Detailed Description

Definition for Service Processor Management Interface Description Table

Member Data Documentation

◆ BaseAddress

EFI_ACPI_2_0_GENERIC_ADDRESS_STRUCTURE EFI_ACPI_SERVICE_PROCESSOR_MANAGEMENT_INTERFACE_TABLE::BaseAddress

The base address of the interface register set described using the Generic Address Structure (GAS, See [ACPI 2.0] for the definition).

◆ DeviceId

EFI_ACPI_SERVICE_PROCESSOR_MANAGEMENT_INTERFACE_TABLE_DEVICE_ID EFI_ACPI_SERVICE_PROCESSOR_MANAGEMENT_INTERFACE_TABLE::DeviceId

Device identification information.

◆ GlobalSystemInterrupt

UINT32 EFI_ACPI_SERVICE_PROCESSOR_MANAGEMENT_INTERFACE_TABLE::GlobalSystemInterrupt

The I/O APIC or I/O SAPIC Global System Interrupt used by the interface.

◆ Gpe

UINT8 EFI_ACPI_SERVICE_PROCESSOR_MANAGEMENT_INTERFACE_TABLE::Gpe

The bit assignment of the SCI interrupt within the GPEx_STS register of a GPE described if the FADT that the interface triggers.

◆ Header

EFI_ACPI_DESCRIPTION_HEADER EFI_ACPI_SERVICE_PROCESSOR_MANAGEMENT_INTERFACE_TABLE::Header

◆ InterfaceType

UINT8 EFI_ACPI_SERVICE_PROCESSOR_MANAGEMENT_INTERFACE_TABLE::InterfaceType

Indicates the type of IPMI interface.

◆ InterruptType

UINT8 EFI_ACPI_SERVICE_PROCESSOR_MANAGEMENT_INTERFACE_TABLE::InterruptType

Interrupt type(s) used by the interface.

◆ PciDeviceFlag

UINT8 EFI_ACPI_SERVICE_PROCESSOR_MANAGEMENT_INTERFACE_TABLE::PciDeviceFlag

PCI Device Flag.

◆ Reserved1

UINT8 EFI_ACPI_SERVICE_PROCESSOR_MANAGEMENT_INTERFACE_TABLE::Reserved1

This field must always be 01h to be compatible with any software that implements previous versions of this spec.

◆ Reserved2

UINT8 EFI_ACPI_SERVICE_PROCESSOR_MANAGEMENT_INTERFACE_TABLE::Reserved2

Reserved, must be 00h.

◆ Reserved3

UINT8 EFI_ACPI_SERVICE_PROCESSOR_MANAGEMENT_INTERFACE_TABLE::Reserved3

This field must always be null (0x00) to be compatible with any software that implements previous versions of this spec.

◆ SpecificationRevision

UINT16 EFI_ACPI_SERVICE_PROCESSOR_MANAGEMENT_INTERFACE_TABLE::SpecificationRevision

Identifies the IPMI specification revision, in BCD format.

The documentation for this struct was generated from the following file:

XenevaOS/Boot/include/IndustryStandard/ServiceProcessorManagementInterfaceTable.h

Public Attributes
EFI_ACPI_DESCRIPTION_HEADER	Header

UINT8	InterfaceType

UINT8	Reserved1

UINT16	SpecificationRevision

UINT8	InterruptType

UINT8	Gpe

UINT8	Reserved2

UINT8	PciDeviceFlag

UINT32	GlobalSystemInterrupt

EFI_ACPI_2_0_GENERIC_ADDRESS_STRUCTURE	BaseAddress

EFI_ACPI_SERVICE_PROCESSOR_MANAGEMENT_INTERFACE_TABLE_DEVICE_ID	DeviceId

UINT8	Reserved3
