#include <WiFi.h>
Detailed Description
Member Data Documentation
◆ AssociationID
| UINT16 EFI_80211_ASSOCIATE_RESULT::AssociationID |
Specifies the association ID value assigned by the AP.
◆ BSSId
| EFI_80211_MAC_ADDRESS EFI_80211_ASSOCIATE_RESULT::BSSId |
Specifies the address of the peer MAC entity from which the association request was received.
◆ CapabilityInfo
| UINT16 EFI_80211_ASSOCIATE_RESULT::CapabilityInfo |
Specifies the operational capabilities advertised by the AP.
◆ ExtCapElement
| EFI_80211_ELEMENT_EXT_CAP* EFI_80211_ASSOCIATE_RESULT::ExtCapElement |
Specifies the parameters within the Extended Capabilities element that are supported by the MAC entity. This is an optional parameter and may be NULL.
◆ RCPIValue
| UINT8 EFI_80211_ASSOCIATE_RESULT::RCPIValue |
Indicates the measured RCPI of the corresponding association request frame. It is an optional parameter and is set to zero if unavailable.
◆ RSNIValue
| UINT8 EFI_80211_ASSOCIATE_RESULT::RSNIValue |
Indicates the measured RSNI at the time the corresponding association request frame was received. It is an optional parameter and is set to zero if unavailable.
◆ TimeoutInterval
| EFI_80211_ELEMENT_TIMEOUT_VAL EFI_80211_ASSOCIATE_RESULT::TimeoutInterval |
Specifies the timeout interval when the result code is AssociateRefusedTemporarily.
◆ VendorSpecificInfo
| UINT8* EFI_80211_ASSOCIATE_RESULT::VendorSpecificInfo |
Specifies zero or more elements. This is an optional parameter and may be NULL.
The documentation for this struct was generated from the following file:
- XenevaOS/Boot/include/Protocol/WiFi.h
