000C

#define	PXE_STATCODE_BUFFER_FULL 0x000D

#define	PXE_STATCODE_INVALID_PARAMETER 0x000E

#define	PXE_STATCODE_INVALID_UNDI 0x000F

#define	PXE_STATCODE_IPV4_NOT_SUPPORTED 0x0010

#define	PXE_STATCODE_IPV6_NOT_SUPPORTED 0x0011

#define	PXE_STATCODE_NOT_ENOUGH_MEMORY 0x0012

#define	PXE_STATCODE_NO_DATA 0x0013

#define	PXE_IFNUM_START 0x0000

#define	PXE_IFNUM_INVALID 0x0000

#define	PXE_CONTROL_QUEUE_IF_BUSY 0x0002

#define	PXE_CONTROL_LINK 0x0001

#define	PXE_CONTROL_LAST_CDB_IN_LIST 0x0000

#define	PXE_FRAME_TYPE_NONE 0x00

#define	PXE_FRAME_TYPE_UNICAST 0x01

#define	PXE_FRAME_TYPE_BROADCAST 0x02

#define	PXE_FRAME_TYPE_FILTERED_MULTICAST 0x03

#define	PXE_FRAME_TYPE_PROMISCUOUS 0x04

#define	PXE_FRAME_TYPE_PROMISCUOUS_MULTICAST 0x05

#define	PXE_FRAME_TYPE_MULTICAST PXE_FRAME_TYPE_FILTERED_MULTICAST

#define	PXE_MAC_LENGTH 32

#define	PXE_IFTYPE_ETHERNET 0x01

#define	PXE_IFTYPE_TOKENRING 0x04

#define	PXE_IFTYPE_FIBRE_CHANNEL 0x12

#define	PXE_HWSTAT_STATE_MASK 0xC0000000

#define	PXE_HWSTAT_BUSY 0xC0000000

#define	PXE_HWSTAT_INITIALIZED 0x80000000

#define	PXE_HWSTAT_STARTED 0x40000000

#define	PXE_HWSTAT_STOPPED 0x00000000

#define	PXE_HWSTAT_COMMAND_FAILED 0x20000000

#define	PXE_HWSTAT_PROMISCUOUS_MULTICAST_RX_ENABLED 0x00001000

#define	PXE_HWSTAT_PROMISCUOUS_RX_ENABLED 0x00000800

#define	PXE_HWSTAT_BROADCAST_RX_ENABLED 0x00000400

#define	PXE_HWSTAT_MULTICAST_RX_ENABLED 0x00000200

#define	PXE_HWSTAT_UNICAST_RX_ENABLED 0x00000100

#define	PXE_HWSTAT_SOFTWARE_INT_ENABLED 0x00000080

#define	PXE_HWSTAT_TX_COMPLETE_INT_ENABLED 0x00000040

#define	PXE_HWSTAT_PACKET_RX_INT_ENABLED 0x00000020

#define	PXE_HWSTAT_CMD_COMPLETE_INT_ENABLED 0x00000010

#define	PXE_HWSTAT_SOFTWARE_INT_PENDING 0x00000008

#define	PXE_HWSTAT_TX_COMPLETE_INT_PENDING 0x00000004

#define	PXE_HWSTAT_PACKET_RX_INT_PENDING 0x00000002

#define	PXE_HWSTAT_CMD_COMPLETE_INT_PENDING 0x00000001

#define	PXE_HWCMD_ISSUE_COMMAND 0x80000000

#define	PXE_HWCMD_INTS_AND_FILTS 0x00000000

#define	PXE_HWCMD_PROMISCUOUS_MULTICAST_RX_ENABLE 0x00001000

#define	PXE_HWCMD_PROMISCUOUS_RX_ENABLE 0x00000800

#define	PXE_HWCMD_BROADCAST_RX_ENABLE 0x00000400

#define	PXE_HWCMD_MULTICAST_RX_ENABLE 0x00000200

#define	PXE_HWCMD_UNICAST_RX_ENABLE 0x00000100

#define	PXE_HWCMD_SOFTWARE_INT_ENABLE 0x00000080

#define	PXE_HWCMD_TX_COMPLETE_INT_ENABLE 0x00000040

#define	PXE_HWCMD_PACKET_RX_INT_ENABLE 0x00000020

#define	PXE_HWCMD_CMD_COMPLETE_INT_ENABLE 0x00000010

#define	PXE_HWCMD_CLEAR_SOFTWARE_INT 0x00000008

#define	PXE_HWCMD_CLEAR_TX_COMPLETE_INT 0x00000004

#define	PXE_HWCMD_CLEAR_PACKET_RX_INT 0x00000002

#define	PXE_HWCMD_CLEAR_CMD_COMPLETE_INT 0x00000001

#define	PXE_ROMID_SIGNATURE PXE_BUSTYPE ('!', 'P', 'X', 'E')

#define	PXE_ROMID_REV 0x02

#define	PXE_ROMID_MAJORVER 0x03

#define	PXE_ROMID_MINORVER 0x01

#define	PXE_ROMID_IMP_HW_UNDI 0x80000000

#define	PXE_ROMID_IMP_SW_VIRT_ADDR 0x40000000

#define	PXE_ROMID_IMP_64BIT_DEVICE 0x00010000

#define	PXE_ROMID_IMP_FRAG_SUPPORTED 0x00008000

#define	PXE_ROMID_IMP_CMD_LINK_SUPPORTED 0x00004000

#define	PXE_ROMID_IMP_CMD_QUEUE_SUPPORTED 0x00002000

#define	PXE_ROMID_IMP_MULTI_FRAME_SUPPORTED 0x00001000

#define	PXE_ROMID_IMP_NVDATA_SUPPORT_MASK 0x00000C00

#define	PXE_ROMID_IMP_NVDATA_BULK_WRITABLE 0x00000C00

#define	PXE_ROMID_IMP_NVDATA_SPARSE_WRITABLE 0x00000800

#define	PXE_ROMID_IMP_NVDATA_READ_ONLY 0x00000400

#define	PXE_ROMID_IMP_NVDATA_NOT_AVAILABLE 0x00000000

#define	PXE_ROMID_IMP_STATISTICS_SUPPORTED 0x00000200

#define	PXE_ROMID_IMP_STATION_ADDR_SETTABLE 0x00000100

#define	PXE_ROMID_IMP_PROMISCUOUS_MULTICAST_RX_SUPPORTED 0x00000080

#define	PXE_ROMID_IMP_PROMISCUOUS_RX_SUPPORTED 0x00000040

#define	PXE_ROMID_IMP_BROADCAST_RX_SUPPORTED 0x00000020

#define	PXE_ROMID_IMP_FILTERED_MULTICAST_RX_SUPPORTED 0x00000010

#define	PXE_ROMID_IMP_SOFTWARE_INT_SUPPORTED 0x00000008

#define	PXE_ROMID_IMP_TX_COMPLETE_INT_SUPPORTED 0x00000004

#define	PXE_ROMID_IMP_PACKET_RX_INT_SUPPORTED 0x00000002

#define	PXE_ROMID_IMP_CMD_COMPLETE_INT_SUPPORTED 0x00000001

#define	MAX_PCI_CONFIG_LEN 64

#define	MAX_EEPROM_LEN 128

#define	MAX_XMIT_BUFFERS 32
	recycling Q length for xmit_done.

