#include <IpSecConfig.h>
Detailed Description
EFI_IPSEC_SPD_SELECTOR
Member Data Documentation
◆ LocalAddress
| EFI_IP_ADDRESS_INFO* _EFI_IPSEC_SPD_SELECTOR::LocalAddress |
A list of ranges of IPv4 or IPv6 addresses, which refers to the addresses being protected by IPsec policy.
◆ LocalAddressCount
| UINT32 _EFI_IPSEC_SPD_SELECTOR::LocalAddressCount |
Specifies the actual number of entries in LocalAddress.
◆ LocalPort
| UINT16 _EFI_IPSEC_SPD_SELECTOR::LocalPort |
Local Port if the Next Layer Protocol uses two ports (as do TCP, UDP, and others). A zero value is a wildcard that matches any value in LocalPort field.
◆ LocalPortRange
| UINT16 _EFI_IPSEC_SPD_SELECTOR::LocalPortRange |
A designed port range size. The start port is LocalPort, and the total number of ports is described by LocalPortRange. This field is ignored if NextLayerProtocol does not use ports.
◆ NextLayerProtocol
| UINT16 _EFI_IPSEC_SPD_SELECTOR::NextLayerProtocol |
Next layer protocol. Obtained from the IPv4 Protocol or the IPv6 Next Header fields. The next layer protocol is whatever comes after any IP extension headers that are present. A zero value is a wildcard that matches any value in NextLayerProtocol field.
◆ RemoteAddress
| EFI_IP_ADDRESS_INFO* _EFI_IPSEC_SPD_SELECTOR::RemoteAddress |
A list of ranges of IPv4 or IPv6 addresses, which are peer entities to LocalAddress.
◆ RemoteAddressCount
| UINT32 _EFI_IPSEC_SPD_SELECTOR::RemoteAddressCount |
Specifies the actual number of entries in RemoteAddress.
◆ RemotePort
| UINT16 _EFI_IPSEC_SPD_SELECTOR::RemotePort |
Remote Port if the Next Layer Protocol uses two ports. A zero value is a wildcard that matches any value in RemotePort field.
◆ RemotePortRange
| UINT16 _EFI_IPSEC_SPD_SELECTOR::RemotePortRange |
A designed port range size. The start port is RemotePort, and the total number of ports is described by RemotePortRange. This field is ignored if NextLayerProtocol does not use ports.
The documentation for this struct was generated from the following file:
- XenevaOS/Boot/include/Protocol/IpSecConfig.h
