chitralekha.h File Reference

#include <stdint.h>
#include <_xeneva.h>

Include dependency graph for chitralekha.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes
struct	_ChCanvas_

Typedefs
typedef struct _ChCanvas_	ChCanvas

Functions
XE_LIB int	ChPrintLibName ()
XE_LIB ChCanvas *	ChCreateCanvas (int reqW, int reqH)
	ChCreateCanvas – creates a new canvas.
XE_LIB int	ChAllocateBuffer (ChCanvas *canvas)
	ChAllocateBuffer – allocates buffers for graphics.
XE_LIB int	ChDeAllocateBuffer (ChCanvas *canvas)
	ChDeAllocateBuffer – de-allocates buffers from canvas.
XE_LIB void	ChCanvasScreenUpdate (ChCanvas *canvas, int x, int y, int w, int h)
	ChCanvasScreenUpdate – updates screen buffer with canvas buffer contents.
XE_LIB void	ChDrawPixel (ChCanvas *canvas, int x, int y, uint32_t color)
	ChDrawPixel – draws a pixel to canvas buffer.
XE_LIB void	ChDrawPixelRAW (ChCanvas *canvas, int x, int y, uint32_t color)
	ChDrawPixelRAW – draws a pixel to canvas buffer.
XE_LIB void	ChDrawPixelAA (ChCanvas *canv, int x, int y, uint32_t color, double alpha)
	ChDrawPixelAA – draw anti-aliased pixel.
XE_LIB uint32_t	ChGetPixel (ChCanvas *canvas, int x, int y)
	ChGetPixel – retuns a pixel from canvas.
XE_LIB void	ChCanvasFill (ChCanvas *canvas, int w, int h, uint32_t color)
	ChCanvasFill – fill the canvas with specific color.
XE_LIB float	ChGetScreenDiagonal (ChCanvas *canv)
	ChGetScreenDiagonal – get screen diagonal using pythagorean theorem in centimetre.
XE_LIB float	ChGetScreenDPI (ChCanvas *canv)
	ChGetScreenDPI – converts screen resolution into dot-per-inch in centimetre.
XE_LIB int	ChGetScreenAspectRatio (ChCanvas *canv)
	ChGetScreenAspectRatio – returns the aspect ration of the screen.

Typedef Documentation

ChCanvas

typedef struct _ChCanvas_ ChCanvas

BSD 2-Clause License

Copyright (c) 2022-2023, Manas Kamal Choudhury All rights reserved.

Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met:

1. Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
2. Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution.

THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS "AS IS" AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT HOLDER OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

Function Documentation

ChAllocateBuffer()

XE_LIB int ChAllocateBuffer

(

ChCanvas *

canvas

)

ChAllocateBuffer – allocates buffers for graphics.

Parameters

canvas

– Pointer to canvas

ChCanvasFill()

XE_LIB void ChCanvasFill	(	ChCanvas *	canvas,
		int	w,
		int	h,
		uint32_t	color
	)

ChCanvasFill – fill the canvas with specific color.

Parameters

canvas	– pointer to canvas structure
w	– width to fill
h	– height to fill
color	– color to be filled with

ChCanvasScreenUpdate()

XE_LIB void ChCanvasScreenUpdate	(	ChCanvas *	canvas,
		int	_x,
		int	_y,
		int	_w,
		int	_h
	)

ChCanvasScreenUpdate – updates screen buffer with canvas buffer contents.

Parameters

canvas	– Pointer to canvas
x	– x position
y	– y position
w	– width of the canvas
h	– height of the canvas

ChCreateCanvas()

XE_LIB ChCanvas * ChCreateCanvas	(	int	reqW,
		int	reqH
	)

ChCreateCanvas – creates a new canvas.

Parameters

reqW	– requested width of the canvas
reqH	– requested height of the canvas

ChDeAllocateBuffer()

XE_LIB int ChDeAllocateBuffer

(

ChCanvas *

canvas

)

ChDeAllocateBuffer – de-allocates buffers from canvas.

Parameters

canvas

– pointer to canvas structure

ChDrawPixel()

XE_LIB void ChDrawPixel	(	ChCanvas *	canvas,
		int	x,
		int	y,
		uint32_t	color
	)

ChDrawPixel – draws a pixel to canvas buffer.

Parameters

canvas	– pointer to canvas
x	– x position
y	– y position
color	– color of the pixel

ChDrawPixelAA()

XE_LIB void ChDrawPixelAA	(	ChCanvas *	canv,
		int	x,
		int	y,
		uint32_t	color,
		double	alpha
	)

ChDrawPixelAA – draw anti-aliased pixel.

Parameters

canv	- Pointer to canvas
x	– X location relative to window
y	– Y location relative to window
color	– Color of the pixel
alpha	– Alpha value

ChDrawPixelRAW()

XE_LIB void ChDrawPixelRAW	(	ChCanvas *	canvas,
		int	x,
		int	y,
		uint32_t	color
	)

ChDrawPixelRAW – draws a pixel to canvas buffer.

Parameters

canvas	– pointer to canvas
x	– x position
y	– y position
color	– color of the pixel

ChGetPixel()

XE_LIB uint32_t ChGetPixel	(	ChCanvas *	canvas,
		int	x,
		int	y
	)

ChGetPixel – retuns a pixel from canvas.

Parameters

canvas	– Pointer to canvas structure
x	– x position
y	– y position

ChGetScreenAspectRatio()

XE_LIB int ChGetScreenAspectRatio

(

ChCanvas *

canv

)

ChGetScreenAspectRatio – returns the aspect ration of the screen.

Parameters

canv	– Pointer to canvas

ChGetScreenDiagonal()

XE_LIB float ChGetScreenDiagonal

(

ChCanvas *

canv

)

ChGetScreenDiagonal – get screen diagonal using pythagorean theorem in centimetre.

Parameters

canv	– Pointer to canvas

ChGetScreenDPI()

XE_LIB float ChGetScreenDPI

(

ChCanvas *

canv

)

ChGetScreenDPI – converts screen resolution into dot-per-inch in centimetre.

Parameters

canv	– Pointer to canvas

ChPrintLibName()

XE_LIB int ChPrintLibName

(

)