#define	MAX_MCAST_ADDRESS_CNT 8

#define	TO_AND_FROM_DEVICE 0

#define	FROM_DEVICE 1

#define	TO_DEVICE 2

#define	PXE_DELAY_MILLISECOND 1000

#define	PXE_DELAY_SECOND 1000000

#define	PXE_IO_READ 0

#define	PXE_IO_WRITE 1

#define	PXE_MEM_READ 2

#define	PXE_MEM_WRITE 4

#define	PXE_MAX_TXRX_UNIT_ETHER 1500

#define	PXE_HWADDR_LEN_ETHER 0x0006

#define	PXE_MAC_HEADER_LEN_ETHER 0x000E

#define	PXE_DUPLEX_ENABLE_FULL_SUPPORTED 1

#define	PXE_DUPLEX_FORCE_FULL_SUPPORTED 2

#define	PXE_LOOPBACK_INTERNAL_SUPPORTED 1

#define	PXE_LOOPBACK_EXTERNAL_SUPPORTED 2

#define	PXE_DUPLEX_DEFAULT 0x00

#define	PXE_FORCE_FULL_DUPLEX 0x01

#define	PXE_ENABLE_FULL_DUPLEX 0x02

#define	PXE_FORCE_HALF_DUPLEX 0x04

#define	PXE_DISABLE_FULL_DUPLEX 0x08

#define	LOOPBACK_NORMAL 0

#define	LOOPBACK_INTERNAL 1

#define	LOOPBACK_EXTERNAL 2

#define	PXE_STATISTICS_RX_TOTAL_FRAMES 0x00

#define	PXE_STATISTICS_RX_GOOD_FRAMES 0x01

#define	PXE_STATISTICS_RX_UNDERSIZE_FRAMES 0x02

#define	PXE_STATISTICS_RX_OVERSIZE_FRAMES 0x03

#define	PXE_STATISTICS_RX_DROPPED_FRAMES 0x04

#define	PXE_STATISTICS_RX_UNICAST_FRAMES 0x05

#define	PXE_STATISTICS_RX_BROADCAST_FRAMES 0x06

#define	PXE_STATISTICS_RX_MULTICAST_FRAMES 0x07

#define	PXE_STATISTICS_RX_CRC_ERROR_FRAMES 0x08

#define	PXE_STATISTICS_RX_TOTAL_BYTES 0x09

#define	PXE_STATISTICS_TX_TOTAL_FRAMES 0x0A

#define	PXE_STATISTICS_TX_GOOD_FRAMES 0x0B

#define	PXE_STATISTICS_TX_UNDERSIZE_FRAMES 0x0C

#define	PXE_STATISTICS_TX_OVERSIZE_FRAMES 0x0D

#define	PXE_STATISTICS_TX_DROPPED_FRAMES 0x0E

#define	PXE_STATISTICS_TX_UNICAST_FRAMES 0x0F

#define	PXE_STATISTICS_TX_BROADCAST_FRAMES 0x10

#define	PXE_STATISTICS_TX_MULTICAST_FRAMES 0x11

#define	PXE_STATISTICS_TX_CRC_ERROR_FRAMES 0x12

#define	PXE_STATISTICS_TX_TOTAL_BYTES 0x13

#define	PXE_STATISTICS_COLLISIONS 0x14

#define	PXE_STATISTICS_UNSUPPORTED_PROTOCOL 0x15

#define	PXE_STATISTICS_RX_DUPLICATED_FRAMES 0x16

#define	PXE_STATISTICS_RX_DECRYPT_ERROR_FRAMES 0x17

#define	PXE_STATISTICS_TX_ERROR_FRAMES 0x18

#define	PXE_STATISTICS_TX_RETRY_FRAMES 0x19

#define	PXE_PROTOCOL_ETHERNET_IP 0x0800

#define	PXE_PROTOCOL_ETHERNET_ARP 0x0806

#define	MAX_XMIT_FRAGMENTS 16

Typedefs
typedef VOID	PXE_VOID

typedef UINT8	PXE_UINT8

typedef UINT16	PXE_UINT16

typedef UINT32	PXE_UINT32

typedef UINTN	PXE_UINTN

typedef UINT64	PXE_UINT64

typedef PXE_UINT8	PXE_BOOL

typedef PXE_UINT16	PXE_OPCODE

typedef PXE_UINT16	PXE_OPFLAGS

typedef PXE_UINT16	PXE_STATFLAGS

typedef PXE_UINT16	PXE_STATCODE

typedef PXE_UINT16	PXE_IFNUM

typedef PXE_UINT16	PXE_CONTROL

typedef PXE_UINT8	PXE_FRAME_TYPE

typedef PXE_UINT32	PXE_IPV4

typedef PXE_UINT32	PXE_IPV6[4]

typedef PXE_UINT8	PXE_MAC_ADDR[PXE_MAC_LENGTH]

typedef PXE_UINT8	PXE_IFTYPE

typedef UINT16	PXE_MEDIA_PROTOCOL

typedef struct s_pxe_hw_undi	PXE_HW_UNDI

typedef struct s_pxe_sw_undi	PXE_SW_UNDI

typedef union u_pxe_undi	PXE_UNDI

typedef struct s_pxe_cdb	PXE_CDB

typedef union u_pxe_ip_addr	PXE_IP_ADDR

typedef union pxe_device	PXE_DEVICE

typedef struct s_pxe_cpb_start_30	PXE_CPB_START_30

typedef struct s_pxe_cpb_start_31	PXE_CPB_START_31

typedef struct s_pxe_db_get_init_info	PXE_DB_GET_INIT_INFO

typedef struct s_pxe_pci_config_info	PXE_PCI_CONFIG_INFO

typedef struct s_pxe_pcc_config_info	PXE_PCC_CONFIG_INFO

typedef union u_pxe_db_get_config_info	PXE_DB_GET_CONFIG_INFO

typedef struct s_pxe_cpb_initialize	PXE_CPB_INITIALIZE

typedef struct s_pxe_db_initialize	PXE_DB_INITIALIZE

typedef struct s_pxe_cpb_receive_filters	PXE_CPB_RECEIVE_FILTERS

typedef struct s_pxe_db_receive_filters	PXE_DB_RECEIVE_FILTERS

typedef struct s_pxe_cpb_station_address	PXE_CPB_STATION_ADDRESS

typedef struct s_pxe_dpb_station_address	PXE_DB_STATION_ADDRESS

typedef struct s_pxe_db_statistics	PXE_DB_STATISTICS

typedef struct s_pxe_cpb_mcast_ip_to_mac	PXE_CPB_MCAST_IP_TO_MAC

typedef struct s_pxe_db_mcast_ip_to_mac	PXE_DB_MCAST_IP_TO_MAC

typedef struct s_pxe_cpb_nvdata_sparse	PXE_CPB_NVDATA_SPARSE

typedef union u_pxe_cpb_nvdata_bulk	PXE_CPB_NVDATA_BULK

typedef struct s_pxe_db_nvdata	PXE_DB_NVDATA

typedef struct s_pxe_db_get_status	PXE_DB_GET_STATUS

typedef struct s_pxe_cpb_fill_header	PXE_CPB_FILL_HEADER

typedef struct s_pxe_cpb_fill_header_fragmented	PXE_CPB_FILL_HEADER_FRAGMENTED

typedef struct s_pxe_cpb_transmit	PXE_CPB_TRANSMIT

typedef struct s_pxe_cpb_transmit_fragments	PXE_CPB_TRANSMIT_FRAGMENTS

typedef struct s_pxe_cpb_receive	PXE_CPB_RECEIVE

typedef struct s_pxe_db_receive	PXE_DB_RECEIVE

Detailed Description

This header file contains all of the PXE type definitions, structure prototypes, global variables and constants that are needed for porting PXE to EFI.

Copyright (c) 2006 - 2018, Intel Corporation. All rights reserved.
This program and the accompanying materials are licensed and made available under the terms and conditions of the BSD License that accompanies this distribution. The full text of the license may be found at http://opensource.org/licenses/bsd-license.php.

THE PROGRAM IS DISTRIBUTED UNDER THE BSD LICENSE ON AN "AS IS" BASIS, WITHOUT WARRANTIES OR REPRESENTATIONS OF ANY KIND, EITHER EXPRESS OR IMPLIED.

Revision Reference:: 32/64-bit PXE specification: alpha-4, 99-Dec-17.

Macro Definition Documentation

◆ FROM_DEVICE

#define FROM_DEVICE 1

◆ LOOPBACK_EXTERNAL

#define LOOPBACK_EXTERNAL 2

◆ LOOPBACK_INTERNAL

#define LOOPBACK_INTERNAL 1

◆ LOOPBACK_NORMAL

#define LOOPBACK_NORMAL 0

◆ MAX_EEPROM_LEN

#define MAX_EEPROM_LEN 128

of dwords.

