#include <Dns6.h>
Public Attributes | ||
| EFI_EVENT | Event | |
| EFI_STATUS | Status | |
| UINT32 | RetryCount | |
| UINT32 | RetryInterval | |
| union { | ||
| DNS6_HOST_TO_ADDR_DATA * H2AData | ||
| DNS6_ADDR_TO_HOST_DATA * A2HData | ||
| DNS6_GENERAL_LOOKUP_DATA * GLookupData | ||
| } | RspData | |
Detailed Description
Member Data Documentation
◆ A2HData
| DNS6_ADDR_TO_HOST_DATA* EFI_DNS6_COMPLETION_TOKEN::A2HData |
When the Token is used for host address to host name translation, A2HData is a pointer to the DNS6_ADDR_TO_HOST_DATA.
◆ Event
| EFI_EVENT EFI_DNS6_COMPLETION_TOKEN::Event |
This Event will be signaled after the Status field is updated by the EFI DNSv6 protocol driver. The type of Event must be EFI_NOTIFY_SIGNAL.
◆ GLookupData
| DNS6_GENERAL_LOOKUP_DATA* EFI_DNS6_COMPLETION_TOKEN::GLookupData |
When the Token is used for a general lookup function, GLookupDATA is a pointer to the DNS6_GENERAL_LOOKUP_DATA.
◆ H2AData
| DNS6_HOST_TO_ADDR_DATA* EFI_DNS6_COMPLETION_TOKEN::H2AData |
When the Token is used for host name to address translation, H2AData is a pointer to the DNS6_HOST_TO_ADDR_DATA.
◆ RetryCount
| UINT32 EFI_DNS6_COMPLETION_TOKEN::RetryCount |
The parameter configured through DNSv6.Configure() interface. Retry number if no response received after RetryInterval.
◆ RetryInterval
| UINT32 EFI_DNS6_COMPLETION_TOKEN::RetryInterval |
The parameter configured through DNSv6.Configure() interface. Minimum interval of retry is 2 seconds. If the retry interval is less than 2 seconds, then use the 2 seconds.
◆ [union]
| union { ... } EFI_DNS6_COMPLETION_TOKEN::RspData |
DNSv6 completion token data
◆ Status
| EFI_STATUS EFI_DNS6_COMPLETION_TOKEN::Status |
Will be set to one of the following values: EFI_SUCCESS: The host name to address translation completed successfully. EFI_NOT_FOUND: No matching Resource Record (RR) is found. EFI_TIMEOUT: No DNS server reachable, or RetryCount was exhausted without response from all specified DNS servers. EFI_DEVICE_ERROR: An unexpected system or network error occurred. EFI_NO_MEDIA: There was a media error.
The documentation for this struct was generated from the following file:
- XenevaOS/Boot/include/Protocol/Dns6.h
