#include <IndustryStandard/Acpi10.h>

Include dependency graph for Acpi20.h:

This graph shows which files directly or indirectly include this file:

Classes
struct	EFI_ACPI_2_0_GENERIC_ADDRESS_STRUCTURE

struct	EFI_ACPI_2_0_ROOT_SYSTEM_DESCRIPTION_POINTER

struct	EFI_ACPI_2_0_COMMON_HEADER

struct	EFI_ACPI_2_0_FIXED_ACPI_DESCRIPTION_TABLE

struct	EFI_ACPI_2_0_FIRMWARE_ACPI_CONTROL_STRUCTURE

struct	EFI_ACPI_2_0_MULTIPLE_APIC_DESCRIPTION_TABLE_HEADER

struct	EFI_ACPI_2_0_PROCESSOR_LOCAL_APIC_STRUCTURE

struct	EFI_ACPI_2_0_IO_APIC_STRUCTURE

struct	EFI_ACPI_2_0_INTERRUPT_SOURCE_OVERRIDE_STRUCTURE

struct	EFI_ACPI_2_0_NON_MASKABLE_INTERRUPT_SOURCE_STRUCTURE

struct	EFI_ACPI_2_0_LOCAL_APIC_NMI_STRUCTURE

struct	EFI_ACPI_2_0_LOCAL_APIC_ADDRESS_OVERRIDE_STRUCTURE

struct	EFI_ACPI_2_0_IO_SAPIC_STRUCTURE

struct	EFI_ACPI_2_0_PROCESSOR_LOCAL_SAPIC_STRUCTURE

struct	EFI_ACPI_2_0_PLATFORM_INTERRUPT_SOURCES_STRUCTURE

struct	EFI_ACPI_2_0_SMART_BATTERY_DESCRIPTION_TABLE

struct	EFI_ACPI_2_0_EMBEDDED_CONTROLLER_BOOT_RESOURCES_TABLE

Macros
#define	ACPI_LARGE_GENERIC_REGISTER_DESCRIPTOR_NAME 0x02

#define	ACPI_GENERIC_REGISTER_DESCRIPTOR 0x82

#define	EFI_ACPI_2_0_SYSTEM_MEMORY 0

#define	EFI_ACPI_2_0_SYSTEM_IO 1

#define	EFI_ACPI_2_0_PCI_CONFIGURATION_SPACE 2

#define	EFI_ACPI_2_0_EMBEDDED_CONTROLLER 3

#define	EFI_ACPI_2_0_SMBUS 4

#define	EFI_ACPI_2_0_FUNCTIONAL_FIXED_HARDWARE 0x7F

#define	EFI_ACPI_2_0_ROOT_SYSTEM_DESCRIPTION_POINTER_REVISION 0x02

#define	EFI_ACPI_2_0_ROOT_SYSTEM_DESCRIPTION_TABLE_REVISION 0x01

#define	EFI_ACPI_2_0_EXTENDED_SYSTEM_DESCRIPTION_TABLE_REVISION 0x01

#define	EFI_ACPI_2_0_FIXED_ACPI_DESCRIPTION_TABLE_REVISION 0x03

#define	EFI_ACPI_2_0_PM_PROFILE_UNSPECIFIED 0

#define	EFI_ACPI_2_0_PM_PROFILE_DESKTOP 1

#define	EFI_ACPI_2_0_PM_PROFILE_MOBILE 2

#define	EFI_ACPI_2_0_PM_PROFILE_WORKSTATION 3

#define	EFI_ACPI_2_0_PM_PROFILE_ENTERPRISE_SERVER 4

#define	EFI_ACPI_2_0_PM_PROFILE_SOHO_SERVER 5

#define	EFI_ACPI_2_0_PM_PROFILE_APPLIANCE_PC 6

#define	EFI_ACPI_2_0_LEGACY_DEVICES BIT0

#define	EFI_ACPI_2_0_8042 BIT1

#define	EFI_ACPI_2_0_WBINVD BIT0

#define	EFI_ACPI_2_0_WBINVD_FLUSH BIT1

