#include "uspi/smsc951x.h"
#include "uspios.h"
#include "uspi/usbhostcontroller.h"
#include "uspi/devicenameservice.h"
#include "uspi/util.h"
#include "uspi/assert.h"

Include dependency graph for smsc951x.c:

Macros
#define	WRITE_REGISTER 0xA0

#define	READ_REGISTER 0xA1

#define	ID_REV 0x00

#define	INT_STS 0x08

#define	RX_CFG 0x0C

#define	TX_CFG 0x10

#define	TX_CFG_ON 0x00000004

#define	HW_CFG 0x14

#define	HW_CFG_BIR 0x00001000

#define	RX_FIFO_INF 0x18

#define	PM_CTRL 0x20

#define	LED_GPIO_CFG 0x24

#define	LED_GPIO_CFG_SPD_LED 0x01000000

#define	LED_GPIO_CFG_LNK_LED 0x00100000

#define	LED_GPIO_CFG_FDX_LED 0x00010000

#define	GPIO_CFG 0x28

#define	AFC_CFG 0x2C

#define	E2P_CMD 0x30

#define	E2P_DATA 0x34

#define	BURST_CAP 0x38

#define	GPIO_WAKE 0x64

#define	INT_EP_CTL 0x68

#define	BULK_IN_DLY 0x6C

#define	MAC_CR 0x100

#define	MAC_CR_RCVOWN 0x00800000

#define	MAC_CR_MCPAS 0x00080000

#define	MAC_CR_PRMS 0x00040000

#define	MAC_CR_BCAST 0x00000800

#define	MAC_CR_TXEN 0x00000008

#define	MAC_CR_RXEN 0x00000004

#define	ADDRH 0x104

#define	ADDRL 0x108

#define	HASHH 0x10C

#define	HASHL 0x110

#define	MII_ADDR 0x114

#define	MII_BUSY 0x01

#define	MII_WRITE 0x02

#define	PHY_ID_MASK 0x1F

#define	PHY_ID_INTERNAL 0x01

#define	REG_NUM_MASK 0x1F

#define	MII_DATA 0x118

#define	FLOW 0x11C

#define	VLAN1 0x120

#define	VLAN2 0x124

#define	WUFF 0x128

#define	WUCSR 0x12C

#define	COE_CR 0x130

#define	TX_CMD_A_DATA_OFFSET 0x001F0000

#define	TX_CMD_A_FIRST_SEG 0x00002000

#define	TX_CMD_A_LAST_SEG 0x00001000

#define	TX_CMD_A_BUF_SIZE 0x000007FF

#define	TX_CMD_B_CSUM_ENABLE 0x00004000

#define	TX_CMD_B_ADD_CRC_DISABLE 0x00002000

#define	TX_CMD_B_DISABLE_PADDING 0x00001000

#define	TX_CMD_B_PKT_BYTE_LENGTH 0x000007FF

#define	RX_STS_FF 0x40000000

#define	RX_STS_FL 0x3FFF0000

#define	RX_STS_FRAMELEN(reg) (((reg) & RX_STS_FL) >> 16)

#define	RX_STS_ES 0x00008000

#define	RX_STS_BF 0x00002000

#define	RX_STS_LE 0x00001000

#define	RX_STS_RF 0x00000800

#define	RX_STS_MF 0x00000400

#define	RX_STS_TL 0x00000080

#define	RX_STS_CS 0x00000040

#define	RX_STS_FT 0x00000020

#define	RX_STS_RW 0x00000010

#define	RX_STS_ME 0x00000008

#define	RX_STS_DB 0x00000004

#define	RX_STS_CRC 0x00000002

#define	RX_STS_ERROR

Functions
boolean	SMSC951xDeviceWriteReg (TSMSC951xDevice *pThis, u32 nIndex, u32 nValue)

boolean	SMSC951xDeviceReadReg (TSMSC951xDevice pThis, u32 nIndex, u32 pValue)

void	SMSC951xDeviceDumpReg (TSMSC951xDevice pThis, const char pName, u32 nIndex)

void	SMSC951xDeviceDumpRegs (TSMSC951xDevice *pThis)

void	SMSC951xDevice (TSMSC951xDevice pThis, TUSBFunction pDevice)

void	_SMSC951xDevice (TSMSC951xDevice *pThis)

boolean	SMSC951xDeviceConfigure (TUSBFunction *pUSBFunction)