◆ MAX_MCAST_ADDRESS_CNT

#define MAX_MCAST_ADDRESS_CNT 8

◆ MAX_PCI_CONFIG_LEN

#define MAX_PCI_CONFIG_LEN 64

cpb and db definitions

of dwords.

◆ MAX_XMIT_BUFFERS

#define MAX_XMIT_BUFFERS 32

recycling Q length for xmit_done.

◆ MAX_XMIT_FRAGMENTS

#define MAX_XMIT_FRAGMENTS 16

◆ PXE_BUSTYPE

#define PXE_BUSTYPE	(	a,
		b,
		c,
		d
	)

Value:

    ( \
      (((PXE_UINT32) (d) & 0xFF) << 24) | (((PXE_UINT32) (c) & 0xFF) << 16) | (((PXE_UINT32) (b) & 0xFF) << 8) | \
        ((PXE_UINT32) (a) & 0xFF) \
    )

◆ PXE_BUSTYPE_1394

#define PXE_BUSTYPE_1394 PXE_BUSTYPE ('1', '3', '9', '4')

◆ PXE_BUSTYPE_PC_CARD

#define PXE_BUSTYPE_PC_CARD PXE_BUSTYPE ('P', 'C', 'C', 'R')

◆ PXE_BUSTYPE_PCI

#define PXE_BUSTYPE_PCI PXE_BUSTYPE ('P', 'C', 'I', 'R')

BUS ROM ID signatures.

◆ PXE_BUSTYPE_PXE

#define PXE_BUSTYPE_PXE PXE_BUSTYPE ('!', 'P', 'X', 'E')

UNDI ROM ID and devive ID signature.

◆ PXE_BUSTYPE_USB

#define PXE_BUSTYPE_USB PXE_BUSTYPE ('U', 'S', 'B', 'R')

◆ PXE_CONST

#define PXE_CONST CONST

◆ PXE_CONTROL_LAST_CDB_IN_LIST

#define PXE_CONTROL_LAST_CDB_IN_LIST 0x0000

◆ PXE_CONTROL_LINK

#define PXE_CONTROL_LINK 0x0001

These two bit values are used to determine if there are more UNDI CDB structures following this one. If the link bit is set, there must be a CDB structure following this one. Execution will start on the next CDB structure as soon as this one completes successfully. If an error is generated by this command, execution will stop.

◆ PXE_CONTROL_QUEUE_IF_BUSY

#define PXE_CONTROL_QUEUE_IF_BUSY 0x0002

Setting this flag directs the UNDI to queue this command for later execution if the UNDI is busy and it supports command queuing. If queuing is not supported, a PXE_STATCODE_INVALID_CONTROL error is returned. If the queue is full, a PXE_STATCODE_CDB_QUEUE_FULL error is returned.

◆ PXE_CPBADDR_NOT_USED

#define PXE_CPBADDR_NOT_USED (PXE_UINT64) 0

zero

◆ PXE_CPBSIZE_NOT_USED

#define PXE_CPBSIZE_NOT_USED 0

zero

◆ PXE_DBADDR_NOT_USED

#define PXE_DBADDR_NOT_USED (PXE_UINT64) 0

zero

◆ PXE_DBSIZE_NOT_USED

#define PXE_DBSIZE_NOT_USED 0

zero

◆ PXE_DELAY_MILLISECOND

#define PXE_DELAY_MILLISECOND 1000

◆ PXE_DELAY_SECOND

#define PXE_DELAY_SECOND 1000000

◆ PXE_DISABLE_FULL_DUPLEX

#define PXE_DISABLE_FULL_DUPLEX 0x08

◆ PXE_DUPLEX_DEFAULT

#define PXE_DUPLEX_DEFAULT 0x00

◆ PXE_DUPLEX_ENABLE_FULL_SUPPORTED

#define PXE_DUPLEX_ENABLE_FULL_SUPPORTED 1

◆ PXE_DUPLEX_FORCE_FULL_SUPPORTED

#define PXE_DUPLEX_FORCE_FULL_SUPPORTED 2

◆ PXE_ENABLE_FULL_DUPLEX

#define PXE_ENABLE_FULL_DUPLEX 0x02

◆ PXE_FALSE

#define PXE_FALSE 0

zero

◆ PXE_FORCE_FULL_DUPLEX

#define PXE_FORCE_FULL_DUPLEX 0x01

◆ PXE_FORCE_HALF_DUPLEX

#define PXE_FORCE_HALF_DUPLEX 0x04

◆ PXE_FRAME_TYPE_BROADCAST

#define PXE_FRAME_TYPE_BROADCAST 0x02

◆ PXE_FRAME_TYPE_FILTERED_MULTICAST

#define PXE_FRAME_TYPE_FILTERED_MULTICAST 0x03

◆ PXE_FRAME_TYPE_MULTICAST

#define PXE_FRAME_TYPE_MULTICAST PXE_FRAME_TYPE_FILTERED_MULTICAST

◆ PXE_FRAME_TYPE_NONE

#define PXE_FRAME_TYPE_NONE 0x00

◆ PXE_FRAME_TYPE_PROMISCUOUS

#define PXE_FRAME_TYPE_PROMISCUOUS 0x04

◆ PXE_FRAME_TYPE_PROMISCUOUS_MULTICAST

#define PXE_FRAME_TYPE_PROMISCUOUS_MULTICAST 0x05

◆ PXE_FRAME_TYPE_UNICAST

#define PXE_FRAME_TYPE_UNICAST 0x01

◆ PXE_HWADDR_LEN_ETHER

#define PXE_HWADDR_LEN_ETHER 0x0006

◆ PXE_HWCMD_BROADCAST_RX_ENABLE

#define PXE_HWCMD_BROADCAST_RX_ENABLE 0x00000400

◆ PXE_HWCMD_CLEAR_CMD_COMPLETE_INT

#define PXE_HWCMD_CLEAR_CMD_COMPLETE_INT 0x00000001

◆ PXE_HWCMD_CLEAR_PACKET_RX_INT

#define PXE_HWCMD_CLEAR_PACKET_RX_INT 0x00000002

◆ PXE_HWCMD_CLEAR_SOFTWARE_INT

#define PXE_HWCMD_CLEAR_SOFTWARE_INT 0x00000008

Use these to clear pending external interrupts.

◆ PXE_HWCMD_CLEAR_TX_COMPLETE_INT

#define PXE_HWCMD_CLEAR_TX_COMPLETE_INT 0x00000004

◆ PXE_HWCMD_CMD_COMPLETE_INT_ENABLE

#define PXE_HWCMD_CMD_COMPLETE_INT_ENABLE 0x00000010

◆ PXE_HWCMD_INTS_AND_FILTS

#define PXE_HWCMD_INTS_AND_FILTS 0x00000000

◆ PXE_HWCMD_ISSUE_COMMAND

#define PXE_HWCMD_ISSUE_COMMAND 0x80000000

Command port definitions. If set, CDB identified in CDBaddr port is given to UNDI. If not set, other bits in this word will be processed.

◆ PXE_HWCMD_MULTICAST_RX_ENABLE

#define PXE_HWCMD_MULTICAST_RX_ENABLE 0x00000200

◆ PXE_HWCMD_PACKET_RX_INT_ENABLE

#define PXE_HWCMD_PACKET_RX_INT_ENABLE 0x00000020

◆ PXE_HWCMD_PROMISCUOUS_MULTICAST_RX_ENABLE

#define PXE_HWCMD_PROMISCUOUS_MULTICAST_RX_ENABLE 0x00001000

Use these to enable/disable receive filters.

◆ PXE_HWCMD_PROMISCUOUS_RX_ENABLE

#define PXE_HWCMD_PROMISCUOUS_RX_ENABLE 0x00000800

◆ PXE_HWCMD_SOFTWARE_INT_ENABLE

#define PXE_HWCMD_SOFTWARE_INT_ENABLE 0x00000080

Use these to enable/disable external interrupts.