#define	EFI_ACPI_2_0_PROC_C1 BIT2

#define	EFI_ACPI_2_0_P_LVL2_UP BIT3

#define	EFI_ACPI_2_0_PWR_BUTTON BIT4

#define	EFI_ACPI_2_0_SLP_BUTTON BIT5

#define	EFI_ACPI_2_0_FIX_RTC BIT6

#define	EFI_ACPI_2_0_RTC_S4 BIT7

#define	EFI_ACPI_2_0_TMR_VAL_EXT BIT8

#define	EFI_ACPI_2_0_DCK_CAP BIT9

#define	EFI_ACPI_2_0_RESET_REG_SUP BIT10

#define	EFI_ACPI_2_0_SEALED_CASE BIT11

#define	EFI_ACPI_2_0_HEADLESS BIT12

#define	EFI_ACPI_2_0_CPU_SW_SLP BIT13

#define	EFI_ACPI_2_0_FIRMWARE_ACPI_CONTROL_STRUCTURE_VERSION 0x01

#define	EFI_ACPI_2_0_S4BIOS_F BIT0

#define	EFI_ACPI_2_0_MULTIPLE_APIC_DESCRIPTION_TABLE_REVISION 0x01

#define	EFI_ACPI_2_0_PCAT_COMPAT BIT0

#define	EFI_ACPI_2_0_PROCESSOR_LOCAL_APIC 0x00

#define	EFI_ACPI_2_0_IO_APIC 0x01

#define	EFI_ACPI_2_0_INTERRUPT_SOURCE_OVERRIDE 0x02

#define	EFI_ACPI_2_0_NON_MASKABLE_INTERRUPT_SOURCE 0x03

#define	EFI_ACPI_2_0_LOCAL_APIC_NMI 0x04

#define	EFI_ACPI_2_0_LOCAL_APIC_ADDRESS_OVERRIDE 0x05

#define	EFI_ACPI_2_0_IO_SAPIC 0x06

#define	EFI_ACPI_2_0_PROCESSOR_LOCAL_SAPIC 0x07

#define	EFI_ACPI_2_0_PLATFORM_INTERRUPT_SOURCES 0x08

#define	EFI_ACPI_2_0_LOCAL_APIC_ENABLED BIT0

#define	EFI_ACPI_2_0_SMART_BATTERY_DESCRIPTION_TABLE_REVISION 0x01

#define	EFI_ACPI_2_0_EMBEDDED_CONTROLLER_BOOT_RESOURCES_TABLE_REVISION 0x01

#define	EFI_ACPI_2_0_ROOT_SYSTEM_DESCRIPTION_POINTER_SIGNATURE SIGNATURE_64('R', 'S', 'D', ' ', 'P', 'T', 'R', ' ')

#define	EFI_ACPI_2_0_MULTIPLE_SAPIC_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('A', 'P', 'I', 'C')

#define	EFI_ACPI_2_0_SIMPLE_BOOT_FLAG_TABLE_SIGNATURE SIGNATURE_32('B', 'O', 'O', 'T')

#define	EFI_ACPI_2_0_DEBUG_PORT_TABLE_SIGNATURE SIGNATURE_32('D', 'B', 'G', 'P')

#define	EFI_ACPI_2_0_DIFFERENTIATED_SYSTEM_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('D', 'S', 'D', 'T')

#define	EFI_ACPI_2_0_EMBEDDED_CONTROLLER_BOOT_RESOURCES_TABLE_SIGNATURE SIGNATURE_32('E', 'C', 'D', 'T')

#define	EFI_ACPI_2_0_EVENT_TIMER_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('E', 'T', 'D', 'T')

#define	EFI_ACPI_2_0_FIRMWARE_ACPI_CONTROL_STRUCTURE_SIGNATURE SIGNATURE_32('F', 'A', 'C', 'S')

