This graph shows which files directly or indirectly include this file:

Classes
struct	acpi_object_common

struct	acpi_object_integer

struct	acpi_object_string

struct	acpi_object_buffer

struct	acpi_object_package

struct	acpi_object_event

struct	acpi_object_mutex

struct	acpi_object_region

struct	acpi_object_method

struct	acpi_object_notify_common

struct	acpi_object_device

struct	acpi_object_power_resource

struct	acpi_object_processor

struct	acpi_object_thermal_zone

struct	acpi_object_field_common

struct	acpi_object_region_field

struct	acpi_object_bank_field

struct	acpi_object_index_field

struct	acpi_object_buffer_field

struct	acpi_object_notify_handler

struct	acpi_object_addr_handler

struct	acpi_object_reference

struct	acpi_object_extra

struct	acpi_object_data

struct	acpi_object_cache_list

union	acpi_operand_object

struct	acpi_common_descriptor

union	acpi_descriptor

Macros
#define	ACPI_OBJECT_COMMON_HEADER

#define	AOPOBJ_AML_CONSTANT 0x01 /* Integer is an AML constant */

#define	AOPOBJ_STATIC_POINTER 0x02 /* Data is part of an ACPI table, don't delete */

#define	AOPOBJ_DATA_VALID 0x04 /* Object is initialized and data is valid */

#define	AOPOBJ_OBJECT_INITIALIZED 0x08 /* Region is initialized */

#define	AOPOBJ_REG_CONNECTED 0x10 /* _REG was run */

#define	AOPOBJ_SETUP_COMPLETE 0x20 /* Region setup is complete */

#define	AOPOBJ_INVALID 0x40 /* Host OS won't allow a Region address */

#define	ACPI_COMMON_BUFFER_INFO(_Type)

#define	ACPI_METHOD_MODULE_LEVEL 0x01 /* Method is actually module-level code */

#define	ACPI_METHOD_INTERNAL_ONLY 0x02 /* Method is implemented internally (_OSI) */

#define	ACPI_METHOD_SERIALIZED 0x04 /* Method is serialized */

#define	ACPI_METHOD_SERIALIZED_PENDING 0x08 /* Method is to be marked serialized */

#define	ACPI_METHOD_IGNORE_SYNC_LEVEL 0x10 /* Method was auto-serialized at table load time */

