#include <WiFi.h>
Detailed Description
Member Data Documentation
◆ AccessNetworkType
| EFI_80211_ACC_NET_TYPE EFI_80211_SCAN_DATA::AccessNetworkType |
Specifies a desired specific access network type or the wildcard access network type. Use 15 as wildcard access network type.
◆ BSSId
| EFI_80211_MAC_ADDRESS EFI_80211_SCAN_DATA::BSSId |
Indicates a specific or wildcard BSSID. Use all binary 1s to represent all SSIDs.
◆ BSSType
| EFI_80211_BSS_TYPE EFI_80211_SCAN_DATA::BSSType |
Determines whether infrastructure BSS, IBSS, MBSS, or all, are included in the scan.
◆ ChannelList
| UINT32* EFI_80211_SCAN_DATA::ChannelList |
Specifies a list of channels that are examined when scanning for a BSS. If set to NULL, all valid channels will be scanned.
◆ MaxChannelTime
| UINT32 EFI_80211_SCAN_DATA::MaxChannelTime |
Indicates the maximum time in TU to spend on each channel when scanning. If zero, the value can be overridden by an implementation-dependent default value.
◆ MinChannelTime
| UINT32 EFI_80211_SCAN_DATA::MinChannelTime |
Indicates the minimum time in TU to spend on each channel when scanning. If zero, the value can be overridden by an implementation-dependent default value.
◆ PassiveMode
| BOOLEAN EFI_80211_SCAN_DATA::PassiveMode |
Indicates passive scanning if TRUE.
◆ ProbeDelay
| UINT32 EFI_80211_SCAN_DATA::ProbeDelay |
The delay in microseconds to be used prior to transmitting a Probe frame during active scanning. If zero, the value can be overridden by an implementation-dependent default value.
◆ RequestInformation
| EFI_80211_ELEMENT_REQ* EFI_80211_SCAN_DATA::RequestInformation |
Points to an optionally present element. This is an optional parameter and may be NULL.
◆ SSId
| UINT8* EFI_80211_SCAN_DATA::SSId |
Specifies the desired SSID or the wildcard SSID. Use NULL to represent all SSIDs.
◆ SSIdLen
| UINT8 EFI_80211_SCAN_DATA::SSIdLen |
Length in bytes of the SSId. If zero, ignore SSId field.
◆ SSIDList
| EFI_80211_ELEMENT_SSID* EFI_80211_SCAN_DATA::SSIDList |
Indicates one or more SSID elements that are optionally present. This is an optional parameter and may be NULL.
◆ VendorSpecificInfo
| UINT8* EFI_80211_SCAN_DATA::VendorSpecificInfo |
Specifies zero or more elements. This is an optional parameter and may be NULL.
The documentation for this struct was generated from the following file:
- XenevaOS/Boot/include/Protocol/WiFi.h