#define	EFI_ACPI_2_0_FIXED_ACPI_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('F', 'A', 'C', 'P')

#define	EFI_ACPI_2_0_MULTIPLE_APIC_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('A', 'P', 'I', 'C')

#define	EFI_ACPI_2_0_PERSISTENT_SYSTEM_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('P', 'S', 'D', 'T')

#define	EFI_ACPI_2_0_ROOT_SYSTEM_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('R', 'S', 'D', 'T')

#define	EFI_ACPI_2_0_SMART_BATTERY_SPECIFICATION_TABLE_SIGNATURE SIGNATURE_32('S', 'B', 'S', 'T')

#define	EFI_ACPI_2_0_SYSTEM_LOCALITY_INFORMATION_TABLE_SIGNATURE SIGNATURE_32('S', 'L', 'I', 'T')

#define	EFI_ACPI_2_0_SERIAL_PORT_CONSOLE_REDIRECTION_TABLE_SIGNATURE SIGNATURE_32('S', 'P', 'C', 'R')

#define	EFI_ACPI_2_0_STATIC_RESOURCE_AFFINITY_TABLE_SIGNATURE SIGNATURE_32('S', 'R', 'A', 'T')

#define	EFI_ACPI_2_0_SECONDARY_SYSTEM_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('S', 'S', 'D', 'T')

#define	EFI_ACPI_2_0_SERVER_PLATFORM_MANAGEMENT_INTERFACE_SIGNATURE SIGNATURE_32('S', 'P', 'M', 'I')

#define	EFI_ACPI_2_0_EXTENDED_SYSTEM_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('X', 'S', 'D', 'T')

#define	EFI_ACPI_2_0_MEMORY_MAPPED_CONFIGURATION_BASE_ADDRESS_TABLE_SIGNATURE SIGNATURE_32('M', 'C', 'F', 'G')

Typedefs
struct {

ACPI_LARGE_RESOURCE_HEADER Header

UINT8 AddressSpaceId

UINT8 RegisterBitWidth

UINT8 RegisterBitOffset

UINT8 AddressSize

UINT64 RegisterAddress

}	EFI_ACPI_GENERIC_REGISTER_DESCRIPTOR

Detailed Description

ACPI 2.0 definitions from the ACPI Specification, revision 2.0

Copyright (c) 2006 - 2018, Intel Corporation. All rights reserved.
This program and the accompanying materials are licensed and made available under the terms and conditions of the BSD License which accompanies this distribution. The full text of the license may be found at http://opensource.org/licenses/bsd-license.php

THE PROGRAM IS DISTRIBUTED UNDER THE BSD LICENSE ON AN "AS IS" BASIS, WITHOUT WARRANTIES OR REPRESENTATIONS OF ANY KIND, EITHER EXPRESS OR IMPLIED.

Macro Definition Documentation

◆ ACPI_GENERIC_REGISTER_DESCRIPTOR

#define ACPI_GENERIC_REGISTER_DESCRIPTOR 0x82

◆ ACPI_LARGE_GENERIC_REGISTER_DESCRIPTOR_NAME

#define ACPI_LARGE_GENERIC_REGISTER_DESCRIPTOR_NAME 0x02

◆ EFI_ACPI_2_0_8042

#define EFI_ACPI_2_0_8042 BIT1

◆ EFI_ACPI_2_0_CPU_SW_SLP

#define EFI_ACPI_2_0_CPU_SW_SLP BIT13

◆ EFI_ACPI_2_0_DCK_CAP

#define EFI_ACPI_2_0_DCK_CAP BIT9

◆ EFI_ACPI_2_0_DEBUG_PORT_TABLE_SIGNATURE

#define EFI_ACPI_2_0_DEBUG_PORT_TABLE_SIGNATURE SIGNATURE_32('D', 'B', 'G', 'P')