◆ PXE_HWCMD_TX_COMPLETE_INT_ENABLE

#define PXE_HWCMD_TX_COMPLETE_INT_ENABLE 0x00000040

◆ PXE_HWCMD_UNICAST_RX_ENABLE

#define PXE_HWCMD_UNICAST_RX_ENABLE 0x00000100

◆ PXE_HWSTAT_BROADCAST_RX_ENABLED

#define PXE_HWSTAT_BROADCAST_RX_ENABLED 0x00000400

◆ PXE_HWSTAT_BUSY

#define PXE_HWSTAT_BUSY 0xC0000000

◆ PXE_HWSTAT_CMD_COMPLETE_INT_ENABLED

#define PXE_HWSTAT_CMD_COMPLETE_INT_ENABLED 0x00000010

◆ PXE_HWSTAT_CMD_COMPLETE_INT_PENDING

#define PXE_HWSTAT_CMD_COMPLETE_INT_PENDING 0x00000001

◆ PXE_HWSTAT_COMMAND_FAILED

#define PXE_HWSTAT_COMMAND_FAILED 0x20000000

If set, last command failed.

◆ PXE_HWSTAT_INITIALIZED

#define PXE_HWSTAT_INITIALIZED 0x80000000

◆ PXE_HWSTAT_MULTICAST_RX_ENABLED

#define PXE_HWSTAT_MULTICAST_RX_ENABLED 0x00000200

◆ PXE_HWSTAT_PACKET_RX_INT_ENABLED

#define PXE_HWSTAT_PACKET_RX_INT_ENABLED 0x00000020

◆ PXE_HWSTAT_PACKET_RX_INT_PENDING

#define PXE_HWSTAT_PACKET_RX_INT_PENDING 0x00000002

◆ PXE_HWSTAT_PROMISCUOUS_MULTICAST_RX_ENABLED

#define PXE_HWSTAT_PROMISCUOUS_MULTICAST_RX_ENABLED 0x00001000

If set, identifies enabled receive filters.

◆ PXE_HWSTAT_PROMISCUOUS_RX_ENABLED

#define PXE_HWSTAT_PROMISCUOUS_RX_ENABLED 0x00000800

◆ PXE_HWSTAT_SOFTWARE_INT_ENABLED

#define PXE_HWSTAT_SOFTWARE_INT_ENABLED 0x00000080

If set, identifies enabled external interrupts.

◆ PXE_HWSTAT_SOFTWARE_INT_PENDING

#define PXE_HWSTAT_SOFTWARE_INT_PENDING 0x00000008

If set, identifies pending interrupts.

◆ PXE_HWSTAT_STARTED

#define PXE_HWSTAT_STARTED 0x40000000

◆ PXE_HWSTAT_STATE_MASK

#define PXE_HWSTAT_STATE_MASK 0xC0000000

Status port bit definitions. UNDI operation state.

◆ PXE_HWSTAT_STOPPED

#define PXE_HWSTAT_STOPPED 0x00000000

◆ PXE_HWSTAT_TX_COMPLETE_INT_ENABLED

#define PXE_HWSTAT_TX_COMPLETE_INT_ENABLED 0x00000040

◆ PXE_HWSTAT_TX_COMPLETE_INT_PENDING

#define PXE_HWSTAT_TX_COMPLETE_INT_PENDING 0x00000004

◆ PXE_HWSTAT_UNICAST_RX_ENABLED

#define PXE_HWSTAT_UNICAST_RX_ENABLED 0x00000100

◆ PXE_IFNUM_INVALID

#define PXE_IFNUM_INVALID 0x0000

This interface number is returned by the S/W UNDI Get State and Start commands if information in the CDB, CPB or DB is invalid.

◆ PXE_IFNUM_START

#define PXE_IFNUM_START 0x0000

This interface number must be passed to the S/W UNDI Start command.

◆ PXE_IFTYPE_ETHERNET

#define PXE_IFTYPE_ETHERNET 0x01

This information is from the ARP section of RFC 1700.

1 Ethernet (10Mb)                                    [JBP]
2 Experimental Ethernet (3Mb)                        [JBP]
3 Amateur Radio AX.25                                [PXK]
4 Proteon ProNET Token Ring                          [JBP]
5 Chaos                                              [GXP]
6 IEEE 802 Networks                                  [JBP]
7 ARCNET                                             [JBP]
8 Hyperchannel                                       [JBP]
9 Lanstar                                             [TU]

10 Autonet Short Address [MXB1] 11 LocalTalk [JKR1] 12 LocalNet (IBM* PCNet or SYTEK* LocalNET) [JXM] 13 Ultra link [RXD2] 14 SMDS [GXC1] 15 Frame Relay [AGM] 16 Asynchronous Transmission Mode (ATM) [JXB2] 17 HDLC [JBP] 18 Fibre Channel [Yakov Rekhter] 19 Asynchronous Transmission Mode (ATM) [Mark Laubach] 20 Serial Line [JBP] 21 Asynchronous Transmission Mode (ATM) [MXB1]

Other names and brands may be claimed as the property of others.

◆ PXE_IFTYPE_FIBRE_CHANNEL

#define PXE_IFTYPE_FIBRE_CHANNEL 0x12

◆ PXE_IFTYPE_TOKENRING

#define PXE_IFTYPE_TOKENRING 0x04

◆ PXE_IO_READ

#define PXE_IO_READ 0

◆ PXE_IO_WRITE

#define PXE_IO_WRITE 1

◆ PXE_LOOPBACK_EXTERNAL_SUPPORTED

#define PXE_LOOPBACK_EXTERNAL_SUPPORTED 2

◆ PXE_LOOPBACK_INTERNAL_SUPPORTED

#define PXE_LOOPBACK_INTERNAL_SUPPORTED 1

◆ PXE_MAC_HEADER_LEN_ETHER

#define PXE_MAC_HEADER_LEN_ETHER 0x000E

◆ PXE_MAC_LENGTH

#define PXE_MAC_LENGTH 32

◆ PXE_MAX_TXRX_UNIT_ETHER

#define PXE_MAX_TXRX_UNIT_ETHER 1500

◆ PXE_MEM_READ

#define PXE_MEM_READ 2

◆ PXE_MEM_WRITE

#define PXE_MEM_WRITE 4

◆ PXE_OPCODE_FILL_HEADER

#define PXE_OPCODE_FILL_HEADER 0x000F

Fill media header in packet for transmit.

◆ PXE_OPCODE_GET_CONFIG_INFO

#define PXE_OPCODE_GET_CONFIG_INFO 0x0004

Get NIC configuration information.

◆ PXE_OPCODE_GET_INIT_INFO

#define PXE_OPCODE_GET_INIT_INFO 0x0003

Get UNDI initialization information.

◆ PXE_OPCODE_GET_STATE

#define PXE_OPCODE_GET_STATE 0x0000

Return UNDI operational state.

◆ PXE_OPCODE_GET_STATUS

#define PXE_OPCODE_GET_STATUS 0x000E

Get & clear interrupt status.

◆ PXE_OPCODE_INITIALIZE

#define PXE_OPCODE_INITIALIZE 0x0005

Changed UNDI operational state from Started to Initialized.

◆ PXE_OPCODE_INTERRUPT_ENABLES

#define PXE_OPCODE_INTERRUPT_ENABLES 0x0008

Read & change state of external interrupt enables.

◆ PXE_OPCODE_LAST_VALID

#define PXE_OPCODE_LAST_VALID 0x0011

Last valid PXE UNDI OpCode number.

◆ PXE_OPCODE_MCAST_IP_TO_MAC

#define PXE_OPCODE_MCAST_IP_TO_MAC 0x000C

Convert multicast IP address to multicast MAC address.

◆ PXE_OPCODE_NVDATA

#define PXE_OPCODE_NVDATA 0x000D

Read or change non-volatile storage on the NIC.

◆ PXE_OPCODE_RECEIVE

#define PXE_OPCODE_RECEIVE 0x0011

Receive packet.

◆ PXE_OPCODE_RECEIVE_FILTERS

#define PXE_OPCODE_RECEIVE_FILTERS 0x0009

Read & change state of packet receive filters.