#define	ACPI_METHOD_MODIFIED_NAMESPACE 0x20 /* Method modified the namespace */

#define	ACPI_COMMON_NOTIFY_INFO

#define	ACPI_COMMON_FIELD_INFO

#define	ACPI_ADDR_HANDLER_DEFAULT_INSTALLED 0x01

#define	ACPI_DESC_TYPE_CACHED 0x01 /* Used only when object is cached */

#define	ACPI_DESC_TYPE_STATE 0x02

#define	ACPI_DESC_TYPE_STATE_UPDATE 0x03

#define	ACPI_DESC_TYPE_STATE_PACKAGE 0x04

#define	ACPI_DESC_TYPE_STATE_CONTROL 0x05

#define	ACPI_DESC_TYPE_STATE_RPSCOPE 0x06

#define	ACPI_DESC_TYPE_STATE_PSCOPE 0x07

#define	ACPI_DESC_TYPE_STATE_WSCOPE 0x08

#define	ACPI_DESC_TYPE_STATE_RESULT 0x09

#define	ACPI_DESC_TYPE_STATE_NOTIFY 0x0A

#define	ACPI_DESC_TYPE_STATE_THREAD 0x0B

#define	ACPI_DESC_TYPE_WALK 0x0C

#define	ACPI_DESC_TYPE_PARSER 0x0D

#define	ACPI_DESC_TYPE_OPERAND 0x0E

#define	ACPI_DESC_TYPE_NAMED 0x0F

#define	ACPI_DESC_TYPE_MAX 0x0F

Typedefs
typedef struct acpi_object_common	ACPI_OBJECT_COMMON

typedef struct acpi_object_integer	ACPI_OBJECT_INTEGER

typedef struct acpi_object_string	ACPI_OBJECT_STRING

typedef struct acpi_object_buffer	ACPI_OBJECT_BUFFER

typedef struct acpi_object_package	ACPI_OBJECT_PACKAGE

typedef struct acpi_object_event	ACPI_OBJECT_EVENT

typedef struct acpi_object_mutex	ACPI_OBJECT_MUTEX

typedef struct acpi_object_region	ACPI_OBJECT_REGION

typedef struct acpi_object_method	ACPI_OBJECT_METHOD

typedef struct acpi_object_notify_common	ACPI_OBJECT_NOTIFY_COMMON

typedef struct acpi_object_device	ACPI_OBJECT_DEVICE

typedef struct acpi_object_power_resource	ACPI_OBJECT_POWER_RESOURCE

typedef struct acpi_object_processor	ACPI_OBJECT_PROCESSOR

typedef struct acpi_object_thermal_zone	ACPI_OBJECT_THERMAL_ZONE

typedef struct acpi_object_field_common	ACPI_OBJECT_FIELD_COMMON

typedef struct acpi_object_region_field	ACPI_OBJECT_REGION_FIELD

typedef struct acpi_object_bank_field	ACPI_OBJECT_BANK_FIELD

typedef struct acpi_object_index_field	ACPI_OBJECT_INDEX_FIELD

typedef struct acpi_object_buffer_field	ACPI_OBJECT_BUFFER_FIELD

typedef struct acpi_object_notify_handler	ACPI_OBJECT_NOTIFY_HANDLER

typedef struct acpi_object_addr_handler	ACPI_OBJECT_ADDR_HANDLER

typedef struct acpi_object_reference	ACPI_OBJECT_REFERENCE

typedef struct acpi_object_extra	ACPI_OBJECT_EXTRA

typedef struct acpi_object_data	ACPI_OBJECT_DATA

typedef struct acpi_object_cache_list	ACPI_OBJECT_CACHE_LIST

typedef union acpi_operand_object	ACPI_OPERAND_OBJECT

typedef struct acpi_common_descriptor	ACPI_COMMON_DESCRIPTOR

typedef union acpi_descriptor	ACPI_DESCRIPTOR

Enumerations
enum	ACPI_REFERENCE_CLASSES { ACPI_REFCLASS_LOCAL = 0 , ACPI_REFCLASS_ARG = 1 , ACPI_REFCLASS_REFOF = 2 , ACPI_REFCLASS_INDEX = 3 , ACPI_REFCLASS_TABLE = 4 , ACPI_REFCLASS_NAME = 5 , ACPI_REFCLASS_DEBUG = 6 , ACPI_REFCLASS_MAX = 6 }

Macro Definition Documentation

◆ ACPI_ADDR_HANDLER_DEFAULT_INSTALLED

#define ACPI_ADDR_HANDLER_DEFAULT_INSTALLED 0x01

◆ ACPI_COMMON_BUFFER_INFO

#define ACPI_COMMON_BUFFER_INFO ( _Type )

Value:

_Type *Pointer; \

UINT32 Length;

UINT32

unsigned int UINT32

Definition ProcessorBind.h:102

Length

ACPI_PHYSICAL_ADDRESS ACPI_SIZE Length

Definition acpixf.h:638

◆ ACPI_COMMON_FIELD_INFO

#define ACPI_COMMON_FIELD_INFO

Value:

    UINT8                           FieldFlags;         /* Access, update, and lock bits */\
    UINT8                           Attribute;          /* From AccessAs keyword */\
    UINT8                           AccessByteWidth;    /* Read/Write size in bytes */\
    ACPI_NAMESPACE_NODE             *Node;              /* Link back to parent node */\
    UINT32                          BitLength;          /* Length of field in bits */\
    UINT32                          BaseByteOffset;     /* Byte offset within containing object */\
    UINT32                          Value;              /* Value to store into the Bank or Index register */\
    UINT8                           StartFieldBitOffset;/* Bit offset within first field datum (0-63) */\
    UINT8                           AccessLength;       /* For serial regions/fields */