TMACAddress *	SMSC951xDeviceGetMACAddress (TSMSC951xDevice *pThis)

boolean	SMSC951xDeviceSendFrame (TSMSC951xDevice pThis, const void pBuffer, unsigned nLength)

boolean	SMSC951xDeviceReceiveFrame (TSMSC951xDevice pThis, void pBuffer, unsigned *pResultLength)

boolean	SMSC951xDeviceIsLinkUp (TSMSC951xDevice *pThis)

boolean	SMSC951xDevicePHYWrite (TSMSC951xDevice *pThis, u8 uchIndex, u16 usValue)

boolean	SMSC951xDevicePHYRead (TSMSC951xDevice pThis, u8 uchIndex, u16 pValue)

boolean	SMSC951xDevicePHYWaitNotBusy (TSMSC951xDevice *pThis)

Macro Definition Documentation

◆ ADDRH

#define ADDRH 0x104

◆ ADDRL

#define ADDRL 0x108

◆ AFC_CFG

#define AFC_CFG 0x2C

◆ BULK_IN_DLY

#define BULK_IN_DLY 0x6C

◆ BURST_CAP

#define BURST_CAP 0x38

◆ COE_CR

#define COE_CR 0x130

◆ E2P_CMD

#define E2P_CMD 0x30

◆ E2P_DATA

#define E2P_DATA 0x34

◆ FLOW

#define FLOW 0x11C

◆ GPIO_CFG

#define GPIO_CFG 0x28

◆ GPIO_WAKE

#define GPIO_WAKE 0x64

◆ HASHH

#define HASHH 0x10C

◆ HASHL

#define HASHL 0x110

◆ HW_CFG

#define HW_CFG 0x14

◆ HW_CFG_BIR

#define HW_CFG_BIR 0x00001000

◆ ID_REV

#define ID_REV 0x00

◆ INT_EP_CTL

#define INT_EP_CTL 0x68

◆ INT_STS

#define INT_STS 0x08

◆ LED_GPIO_CFG

#define LED_GPIO_CFG 0x24

◆ LED_GPIO_CFG_FDX_LED

#define LED_GPIO_CFG_FDX_LED 0x00010000

◆ LED_GPIO_CFG_LNK_LED

#define LED_GPIO_CFG_LNK_LED 0x00100000

◆ LED_GPIO_CFG_SPD_LED

#define LED_GPIO_CFG_SPD_LED 0x01000000

◆ MAC_CR

#define MAC_CR 0x100

◆ MAC_CR_BCAST

#define MAC_CR_BCAST 0x00000800

◆ MAC_CR_MCPAS

#define MAC_CR_MCPAS 0x00080000

◆ MAC_CR_PRMS

#define MAC_CR_PRMS 0x00040000

◆ MAC_CR_RCVOWN

#define MAC_CR_RCVOWN 0x00800000

◆ MAC_CR_RXEN

#define MAC_CR_RXEN 0x00000004

◆ MAC_CR_TXEN

#define MAC_CR_TXEN 0x00000008

◆ MII_ADDR

#define MII_ADDR 0x114

◆ MII_BUSY

#define MII_BUSY 0x01

◆ MII_DATA

#define MII_DATA 0x118

◆ MII_WRITE

#define MII_WRITE 0x02

◆ PHY_ID_INTERNAL

#define PHY_ID_INTERNAL 0x01

◆ PHY_ID_MASK

#define PHY_ID_MASK 0x1F

◆ PM_CTRL

#define PM_CTRL 0x20

◆ READ_REGISTER

#define READ_REGISTER 0xA1

◆ REG_NUM_MASK

#define REG_NUM_MASK 0x1F

◆ RX_CFG

#define RX_CFG 0x0C

◆ RX_FIFO_INF

#define RX_FIFO_INF 0x18

◆ RX_STS_BF

#define RX_STS_BF 0x00002000

◆ RX_STS_CRC

#define RX_STS_CRC 0x00000002

◆ RX_STS_CS

#define RX_STS_CS 0x00000040

◆ RX_STS_DB

#define RX_STS_DB 0x00000004

◆ RX_STS_ERROR

#define RX_STS_ERROR

Value:

                     (  RX_STS_FF   \
                     | RX_STS_ES    \
                     | RX_STS_LE    \
                     | RX_STS_TL    \
                     | RX_STS_CS    \
                     | RX_STS_RW    \
                     | RX_STS_ME    \
                     | RX_STS_DB    \
                     | RX_STS_CRC)

◆ RX_STS_ES

#define RX_STS_ES 0x00008000

◆ RX_STS_FF

#define RX_STS_FF 0x40000000

◆ RX_STS_FL

#define RX_STS_FL 0x3FFF0000

◆ RX_STS_FRAMELEN

#define RX_STS_FRAMELEN ( reg ) (((reg) & RX_STS_FL) >> 16)