◆ PXE_OPCODE_RESET

#define PXE_OPCODE_RESET 0x0006

Re-initialize the NIC H/W.

◆ PXE_OPCODE_SHUTDOWN

#define PXE_OPCODE_SHUTDOWN 0x0007

Change the UNDI operational state from Initialized to Started.

◆ PXE_OPCODE_START

#define PXE_OPCODE_START 0x0001

Change UNDI operational state from Stopped to Started.

◆ PXE_OPCODE_STATION_ADDRESS

#define PXE_OPCODE_STATION_ADDRESS 0x000A

Read & change station MAC address.

◆ PXE_OPCODE_STATISTICS

#define PXE_OPCODE_STATISTICS 0x000B

Read traffic statistics.

◆ PXE_OPCODE_STOP

#define PXE_OPCODE_STOP 0x0002

Change UNDI operational state from Started to Stopped.

◆ PXE_OPCODE_TRANSMIT

#define PXE_OPCODE_TRANSMIT 0x0010

Transmit packet(s).

◆ PXE_OPFLAGS_FILL_HEADER_FRAGMENTED

#define PXE_OPFLAGS_FILL_HEADER_FRAGMENTED 0x0001

◆ PXE_OPFLAGS_FILL_HEADER_OPMASK

#define PXE_OPFLAGS_FILL_HEADER_OPMASK 0x0001

UNDI Fill Header.

◆ PXE_OPFLAGS_FILL_HEADER_WHOLE

#define PXE_OPFLAGS_FILL_HEADER_WHOLE 0x0000

◆ PXE_OPFLAGS_GET_INTERRUPT_STATUS

#define PXE_OPFLAGS_GET_INTERRUPT_STATUS 0x0001

UNDI Get Status.

Return current interrupt status. This will also clear any interrupts that are currently set. This can be used in a polling routine. The interrupt flags are still set and cleared even when the interrupts are disabled.

◆ PXE_OPFLAGS_GET_MEDIA_STATUS

#define PXE_OPFLAGS_GET_MEDIA_STATUS 0x0004

Return current media status.

◆ PXE_OPFLAGS_GET_TRANSMITTED_BUFFERS

#define PXE_OPFLAGS_GET_TRANSMITTED_BUFFERS 0x0002

Return list of transmitted buffers for recycling. Transmit buffers must not be changed or unallocated until they have recycled. After issuing a transmit command, wait for a transmit complete interrupt. When a transmit complete interrupt is received, read the transmitted buffers. Do not plan on getting one buffer per interrupt. Some NICs and UNDIs may transmit multiple buffers per interrupt.

◆ PXE_OPFLAGS_INITIALIZE_CABLE_DETECT_MASK

#define PXE_OPFLAGS_INITIALIZE_CABLE_DETECT_MASK 0x0001

UNDI Initialize

◆ PXE_OPFLAGS_INITIALIZE_DETECT_CABLE

#define PXE_OPFLAGS_INITIALIZE_DETECT_CABLE 0x0000

◆ PXE_OPFLAGS_INITIALIZE_DO_NOT_DETECT_CABLE

#define PXE_OPFLAGS_INITIALIZE_DO_NOT_DETECT_CABLE 0x0001

◆ PXE_OPFLAGS_INTERRUPT_COMMAND

#define PXE_OPFLAGS_INTERRUPT_COMMAND 0x0004

Enable command interrupts. An external interrupt will be generated when command execution stops.

◆ PXE_OPFLAGS_INTERRUPT_DISABLE

#define PXE_OPFLAGS_INTERRUPT_DISABLE 0x4000

◆ PXE_OPFLAGS_INTERRUPT_ENABLE

#define PXE_OPFLAGS_INTERRUPT_ENABLE 0x8000

◆ PXE_OPFLAGS_INTERRUPT_OPMASK

#define PXE_OPFLAGS_INTERRUPT_OPMASK 0xC000

UNDI Shutdown.

No OpFlags. UNDI Interrupt Enables.

Select whether to enable or disable external interrupt signals. Setting both enable and disable will return PXE_STATCODE_INVALID_OPFLAGS.

◆ PXE_OPFLAGS_INTERRUPT_READ

#define PXE_OPFLAGS_INTERRUPT_READ 0x0000

◆ PXE_OPFLAGS_INTERRUPT_RECEIVE

#define PXE_OPFLAGS_INTERRUPT_RECEIVE 0x0001

Enable receive interrupts. An external interrupt will be generated after a complete non-error packet has been received.

◆ PXE_OPFLAGS_INTERRUPT_SOFTWARE

#define PXE_OPFLAGS_INTERRUPT_SOFTWARE 0x0008

Generate software interrupt. Setting this bit generates an external interrupt, if it is supported by the hardware.

◆ PXE_OPFLAGS_INTERRUPT_TRANSMIT

#define PXE_OPFLAGS_INTERRUPT_TRANSMIT 0x0002

Enable transmit interrupts. An external interrupt will be generated after a complete non-error packet has been transmitted.

◆ PXE_OPFLAGS_MCAST_IP_TO_MAC_OPMASK

#define PXE_OPFLAGS_MCAST_IP_TO_MAC_OPMASK 0x0003

UNDI MCast IP to MAC.

Identify the type of IP address in the CPB.

◆ PXE_OPFLAGS_MCAST_IPV4_TO_MAC

#define PXE_OPFLAGS_MCAST_IPV4_TO_MAC 0x0000

◆ PXE_OPFLAGS_MCAST_IPV6_TO_MAC

#define PXE_OPFLAGS_MCAST_IPV6_TO_MAC 0x0001

◆ PXE_OPFLAGS_NOT_USED

#define PXE_OPFLAGS_NOT_USED 0x0000

◆ PXE_OPFLAGS_NVDATA_OPMASK

#define PXE_OPFLAGS_NVDATA_OPMASK 0x0001

UNDI NvData.

Select the type of non-volatile data operation.

◆ PXE_OPFLAGS_NVDATA_READ

#define PXE_OPFLAGS_NVDATA_READ 0x0000

◆ PXE_OPFLAGS_NVDATA_WRITE

#define PXE_OPFLAGS_NVDATA_WRITE 0x0001

◆ PXE_OPFLAGS_RECEIVE_FILTER_ALL_MULTICAST

#define PXE_OPFLAGS_RECEIVE_FILTER_ALL_MULTICAST 0x0010

Enable promiscuous multicast packet receiving. All multicast packets will be received.

◆ PXE_OPFLAGS_RECEIVE_FILTER_BROADCAST

#define PXE_OPFLAGS_RECEIVE_FILTER_BROADCAST 0x0002

Enable broadcast packet receiving. Packets sent to the broadcast MAC address will be received.

◆ PXE_OPFLAGS_RECEIVE_FILTER_DISABLE

#define PXE_OPFLAGS_RECEIVE_FILTER_DISABLE 0x4000

◆ PXE_OPFLAGS_RECEIVE_FILTER_ENABLE

#define PXE_OPFLAGS_RECEIVE_FILTER_ENABLE 0x8000

◆ PXE_OPFLAGS_RECEIVE_FILTER_FILTERED_MULTICAST

#define PXE_OPFLAGS_RECEIVE_FILTER_FILTERED_MULTICAST 0x0004

Enable filtered multicast packet receiving. Packets sent to any of the multicast MAC addresses in the multicast MAC address filter list will be received. If the filter list is empty, no multicast

◆ PXE_OPFLAGS_RECEIVE_FILTER_OPMASK

#define PXE_OPFLAGS_RECEIVE_FILTER_OPMASK 0xC000

UNDI Receive Filters.

Select whether to enable or disable receive filters. Setting both enable and disable will return PXE_STATCODE_INVALID_OPCODE.

◆ PXE_OPFLAGS_RECEIVE_FILTER_PROMISCUOUS

#define PXE_OPFLAGS_RECEIVE_FILTER_PROMISCUOUS 0x0008

Enable promiscuous packet receiving. All packets will be received.