◆ ACPI_COMMON_NOTIFY_INFO

#define ACPI_COMMON_NOTIFY_INFO

Value:

union acpi_operand_object *NotifyList[2]; /* Handlers for system/device notifies */\

union acpi_operand_object *Handler; /* Handler for Address space */

Handler

ACPI_PHYSICAL_ADDRESS ACPI_SIZE BOOLEAN Warn BOOLEAN Physical UINT32 ACPI_TABLE_HEADER *OutTableHeader ACPI_TABLE_HEADER **OutTable ACPI_HANDLE UINT32 ACPI_WALK_CALLBACK ACPI_WALK_CALLBACK void void **ReturnValue UINT32 ACPI_BUFFER *RetPathPtr ACPI_OBJECT_HANDLER Handler

Definition acpixf.h:764

acpi_operand_object

Definition acobject.h:623

◆ ACPI_DESC_TYPE_CACHED

#define ACPI_DESC_TYPE_CACHED 0x01 /* Used only when object is cached */

◆ ACPI_DESC_TYPE_MAX

#define ACPI_DESC_TYPE_MAX 0x0F

◆ ACPI_DESC_TYPE_NAMED

#define ACPI_DESC_TYPE_NAMED 0x0F

◆ ACPI_DESC_TYPE_OPERAND

#define ACPI_DESC_TYPE_OPERAND 0x0E

◆ ACPI_DESC_TYPE_PARSER

#define ACPI_DESC_TYPE_PARSER 0x0D

◆ ACPI_DESC_TYPE_STATE

#define ACPI_DESC_TYPE_STATE 0x02

◆ ACPI_DESC_TYPE_STATE_CONTROL

#define ACPI_DESC_TYPE_STATE_CONTROL 0x05

◆ ACPI_DESC_TYPE_STATE_NOTIFY

#define ACPI_DESC_TYPE_STATE_NOTIFY 0x0A

◆ ACPI_DESC_TYPE_STATE_PACKAGE

#define ACPI_DESC_TYPE_STATE_PACKAGE 0x04

◆ ACPI_DESC_TYPE_STATE_PSCOPE

#define ACPI_DESC_TYPE_STATE_PSCOPE 0x07

◆ ACPI_DESC_TYPE_STATE_RESULT

#define ACPI_DESC_TYPE_STATE_RESULT 0x09

◆ ACPI_DESC_TYPE_STATE_RPSCOPE

#define ACPI_DESC_TYPE_STATE_RPSCOPE 0x06

◆ ACPI_DESC_TYPE_STATE_THREAD

#define ACPI_DESC_TYPE_STATE_THREAD 0x0B

◆ ACPI_DESC_TYPE_STATE_UPDATE

#define ACPI_DESC_TYPE_STATE_UPDATE 0x03

◆ ACPI_DESC_TYPE_STATE_WSCOPE

#define ACPI_DESC_TYPE_STATE_WSCOPE 0x08

◆ ACPI_DESC_TYPE_WALK

#define ACPI_DESC_TYPE_WALK 0x0C

◆ ACPI_METHOD_IGNORE_SYNC_LEVEL

#define ACPI_METHOD_IGNORE_SYNC_LEVEL 0x10 /* Method was auto-serialized at table load time */

◆ ACPI_METHOD_INTERNAL_ONLY

#define ACPI_METHOD_INTERNAL_ONLY 0x02 /* Method is implemented internally (_OSI) */

◆ ACPI_METHOD_MODIFIED_NAMESPACE

#define ACPI_METHOD_MODIFIED_NAMESPACE 0x20 /* Method modified the namespace */

◆ ACPI_METHOD_MODULE_LEVEL

#define ACPI_METHOD_MODULE_LEVEL 0x01 /* Method is actually module-level code */

◆ ACPI_METHOD_SERIALIZED

#define ACPI_METHOD_SERIALIZED 0x04 /* Method is serialized */

◆ ACPI_METHOD_SERIALIZED_PENDING

#define ACPI_METHOD_SERIALIZED_PENDING 0x08 /* Method is to be marked serialized */

◆ ACPI_OBJECT_COMMON_HEADER

#define ACPI_OBJECT_COMMON_HEADER

Value:

    union acpi_operand_object       *NextObject;        /* Objects linked to parent NS node */\
    UINT8                           DescriptorType;     /* To differentiate various internal objs */\
    UINT8                           Type;               /* ACPI_OBJECT_TYPE */\
    UINT16                          ReferenceCount;     /* For object deletion management */\
    UINT8                           Flags;