◆ RX_STS_FT

#define RX_STS_FT 0x00000020

◆ RX_STS_LE

#define RX_STS_LE 0x00001000

◆ RX_STS_ME

#define RX_STS_ME 0x00000008

◆ RX_STS_MF

#define RX_STS_MF 0x00000400

◆ RX_STS_RF

#define RX_STS_RF 0x00000800

◆ RX_STS_RW

#define RX_STS_RW 0x00000010

◆ RX_STS_TL

#define RX_STS_TL 0x00000080

◆ TX_CFG

#define TX_CFG 0x10

◆ TX_CFG_ON

#define TX_CFG_ON 0x00000004

◆ TX_CMD_A_BUF_SIZE

#define TX_CMD_A_BUF_SIZE 0x000007FF

◆ TX_CMD_A_DATA_OFFSET

#define TX_CMD_A_DATA_OFFSET 0x001F0000

◆ TX_CMD_A_FIRST_SEG

#define TX_CMD_A_FIRST_SEG 0x00002000

◆ TX_CMD_A_LAST_SEG

#define TX_CMD_A_LAST_SEG 0x00001000

◆ TX_CMD_B_ADD_CRC_DISABLE

#define TX_CMD_B_ADD_CRC_DISABLE 0x00002000

◆ TX_CMD_B_CSUM_ENABLE

#define TX_CMD_B_CSUM_ENABLE 0x00004000

◆ TX_CMD_B_DISABLE_PADDING

#define TX_CMD_B_DISABLE_PADDING 0x00001000

◆ TX_CMD_B_PKT_BYTE_LENGTH

#define TX_CMD_B_PKT_BYTE_LENGTH 0x000007FF

◆ VLAN1

#define VLAN1 0x120

◆ VLAN2

#define VLAN2 0x124

◆ WRITE_REGISTER

#define WRITE_REGISTER 0xA0

◆ WUCSR

#define WUCSR 0x12C

◆ WUFF

#define WUFF 0x128

Function Documentation

◆ _SMSC951xDevice()

void _SMSC951xDevice ( TSMSC951xDevice * pThis )

◆ SMSC951xDevice()

void SMSC951xDevice	(	TSMSC951xDevice *	pThis,
		TUSBFunction *	pDevice
	)

◆ SMSC951xDeviceConfigure()

boolean SMSC951xDeviceConfigure ( TUSBFunction * pUSBFunction )

◆ SMSC951xDeviceDumpReg()

void SMSC951xDeviceDumpReg	(	TSMSC951xDevice *	pThis,
		const char *	pName,
		u32	nIndex
	)

◆ SMSC951xDeviceDumpRegs()

void SMSC951xDeviceDumpRegs ( TSMSC951xDevice * pThis )

◆ SMSC951xDeviceGetMACAddress()

TMACAddress * SMSC951xDeviceGetMACAddress ( TSMSC951xDevice * pThis )

◆ SMSC951xDeviceIsLinkUp()

boolean SMSC951xDeviceIsLinkUp ( TSMSC951xDevice * pThis )

◆ SMSC951xDevicePHYRead()

boolean SMSC951xDevicePHYRead	(	TSMSC951xDevice *	pThis,
		u8	uchIndex,
		u16 *	pValue
	)

◆ SMSC951xDevicePHYWaitNotBusy()

boolean SMSC951xDevicePHYWaitNotBusy ( TSMSC951xDevice * pThis )

◆ SMSC951xDevicePHYWrite()

boolean SMSC951xDevicePHYWrite	(	TSMSC951xDevice *	pThis,
		u8	uchIndex,
		u16	usValue
	)

◆ SMSC951xDeviceReadReg()

boolean SMSC951xDeviceReadReg	(	TSMSC951xDevice *	pThis,
		u32	nIndex,
		u32 *	pValue
	)

◆ SMSC951xDeviceReceiveFrame()

boolean SMSC951xDeviceReceiveFrame	(	TSMSC951xDevice *	pThis,
		void *	pBuffer,
		unsigned *	pResultLength
	)

◆ SMSC951xDeviceSendFrame()

boolean SMSC951xDeviceSendFrame	(	TSMSC951xDevice *	pThis,
		const void *	pBuffer,
		unsigned	nLength
	)

◆ SMSC951xDeviceWriteReg()

boolean SMSC951xDeviceWriteReg	(	TSMSC951xDevice *	pThis,
		u32	nIndex,
		u32	nValue
	)