◆ PXE_OPFLAGS_RECEIVE_FILTER_READ

#define PXE_OPFLAGS_RECEIVE_FILTER_READ 0x0000

◆ PXE_OPFLAGS_RECEIVE_FILTER_RESET_MCAST_LIST

#define PXE_OPFLAGS_RECEIVE_FILTER_RESET_MCAST_LIST 0x2000

To reset the contents of the multicast MAC address filter list, set this OpFlag:

◆ PXE_OPFLAGS_RECEIVE_FILTER_UNICAST

#define PXE_OPFLAGS_RECEIVE_FILTER_UNICAST 0x0001

Enable unicast packet receiving. Packets sent to the current station MAC address will be received.

◆ PXE_OPFLAGS_RESET_DISABLE_FILTERS

#define PXE_OPFLAGS_RESET_DISABLE_FILTERS 0x0002

◆ PXE_OPFLAGS_RESET_DISABLE_INTERRUPTS

#define PXE_OPFLAGS_RESET_DISABLE_INTERRUPTS 0x0001

UNDI Reset

◆ PXE_OPFLAGS_STATION_ADDRESS_READ

#define PXE_OPFLAGS_STATION_ADDRESS_READ 0x0000

UNDI Station Address.

◆ PXE_OPFLAGS_STATION_ADDRESS_RESET

#define PXE_OPFLAGS_STATION_ADDRESS_RESET 0x0001

◆ PXE_OPFLAGS_STATION_ADDRESS_WRITE

#define PXE_OPFLAGS_STATION_ADDRESS_WRITE 0x0000

◆ PXE_OPFLAGS_STATISTICS_READ

#define PXE_OPFLAGS_STATISTICS_READ 0x0000

UNDI Statistics.

◆ PXE_OPFLAGS_STATISTICS_RESET

#define PXE_OPFLAGS_STATISTICS_RESET 0x0001

◆ PXE_OPFLAGS_SWUNDI_TRANSMIT_OPMASK

#define PXE_OPFLAGS_SWUNDI_TRANSMIT_OPMASK 0x0001

UNDI Transmit.

S/W UNDI only. Return after the packet has been transmitted. A transmit complete interrupt will still be generated and the transmit buffer will have to be recycled.

◆ PXE_OPFLAGS_TRANSMIT_BLOCK

#define PXE_OPFLAGS_TRANSMIT_BLOCK 0x0001

◆ PXE_OPFLAGS_TRANSMIT_DONT_BLOCK

#define PXE_OPFLAGS_TRANSMIT_DONT_BLOCK 0x0000

◆ PXE_OPFLAGS_TRANSMIT_FRAGMENTED

#define PXE_OPFLAGS_TRANSMIT_FRAGMENTED 0x0002

◆ PXE_OPFLAGS_TRANSMIT_OPMASK

#define PXE_OPFLAGS_TRANSMIT_OPMASK 0x0002

◆ PXE_OPFLAGS_TRANSMIT_WHOLE

#define PXE_OPFLAGS_TRANSMIT_WHOLE 0x0000

◆ PXE_PROTOCOL_ETHERNET_ARP

#define PXE_PROTOCOL_ETHERNET_ARP 0x0806

◆ PXE_PROTOCOL_ETHERNET_IP

#define PXE_PROTOCOL_ETHERNET_IP 0x0800

◆ PXE_ROMID_IMP_64BIT_DEVICE

#define PXE_ROMID_IMP_64BIT_DEVICE 0x00010000

◆ PXE_ROMID_IMP_BROADCAST_RX_SUPPORTED

#define PXE_ROMID_IMP_BROADCAST_RX_SUPPORTED 0x00000020

◆ PXE_ROMID_IMP_CMD_COMPLETE_INT_SUPPORTED

#define PXE_ROMID_IMP_CMD_COMPLETE_INT_SUPPORTED 0x00000001

◆ PXE_ROMID_IMP_CMD_LINK_SUPPORTED

#define PXE_ROMID_IMP_CMD_LINK_SUPPORTED 0x00004000

◆ PXE_ROMID_IMP_CMD_QUEUE_SUPPORTED

#define PXE_ROMID_IMP_CMD_QUEUE_SUPPORTED 0x00002000

◆ PXE_ROMID_IMP_FILTERED_MULTICAST_RX_SUPPORTED

#define PXE_ROMID_IMP_FILTERED_MULTICAST_RX_SUPPORTED 0x00000010

◆ PXE_ROMID_IMP_FRAG_SUPPORTED

#define PXE_ROMID_IMP_FRAG_SUPPORTED 0x00008000

◆ PXE_ROMID_IMP_HW_UNDI

#define PXE_ROMID_IMP_HW_UNDI 0x80000000

Implementation flags.

◆ PXE_ROMID_IMP_MULTI_FRAME_SUPPORTED

#define PXE_ROMID_IMP_MULTI_FRAME_SUPPORTED 0x00001000

◆ PXE_ROMID_IMP_NVDATA_BULK_WRITABLE

#define PXE_ROMID_IMP_NVDATA_BULK_WRITABLE 0x00000C00

◆ PXE_ROMID_IMP_NVDATA_NOT_AVAILABLE

#define PXE_ROMID_IMP_NVDATA_NOT_AVAILABLE 0x00000000

◆ PXE_ROMID_IMP_NVDATA_READ_ONLY

#define PXE_ROMID_IMP_NVDATA_READ_ONLY 0x00000400

◆ PXE_ROMID_IMP_NVDATA_SPARSE_WRITABLE

#define PXE_ROMID_IMP_NVDATA_SPARSE_WRITABLE 0x00000800

◆ PXE_ROMID_IMP_NVDATA_SUPPORT_MASK

#define PXE_ROMID_IMP_NVDATA_SUPPORT_MASK 0x00000C00

◆ PXE_ROMID_IMP_PACKET_RX_INT_SUPPORTED

#define PXE_ROMID_IMP_PACKET_RX_INT_SUPPORTED 0x00000002

◆ PXE_ROMID_IMP_PROMISCUOUS_MULTICAST_RX_SUPPORTED

#define PXE_ROMID_IMP_PROMISCUOUS_MULTICAST_RX_SUPPORTED 0x00000080

◆ PXE_ROMID_IMP_PROMISCUOUS_RX_SUPPORTED

#define PXE_ROMID_IMP_PROMISCUOUS_RX_SUPPORTED 0x00000040

◆ PXE_ROMID_IMP_SOFTWARE_INT_SUPPORTED

#define PXE_ROMID_IMP_SOFTWARE_INT_SUPPORTED 0x00000008

◆ PXE_ROMID_IMP_STATION_ADDR_SETTABLE

#define PXE_ROMID_IMP_STATION_ADDR_SETTABLE 0x00000100

◆ PXE_ROMID_IMP_STATISTICS_SUPPORTED

#define PXE_ROMID_IMP_STATISTICS_SUPPORTED 0x00000200

◆ PXE_ROMID_IMP_SW_VIRT_ADDR

#define PXE_ROMID_IMP_SW_VIRT_ADDR 0x40000000

◆ PXE_ROMID_IMP_TX_COMPLETE_INT_SUPPORTED

#define PXE_ROMID_IMP_TX_COMPLETE_INT_SUPPORTED 0x00000004

◆ PXE_ROMID_MAJORVER

#define PXE_ROMID_MAJORVER 0x03

UNDI command interface revision. These are the values that get sent in option 94 (Client Network Interface Identifier) in the DHCP Discover and PXE Boot Server Request packets.

◆ PXE_ROMID_MINORVER

#define PXE_ROMID_MINORVER 0x01

◆ PXE_ROMID_REV

#define PXE_ROMID_REV 0x02

!PXE structure format revision

◆ PXE_ROMID_SIGNATURE

#define PXE_ROMID_SIGNATURE PXE_BUSTYPE ('!', 'P', 'X', 'E')

Signature of !PXE structure.