"DBGP" MS Bebug Port Spec

◆ EFI_ACPI_2_0_DIFFERENTIATED_SYSTEM_DESCRIPTION_TABLE_SIGNATURE

#define EFI_ACPI_2_0_DIFFERENTIATED_SYSTEM_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('D', 'S', 'D', 'T')

"DSDT" Differentiated System Description Table

◆ EFI_ACPI_2_0_EMBEDDED_CONTROLLER

#define EFI_ACPI_2_0_EMBEDDED_CONTROLLER 3

◆ EFI_ACPI_2_0_EMBEDDED_CONTROLLER_BOOT_RESOURCES_TABLE_REVISION

#define EFI_ACPI_2_0_EMBEDDED_CONTROLLER_BOOT_RESOURCES_TABLE_REVISION 0x01

ECDT Version (as defined in ACPI 2.0 spec.)

◆ EFI_ACPI_2_0_EMBEDDED_CONTROLLER_BOOT_RESOURCES_TABLE_SIGNATURE

#define EFI_ACPI_2_0_EMBEDDED_CONTROLLER_BOOT_RESOURCES_TABLE_SIGNATURE SIGNATURE_32('E', 'C', 'D', 'T')

"ECDT" Embedded Controller Boot Resources Table

◆ EFI_ACPI_2_0_EVENT_TIMER_DESCRIPTION_TABLE_SIGNATURE

#define EFI_ACPI_2_0_EVENT_TIMER_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('E', 'T', 'D', 'T')

"ETDT" Event Timer Description Table

◆ EFI_ACPI_2_0_EXTENDED_SYSTEM_DESCRIPTION_TABLE_REVISION

#define EFI_ACPI_2_0_EXTENDED_SYSTEM_DESCRIPTION_TABLE_REVISION 0x01

XSDT Revision (as defined in ACPI 2.0 spec.)

◆ EFI_ACPI_2_0_EXTENDED_SYSTEM_DESCRIPTION_TABLE_SIGNATURE

#define EFI_ACPI_2_0_EXTENDED_SYSTEM_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('X', 'S', 'D', 'T')

"XSDT" Extended System Description Table

◆ EFI_ACPI_2_0_FIRMWARE_ACPI_CONTROL_STRUCTURE_SIGNATURE

#define EFI_ACPI_2_0_FIRMWARE_ACPI_CONTROL_STRUCTURE_SIGNATURE SIGNATURE_32('F', 'A', 'C', 'S')

"FACS" Firmware ACPI Control Structure

◆ EFI_ACPI_2_0_FIRMWARE_ACPI_CONTROL_STRUCTURE_VERSION

#define EFI_ACPI_2_0_FIRMWARE_ACPI_CONTROL_STRUCTURE_VERSION 0x01

FACS Version (as defined in ACPI 2.0 spec.)

◆ EFI_ACPI_2_0_FIX_RTC

#define EFI_ACPI_2_0_FIX_RTC BIT6

◆ EFI_ACPI_2_0_FIXED_ACPI_DESCRIPTION_TABLE_REVISION

#define EFI_ACPI_2_0_FIXED_ACPI_DESCRIPTION_TABLE_REVISION 0x03

FADT Version (as defined in ACPI 2.0 spec.)

◆ EFI_ACPI_2_0_FIXED_ACPI_DESCRIPTION_TABLE_SIGNATURE

#define EFI_ACPI_2_0_FIXED_ACPI_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('F', 'A', 'C', 'P')

