#include <Dhcp4.h>
Member Data Documentation
◆ CallbackContext
| VOID* EFI_DHCP4_CONFIG_DATA::CallbackContext |
The pointer to the context that will be passed to Dhcp4Callback when it is called.
◆ ClientAddress
| EFI_IPv4_ADDRESS EFI_DHCP4_CONFIG_DATA::ClientAddress |
For a DHCPDISCOVER, setting this parameter to the previously allocated IP address will cause the EFI DHCPv4 Protocol driver to enter the Dhcp4InitReboot state. And set this field to 0.0.0.0 to enter the Dhcp4Init state. For a DHCPINFORM this parameter should be set to the client network address which was assigned to the client during a DHCPDISCOVER.
◆ Dhcp4Callback
| EFI_DHCP4_CALLBACK EFI_DHCP4_CONFIG_DATA::Dhcp4Callback |
The callback function to intercept various events that occurred in the DHCP configuration process. Set to NULL to ignore all those events.
◆ DiscoverTimeout
| UINT32* EFI_DHCP4_CONFIG_DATA::DiscoverTimeout |
The maximum amount of time (in seconds) to wait for returned packets in each of the retries. Timeout values of zero will default to a timeout value of one second. Set to NULL to use default timeout values.
◆ DiscoverTryCount
| UINT32 EFI_DHCP4_CONFIG_DATA::DiscoverTryCount |
The number of times to try sending a packet during the Dhcp4SendDiscover event and waiting for a response during the Dhcp4RcvdOffer event. Set to zero to use the default try counts and timeout values.
◆ OptionCount
| UINT32 EFI_DHCP4_CONFIG_DATA::OptionCount |
Number of DHCP options in the OptionList.
◆ OptionList
| EFI_DHCP4_PACKET_OPTION** EFI_DHCP4_CONFIG_DATA::OptionList |
List of DHCP options to be included in every packet that is sent during the Dhcp4SendDiscover event. Pad options are appended automatically by DHCP driver in outgoing DHCP packets. If OptionList itself contains pad option, they are ignored by the driver. OptionList can be freed after EFI_DHCP4_PROTOCOL.Configure() returns. Ignored if OptionCount is zero.
◆ RequestTimeout
| UINT32* EFI_DHCP4_CONFIG_DATA::RequestTimeout |
The maximum amount of time (in seconds) to wait for return packets in each of the retries. Timeout values of zero will default to a timeout value of one second. Set to NULL to use default timeout values.
◆ RequestTryCount
| UINT32 EFI_DHCP4_CONFIG_DATA::RequestTryCount |
The number of times to try sending a packet during the Dhcp4SendRequest event and waiting for a response during the Dhcp4RcvdAck event before accepting failure. Set to zero to use the default try counts and timeout values.
The documentation for this struct was generated from the following file:
- XenevaOS/Boot/include/Protocol/Dhcp4.h