◆ PXE_STATCODE_ALREADY_INITIALIZED

#define PXE_STATCODE_ALREADY_INITIALIZED 0x0008

◆ PXE_STATCODE_ALREADY_STARTED

#define PXE_STATCODE_ALREADY_STARTED 0x0005

◆ PXE_STATCODE_BUFFER_FULL

#define PXE_STATCODE_BUFFER_FULL 0x000D

◆ PXE_STATCODE_BUSY

#define PXE_STATCODE_BUSY 0x0003

◆ PXE_STATCODE_DEVICE_FAILURE

#define PXE_STATCODE_DEVICE_FAILURE 0x000A

◆ PXE_STATCODE_INITIALIZE

#define PXE_STATCODE_INITIALIZE 0x0000

◆ PXE_STATCODE_INVALID_CDB

#define PXE_STATCODE_INVALID_CDB 0x0001

◆ PXE_STATCODE_INVALID_CPB

#define PXE_STATCODE_INVALID_CPB 0x0002

◆ PXE_STATCODE_INVALID_PARAMETER

#define PXE_STATCODE_INVALID_PARAMETER 0x000E

◆ PXE_STATCODE_INVALID_UNDI

#define PXE_STATCODE_INVALID_UNDI 0x000F

◆ PXE_STATCODE_IPV4_NOT_SUPPORTED

#define PXE_STATCODE_IPV4_NOT_SUPPORTED 0x0010

◆ PXE_STATCODE_IPV6_NOT_SUPPORTED

#define PXE_STATCODE_IPV6_NOT_SUPPORTED 0x0011

◆ PXE_STATCODE_NO_DATA

#define PXE_STATCODE_NO_DATA 0x0013

◆ PXE_STATCODE_NOT_ENOUGH_MEMORY

#define PXE_STATCODE_NOT_ENOUGH_MEMORY 0x0012

◆ PXE_STATCODE_NOT_INITIALIZED

#define PXE_STATCODE_NOT_INITIALIZED 0x0009

◆ PXE_STATCODE_NOT_SHUTDOWN

#define PXE_STATCODE_NOT_SHUTDOWN 0x0007

◆ PXE_STATCODE_NOT_STARTED

#define PXE_STATCODE_NOT_STARTED 0x0006

◆ PXE_STATCODE_NVDATA_FAILURE

#define PXE_STATCODE_NVDATA_FAILURE 0x000B

◆ PXE_STATCODE_QUEUE_FULL

#define PXE_STATCODE_QUEUE_FULL 0x0004

◆ PXE_STATCODE_SUCCESS

#define PXE_STATCODE_SUCCESS 0x0000

Common StatCodes returned by all UNDI commands, UNDI protocol functions and BC protocol functions.

◆ PXE_STATCODE_UNSUPPORTED

#define PXE_STATCODE_UNSUPPORTED 0x000C

◆ PXE_STATFLAGS_CABLE_DETECT_MASK

#define PXE_STATFLAGS_CABLE_DETECT_MASK 0x0001

UNDI Start.

No additional StatFlags. UNDI Get Init Info.

◆ PXE_STATFLAGS_CABLE_DETECT_NOT_SUPPORTED

#define PXE_STATFLAGS_CABLE_DETECT_NOT_SUPPORTED 0x0000

◆ PXE_STATFLAGS_CABLE_DETECT_SUPPORTED

#define PXE_STATFLAGS_CABLE_DETECT_SUPPORTED 0x0001

◆ PXE_STATFLAGS_COMMAND_COMPLETE

#define PXE_STATFLAGS_COMMAND_COMPLETE 0xC000

◆ PXE_STATFLAGS_COMMAND_FAILED

#define PXE_STATFLAGS_COMMAND_FAILED 0x8000

◆ PXE_STATFLAGS_COMMAND_QUEUED

#define PXE_STATFLAGS_COMMAND_QUEUED 0x4000

◆ PXE_STATFLAGS_GET_STATE_INITIALIZED

#define PXE_STATFLAGS_GET_STATE_INITIALIZED 0x0002

◆ PXE_STATFLAGS_GET_STATE_MASK

#define PXE_STATFLAGS_GET_STATE_MASK 0x0003

UNDI Get State.

◆ PXE_STATFLAGS_GET_STATE_STARTED

#define PXE_STATFLAGS_GET_STATE_STARTED 0x0001

◆ PXE_STATFLAGS_GET_STATE_STOPPED

#define PXE_STATFLAGS_GET_STATE_STOPPED 0x0000

◆ PXE_STATFLAGS_GET_STATUS_COMMAND

#define PXE_STATFLAGS_GET_STATUS_COMMAND 0x0004

If set, at least one command interrupt occurred.

◆ PXE_STATFLAGS_GET_STATUS_INTERRUPT_MASK

#define PXE_STATFLAGS_GET_STATUS_INTERRUPT_MASK 0x000F

/ UNDI MCast IP to MAC. / / No additional StatFlags.

UNDI Station Address.

No additional StatFlags. UNDI Statistics.

No additional StatFlags. UNDI NvData.

No additional StatFlags. UNDI Get Status. Use to determine if an interrupt has occurred.

◆ PXE_STATFLAGS_GET_STATUS_NO_INTERRUPTS

#define PXE_STATFLAGS_GET_STATUS_NO_INTERRUPTS 0x0000

◆ PXE_STATFLAGS_GET_STATUS_NO_MEDIA

#define PXE_STATFLAGS_GET_STATUS_NO_MEDIA 0x0040

This flag is set if there is no media detected.

◆ PXE_STATFLAGS_GET_STATUS_NO_MEDIA_MASK

#define PXE_STATFLAGS_GET_STATUS_NO_MEDIA_MASK 0x0002

◆ PXE_STATFLAGS_GET_STATUS_NO_MEDIA_NOT_SUPPORTED

#define PXE_STATFLAGS_GET_STATUS_NO_MEDIA_NOT_SUPPORTED 0x0000

◆ PXE_STATFLAGS_GET_STATUS_NO_MEDIA_SUPPORTED

#define PXE_STATFLAGS_GET_STATUS_NO_MEDIA_SUPPORTED 0x0002

◆ PXE_STATFLAGS_GET_STATUS_NO_TXBUFS_WRITTEN

#define PXE_STATFLAGS_GET_STATUS_NO_TXBUFS_WRITTEN 0x0020

This flag is set if no transmitted buffer addresses were written into the DB. (This could be because DBsize was too small.)

◆ PXE_STATFLAGS_GET_STATUS_RECEIVE

#define PXE_STATFLAGS_GET_STATUS_RECEIVE 0x0001

If set, at least one receive interrupt occurred.

◆ PXE_STATFLAGS_GET_STATUS_SOFTWARE

#define PXE_STATFLAGS_GET_STATUS_SOFTWARE 0x0008

If set, at least one software interrupt occurred.

◆ PXE_STATFLAGS_GET_STATUS_TRANSMIT

#define PXE_STATFLAGS_GET_STATUS_TRANSMIT 0x0002

If set, at least one transmit interrupt occurred.

◆ PXE_STATFLAGS_GET_STATUS_TXBUF_QUEUE_EMPTY

#define PXE_STATFLAGS_GET_STATUS_TXBUF_QUEUE_EMPTY 0x0010

This flag is set if the transmitted buffer queue is empty. This flag will be set if all transmitted buffer addresses get written into the DB.

◆ PXE_STATFLAGS_INITIALIZE

#define PXE_STATFLAGS_INITIALIZE 0x0000

◆ PXE_STATFLAGS_INITIALIZED_NO_MEDIA

#define PXE_STATFLAGS_INITIALIZED_NO_MEDIA 0x0001

UNDI Initialize.

◆ PXE_STATFLAGS_INTERRUPT_COMMAND

#define PXE_STATFLAGS_INTERRUPT_COMMAND 0x0004

If set, command interrupts are enabled.

◆ PXE_STATFLAGS_INTERRUPT_RECEIVE

#define PXE_STATFLAGS_INTERRUPT_RECEIVE 0x0001

UNDI Shutdown.

No additional StatFlags. UNDI Interrupt Enables.

If set, receive interrupts are enabled.

◆ PXE_STATFLAGS_INTERRUPT_TRANSMIT

#define PXE_STATFLAGS_INTERRUPT_TRANSMIT 0x0002

If set, transmit interrupts are enabled.