"FACP" Fixed ACPI Description Table

◆ EFI_ACPI_2_0_FUNCTIONAL_FIXED_HARDWARE

#define EFI_ACPI_2_0_FUNCTIONAL_FIXED_HARDWARE 0x7F

◆ EFI_ACPI_2_0_HEADLESS

#define EFI_ACPI_2_0_HEADLESS BIT12

◆ EFI_ACPI_2_0_INTERRUPT_SOURCE_OVERRIDE

#define EFI_ACPI_2_0_INTERRUPT_SOURCE_OVERRIDE 0x02

◆ EFI_ACPI_2_0_IO_APIC

#define EFI_ACPI_2_0_IO_APIC 0x01

◆ EFI_ACPI_2_0_IO_SAPIC

#define EFI_ACPI_2_0_IO_SAPIC 0x06

◆ EFI_ACPI_2_0_LEGACY_DEVICES

#define EFI_ACPI_2_0_LEGACY_DEVICES BIT0

◆ EFI_ACPI_2_0_LOCAL_APIC_ADDRESS_OVERRIDE

#define EFI_ACPI_2_0_LOCAL_APIC_ADDRESS_OVERRIDE 0x05

◆ EFI_ACPI_2_0_LOCAL_APIC_ENABLED

#define EFI_ACPI_2_0_LOCAL_APIC_ENABLED BIT0

Local APIC Flags. All other bits are reserved and must be 0.

◆ EFI_ACPI_2_0_LOCAL_APIC_NMI

#define EFI_ACPI_2_0_LOCAL_APIC_NMI 0x04

◆ EFI_ACPI_2_0_MEMORY_MAPPED_CONFIGURATION_BASE_ADDRESS_TABLE_SIGNATURE

#define EFI_ACPI_2_0_MEMORY_MAPPED_CONFIGURATION_BASE_ADDRESS_TABLE_SIGNATURE SIGNATURE_32('M', 'C', 'F', 'G')

"MCFG" PCI Express Memory Mapped Configuration Space Base Address Description Table

◆ EFI_ACPI_2_0_MULTIPLE_APIC_DESCRIPTION_TABLE_REVISION

#define EFI_ACPI_2_0_MULTIPLE_APIC_DESCRIPTION_TABLE_REVISION 0x01

MADT Revision (as defined in ACPI 2.0 spec.)

◆ EFI_ACPI_2_0_MULTIPLE_APIC_DESCRIPTION_TABLE_SIGNATURE

#define EFI_ACPI_2_0_MULTIPLE_APIC_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('A', 'P', 'I', 'C')

"APIC" Multiple APIC Description Table

◆ EFI_ACPI_2_0_MULTIPLE_SAPIC_DESCRIPTION_TABLE_SIGNATURE

#define EFI_ACPI_2_0_MULTIPLE_SAPIC_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('A', 'P', 'I', 'C')

"SPIC" Multiple SAPIC Description Table

BUGBUG: Don't know where this came from except SR870BN4 uses it. #define EFI_ACPI_2_0_MULTIPLE_SAPIC_DESCRIPTION_TABLE_SIGNATURE 0x43495053

◆ EFI_ACPI_2_0_NON_MASKABLE_INTERRUPT_SOURCE

#define EFI_ACPI_2_0_NON_MASKABLE_INTERRUPT_SOURCE 0x03

◆ EFI_ACPI_2_0_P_LVL2_UP

#define EFI_ACPI_2_0_P_LVL2_UP BIT3

◆ EFI_ACPI_2_0_PCAT_COMPAT

#define EFI_ACPI_2_0_PCAT_COMPAT BIT0

Multiple APIC Flags All other bits are reserved and must be set to 0.

◆ EFI_ACPI_2_0_PCI_CONFIGURATION_SPACE

#define EFI_ACPI_2_0_PCI_CONFIGURATION_SPACE 2

◆ EFI_ACPI_2_0_PERSISTENT_SYSTEM_DESCRIPTION_TABLE_SIGNATURE

#define EFI_ACPI_2_0_PERSISTENT_SYSTEM_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('P', 'S', 'D', 'T')

