#include <WiFi.h>
Detailed Description
Member Data Documentation
◆ BeaconPeriod
| UINT16 EFI_80211_BSS_DESCRIPTION::BeaconPeriod |
The beacon period in TU of the found BSS.
◆ BSSBasicRateSet
| UINT8* EFI_80211_BSS_DESCRIPTION::BSSBasicRateSet |
The set of data rates that shall be supported by all STAs that desire to join this BSS.
◆ BSSId
| EFI_80211_MAC_ADDRESS EFI_80211_BSS_DESCRIPTION::BSSId |
Indicates a specific BSSID of the found BSS.
◆ BSSMembershipSelectorSet
| UINT8* EFI_80211_BSS_DESCRIPTION::BSSMembershipSelectorSet |
Specifies the BSS membership selectors that represent the set of features that shall be supported by all STAs to join this BSS.
◆ BSSType
| EFI_80211_BSS_TYPE EFI_80211_BSS_DESCRIPTION::BSSType |
Specifies the type of the found BSS.
◆ CapabilityInfo
| UINT16 EFI_80211_BSS_DESCRIPTION::CapabilityInfo |
The advertised capabilities of the BSS.
◆ Country
| EFI_80211_ELEMENT_COUNTRY* EFI_80211_BSS_DESCRIPTION::Country |
The information required to identify the regulatory domain in which the peer STA is located.
◆ ExtCapElement
| EFI_80211_ELEMENT_EXT_CAP* EFI_80211_BSS_DESCRIPTION::ExtCapElement |
Specifies the parameters within the Extended Capabilities element that are supported by the MAC entity. This is an optional parameter and may be NULL.
◆ OperationalRateSet
| UINT8* EFI_80211_BSS_DESCRIPTION::OperationalRateSet |
The set of data rates that the peer STA desires to use for communication within the BSS.
◆ RCPIMeasurement
| UINT8 EFI_80211_BSS_DESCRIPTION::RCPIMeasurement |
Specifies the RCPI of the received frame.
◆ RequestedElements
| UINT8* EFI_80211_BSS_DESCRIPTION::RequestedElements |
Specifies the elements requested by the request element of the Probe Request frame. This is an optional parameter and may be NULL.
◆ RSN
| EFI_80211_ELEMENT_RSN EFI_80211_BSS_DESCRIPTION::RSN |
The cipher suites and AKM suites supported in the BSS.
◆ RSNIMeasurement
| UINT8 EFI_80211_BSS_DESCRIPTION::RSNIMeasurement |
Specifies the RSNI of the received frame.
◆ RSSI
| UINT8 EFI_80211_BSS_DESCRIPTION::RSSI |
Specifies the RSSI of the received frame.
◆ SSId
| UINT8* EFI_80211_BSS_DESCRIPTION::SSId |
Specifies the SSID of the found BSS. If NULL, ignore SSIdLen field.
◆ SSIdLen
| UINT8 EFI_80211_BSS_DESCRIPTION::SSIdLen |
Specifies the SSID of the found BSS. If NULL, ignore SSIdLen field.
◆ Timestamp
| UINT64 EFI_80211_BSS_DESCRIPTION::Timestamp |
The timestamp of the received frame from the found BSS.
The documentation for this struct was generated from the following file:
- XenevaOS/Boot/include/Protocol/WiFi.h