◆ PXE_STATFLAGS_RECEIVE_FILTER_ALL_MULTICAST

#define PXE_STATFLAGS_RECEIVE_FILTER_ALL_MULTICAST 0x0010

If set, all multicast packets will be received.

◆ PXE_STATFLAGS_RECEIVE_FILTER_BROADCAST

#define PXE_STATFLAGS_RECEIVE_FILTER_BROADCAST 0x0002

If set, broadcast packets will be received.

◆ PXE_STATFLAGS_RECEIVE_FILTER_FILTERED_MULTICAST

#define PXE_STATFLAGS_RECEIVE_FILTER_FILTERED_MULTICAST 0x0004

If set, multicast packets that match up with the multicast address filter list will be received.

◆ PXE_STATFLAGS_RECEIVE_FILTER_PROMISCUOUS

#define PXE_STATFLAGS_RECEIVE_FILTER_PROMISCUOUS 0x0008

If set, all packets will be received.

◆ PXE_STATFLAGS_RECEIVE_FILTER_UNICAST

#define PXE_STATFLAGS_RECEIVE_FILTER_UNICAST 0x0001

UNDI Receive Filters. If set, unicast packets will be received.

◆ PXE_STATFLAGS_RESET_NO_MEDIA

#define PXE_STATFLAGS_RESET_NO_MEDIA 0x0001

UNDI Reset.

◆ PXE_STATFLAGS_STATUS_MASK

#define PXE_STATFLAGS_STATUS_MASK 0xC000

Common StatFlags that can be returned by all commands.

The COMMAND_COMPLETE and COMMAND_FAILED status flags must be implemented by all UNDIs. COMMAND_QUEUED is only needed by UNDIs that support command queuing.

◆ PXE_STATISTICS_COLLISIONS

#define PXE_STATISTICS_COLLISIONS 0x14

Number of collisions detection on this subnet.

◆ PXE_STATISTICS_RX_BROADCAST_FRAMES

#define PXE_STATISTICS_RX_BROADCAST_FRAMES 0x06

Number of valid broadcast frames received and not dropped.

◆ PXE_STATISTICS_RX_CRC_ERROR_FRAMES

#define PXE_STATISTICS_RX_CRC_ERROR_FRAMES 0x08

Number of frames w/ CRC or alignment errors.

◆ PXE_STATISTICS_RX_DECRYPT_ERROR_FRAMES

#define PXE_STATISTICS_RX_DECRYPT_ERROR_FRAMES 0x17

Number of encrypted frames received that failed to decrypt.

◆ PXE_STATISTICS_RX_DROPPED_FRAMES

#define PXE_STATISTICS_RX_DROPPED_FRAMES 0x04

Valid frames that were dropped because receive buffers were full.

◆ PXE_STATISTICS_RX_DUPLICATED_FRAMES

#define PXE_STATISTICS_RX_DUPLICATED_FRAMES 0x16

Number of valid frames received that were duplicated.

◆ PXE_STATISTICS_RX_GOOD_FRAMES

#define PXE_STATISTICS_RX_GOOD_FRAMES 0x01

Number of valid frames received and copied into receive buffers.

◆ PXE_STATISTICS_RX_MULTICAST_FRAMES

#define PXE_STATISTICS_RX_MULTICAST_FRAMES 0x07

Number of valid mutlicast frames received and not dropped.

◆ PXE_STATISTICS_RX_OVERSIZE_FRAMES

#define PXE_STATISTICS_RX_OVERSIZE_FRAMES 0x03

Number of frames longer than the maxminum length for the media. This would be >1500 for ethernet.

◆ PXE_STATISTICS_RX_TOTAL_BYTES

#define PXE_STATISTICS_RX_TOTAL_BYTES 0x09

Total number of bytes received. Includes frames with errors and dropped frames.

◆ PXE_STATISTICS_RX_TOTAL_FRAMES

#define PXE_STATISTICS_RX_TOTAL_FRAMES 0x00

Total number of frames received. Includes frames with errors and dropped frames.

◆ PXE_STATISTICS_RX_UNDERSIZE_FRAMES

#define PXE_STATISTICS_RX_UNDERSIZE_FRAMES 0x02

Number of frames below the minimum length for the media. This would be <64 for ethernet.

◆ PXE_STATISTICS_RX_UNICAST_FRAMES

#define PXE_STATISTICS_RX_UNICAST_FRAMES 0x05

Number of valid unicast frames received and not dropped.

◆ PXE_STATISTICS_TX_BROADCAST_FRAMES

#define PXE_STATISTICS_TX_BROADCAST_FRAMES 0x10

◆ PXE_STATISTICS_TX_CRC_ERROR_FRAMES

#define PXE_STATISTICS_TX_CRC_ERROR_FRAMES 0x12

◆ PXE_STATISTICS_TX_DROPPED_FRAMES

#define PXE_STATISTICS_TX_DROPPED_FRAMES 0x0E

◆ PXE_STATISTICS_TX_ERROR_FRAMES

#define PXE_STATISTICS_TX_ERROR_FRAMES 0x18

Number of frames that failed to transmit after exceeding the retry limit.

◆ PXE_STATISTICS_TX_GOOD_FRAMES

#define PXE_STATISTICS_TX_GOOD_FRAMES 0x0B

◆ PXE_STATISTICS_TX_MULTICAST_FRAMES

#define PXE_STATISTICS_TX_MULTICAST_FRAMES 0x11

◆ PXE_STATISTICS_TX_OVERSIZE_FRAMES

#define PXE_STATISTICS_TX_OVERSIZE_FRAMES 0x0D

◆ PXE_STATISTICS_TX_RETRY_FRAMES

#define PXE_STATISTICS_TX_RETRY_FRAMES 0x19

Number of frames transmitted successfully after more than one attempt.

◆ PXE_STATISTICS_TX_TOTAL_BYTES

#define PXE_STATISTICS_TX_TOTAL_BYTES 0x13

◆ PXE_STATISTICS_TX_TOTAL_FRAMES

#define PXE_STATISTICS_TX_TOTAL_FRAMES 0x0A

Transmit statistics.

◆ PXE_STATISTICS_TX_UNDERSIZE_FRAMES

#define PXE_STATISTICS_TX_UNDERSIZE_FRAMES 0x0C

◆ PXE_STATISTICS_TX_UNICAST_FRAMES

#define PXE_STATISTICS_TX_UNICAST_FRAMES 0x0F

◆ PXE_STATISTICS_UNSUPPORTED_PROTOCOL

#define PXE_STATISTICS_UNSUPPORTED_PROTOCOL 0x15

Number of frames destined for unsupported protocol.

◆ PXE_SWAP_UINT16

#define PXE_SWAP_UINT16 ( n ) ((((PXE_UINT16) (n) & 0x00FF) << 8) | (((PXE_UINT16) (n) & 0xFF00) >> 8))

◆ PXE_SWAP_UINT32

#define PXE_SWAP_UINT32 ( n )

Value:

  ((((PXE_UINT32)(n) & 0x000000FF) << 24) | \
   (((PXE_UINT32)(n) & 0x0000FF00) << 8)  | \
   (((PXE_UINT32)(n) & 0x00FF0000) >> 8)  | \
   (((PXE_UINT32)(n) & 0xFF000000) >> 24))

◆ PXE_SWAP_UINT64

#define PXE_SWAP_UINT64 ( n )

Value:

  ((((PXE_UINT64)(n) & 0x00000000000000FFULL) << 56) | \
   (((PXE_UINT64)(n) & 0x000000000000FF00ULL) << 40) | \
   (((PXE_UINT64)(n) & 0x0000000000FF0000ULL) << 24) | \
   (((PXE_UINT64)(n) & 0x00000000FF000000ULL) << 8)  | \
   (((PXE_UINT64)(n) & 0x000000FF00000000ULL) >> 8)  | \
   (((PXE_UINT64)(n) & 0x0000FF0000000000ULL) >> 24) | \
   (((PXE_UINT64)(n) & 0x00FF000000000000ULL) >> 40) | \
   (((PXE_UINT64)(n) & 0xFF00000000000000ULL) >> 56))