"PSDT" Persistent System Description Table

◆ EFI_ACPI_2_0_PLATFORM_INTERRUPT_SOURCES

#define EFI_ACPI_2_0_PLATFORM_INTERRUPT_SOURCES 0x08

◆ EFI_ACPI_2_0_PM_PROFILE_APPLIANCE_PC

#define EFI_ACPI_2_0_PM_PROFILE_APPLIANCE_PC 6

◆ EFI_ACPI_2_0_PM_PROFILE_DESKTOP

#define EFI_ACPI_2_0_PM_PROFILE_DESKTOP 1

◆ EFI_ACPI_2_0_PM_PROFILE_ENTERPRISE_SERVER

#define EFI_ACPI_2_0_PM_PROFILE_ENTERPRISE_SERVER 4

◆ EFI_ACPI_2_0_PM_PROFILE_MOBILE

#define EFI_ACPI_2_0_PM_PROFILE_MOBILE 2

◆ EFI_ACPI_2_0_PM_PROFILE_SOHO_SERVER

#define EFI_ACPI_2_0_PM_PROFILE_SOHO_SERVER 5

◆ EFI_ACPI_2_0_PM_PROFILE_UNSPECIFIED

#define EFI_ACPI_2_0_PM_PROFILE_UNSPECIFIED 0

◆ EFI_ACPI_2_0_PM_PROFILE_WORKSTATION

#define EFI_ACPI_2_0_PM_PROFILE_WORKSTATION 3

◆ EFI_ACPI_2_0_PROC_C1

#define EFI_ACPI_2_0_PROC_C1 BIT2

◆ EFI_ACPI_2_0_PROCESSOR_LOCAL_APIC

#define EFI_ACPI_2_0_PROCESSOR_LOCAL_APIC 0x00

◆ EFI_ACPI_2_0_PROCESSOR_LOCAL_SAPIC

#define EFI_ACPI_2_0_PROCESSOR_LOCAL_SAPIC 0x07

◆ EFI_ACPI_2_0_PWR_BUTTON

#define EFI_ACPI_2_0_PWR_BUTTON BIT4

◆ EFI_ACPI_2_0_RESET_REG_SUP

#define EFI_ACPI_2_0_RESET_REG_SUP BIT10

◆ EFI_ACPI_2_0_ROOT_SYSTEM_DESCRIPTION_POINTER_REVISION

#define EFI_ACPI_2_0_ROOT_SYSTEM_DESCRIPTION_POINTER_REVISION 0x02

RSD_PTR Revision (as defined in ACPI 2.0 spec.)

◆ EFI_ACPI_2_0_ROOT_SYSTEM_DESCRIPTION_POINTER_SIGNATURE

#define EFI_ACPI_2_0_ROOT_SYSTEM_DESCRIPTION_POINTER_SIGNATURE SIGNATURE_64('R', 'S', 'D', ' ', 'P', 'T', 'R', ' ')

"RSD PTR " Root System Description Pointer

◆ EFI_ACPI_2_0_ROOT_SYSTEM_DESCRIPTION_TABLE_REVISION

#define EFI_ACPI_2_0_ROOT_SYSTEM_DESCRIPTION_TABLE_REVISION 0x01

RSDT Revision (as defined in ACPI 2.0 spec.)

◆ EFI_ACPI_2_0_ROOT_SYSTEM_DESCRIPTION_TABLE_SIGNATURE

#define EFI_ACPI_2_0_ROOT_SYSTEM_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('R', 'S', 'D', 'T')

"RSDT" Root System Description Table

◆ EFI_ACPI_2_0_RTC_S4

#define EFI_ACPI_2_0_RTC_S4 BIT7

◆ EFI_ACPI_2_0_S4BIOS_F

#define EFI_ACPI_2_0_S4BIOS_F BIT0

Firmware Control Structure Feature Flags All other bits are reserved and must be set to 0.

