#include <SpiIo.h>
Detailed Description
The EFI_SPI_BUS_ TRANSACTION data structure contains the description of the SPI transaction to perform on the host controller.
Member Data Documentation
◆ BusWidth
| UINT32 _EFI_SPI_BUS_TRANSACTION::BusWidth |
SPI bus width in bits: 1, 2, 4
◆ DebugTransaction
| BOOLEAN _EFI_SPI_BUS_TRANSACTION::DebugTransaction |
TRUE if the transaction is being debugged. Debugging may be turned on for a single SPI transaction. Only this transaction will display debugging messages. All other transactions with this value set to FALSE will not display any debugging messages.
◆ FrameSize
| UINT32 _EFI_SPI_BUS_TRANSACTION::FrameSize |
Frame size in bits, range: 1 - 32
◆ ReadBuffer
| UINT8* _EFI_SPI_BUS_TRANSACTION::ReadBuffer |
Buffer to receive the data from the SPI peripheral
- Frame sizes 1 - 8 bits: UINT8 (one byte) per frame
- Frame sizes 7 - 16 bits : UINT16 (two bytes) per frame
- Frame sizes 17 - 32 bits : UINT32 (four bytes) per frame
◆ ReadBytes
| UINT32 _EFI_SPI_BUS_TRANSACTION::ReadBytes |
Length of the read buffer in bytes
◆ SpiPeripheral
| CONST EFI_SPI_PERIPHERAL* _EFI_SPI_BUS_TRANSACTION::SpiPeripheral |
Pointer to the SPI peripheral being manipulated.
◆ TransactionType
| EFI_SPI_TRANSACTION_TYPE _EFI_SPI_BUS_TRANSACTION::TransactionType |
Type of transaction specified by one of the EFI_SPI_TRANSACTION_TYPE values.
◆ WriteBuffer
| UINT8* _EFI_SPI_BUS_TRANSACTION::WriteBuffer |
Buffer containing data to send to the SPI peripheral Frame sizes 1 - 8 bits: UINT8 (one byte) per frame Frame sizes 7 - 16 bits : UINT16 (two bytes) per frame
◆ WriteBytes
| UINT32 _EFI_SPI_BUS_TRANSACTION::WriteBytes |
Length of the write buffer in bytes
The documentation for this struct was generated from the following file:
- XenevaOS/Boot/include/Protocol/SpiIo.h