◆ EFI_ACPI_2_0_SEALED_CASE

#define EFI_ACPI_2_0_SEALED_CASE BIT11

◆ EFI_ACPI_2_0_SECONDARY_SYSTEM_DESCRIPTION_TABLE_SIGNATURE

#define EFI_ACPI_2_0_SECONDARY_SYSTEM_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('S', 'S', 'D', 'T')

"SSDT" Secondary System Description Table

◆ EFI_ACPI_2_0_SERIAL_PORT_CONSOLE_REDIRECTION_TABLE_SIGNATURE

#define EFI_ACPI_2_0_SERIAL_PORT_CONSOLE_REDIRECTION_TABLE_SIGNATURE SIGNATURE_32('S', 'P', 'C', 'R')

"SPCR" Serial Port Concole Redirection Table

◆ EFI_ACPI_2_0_SERVER_PLATFORM_MANAGEMENT_INTERFACE_SIGNATURE

#define EFI_ACPI_2_0_SERVER_PLATFORM_MANAGEMENT_INTERFACE_SIGNATURE SIGNATURE_32('S', 'P', 'M', 'I')

"SPMI" Server Platform Management Interface Table

◆ EFI_ACPI_2_0_SIMPLE_BOOT_FLAG_TABLE_SIGNATURE

#define EFI_ACPI_2_0_SIMPLE_BOOT_FLAG_TABLE_SIGNATURE SIGNATURE_32('B', 'O', 'O', 'T')

"BOOT" MS Simple Boot Spec

◆ EFI_ACPI_2_0_SLP_BUTTON

#define EFI_ACPI_2_0_SLP_BUTTON BIT5

◆ EFI_ACPI_2_0_SMART_BATTERY_DESCRIPTION_TABLE_REVISION

#define EFI_ACPI_2_0_SMART_BATTERY_DESCRIPTION_TABLE_REVISION 0x01

SBST Version (as defined in ACPI 2.0 spec.)

◆ EFI_ACPI_2_0_SMART_BATTERY_SPECIFICATION_TABLE_SIGNATURE

#define EFI_ACPI_2_0_SMART_BATTERY_SPECIFICATION_TABLE_SIGNATURE SIGNATURE_32('S', 'B', 'S', 'T')

"SBST" Smart Battery Specification Table

◆ EFI_ACPI_2_0_SMBUS

#define EFI_ACPI_2_0_SMBUS 4

◆ EFI_ACPI_2_0_STATIC_RESOURCE_AFFINITY_TABLE_SIGNATURE

#define EFI_ACPI_2_0_STATIC_RESOURCE_AFFINITY_TABLE_SIGNATURE SIGNATURE_32('S', 'R', 'A', 'T')

"SRAT" Static Resource Affinity Table

◆ EFI_ACPI_2_0_SYSTEM_IO

#define EFI_ACPI_2_0_SYSTEM_IO 1

◆ EFI_ACPI_2_0_SYSTEM_LOCALITY_INFORMATION_TABLE_SIGNATURE

#define EFI_ACPI_2_0_SYSTEM_LOCALITY_INFORMATION_TABLE_SIGNATURE SIGNATURE_32('S', 'L', 'I', 'T')

"SLIT" System Locality Information Table

◆ EFI_ACPI_2_0_SYSTEM_MEMORY

#define EFI_ACPI_2_0_SYSTEM_MEMORY 0

◆ EFI_ACPI_2_0_TMR_VAL_EXT

#define EFI_ACPI_2_0_TMR_VAL_EXT BIT8

◆ EFI_ACPI_2_0_WBINVD

#define EFI_ACPI_2_0_WBINVD BIT0

◆ EFI_ACPI_2_0_WBINVD_FLUSH

#define EFI_ACPI_2_0_WBINVD_FLUSH BIT1

Typedef Documentation

◆ [struct]

typedef PACKED struct { ... } EFI_ACPI_GENERIC_REGISTER_DESCRIPTOR

Generic Register Descriptor

Variable Documentation

◆ AddressSize

UINT8 AddressSize

◆ AddressSpaceId

UINT8 AddressSpaceId

◆ Header

ACPI_LARGE_RESOURCE_HEADER Header

◆ RegisterAddress

UINT64 RegisterAddress

◆ RegisterBitOffset

UINT8 RegisterBitOffset

◆ RegisterBitWidth

UINT8 RegisterBitWidth

Classes

Macros

Typedefs
