#include <IndustryStandard/Acpi20.h>

Include dependency graph for Acpi30.h:

This graph shows which files directly or indirectly include this file:

Classes
struct	EFI_ACPI_3_0_GENERIC_ADDRESS_STRUCTURE

struct	EFI_ACPI_3_0_ROOT_SYSTEM_DESCRIPTION_POINTER

struct	EFI_ACPI_3_0_COMMON_HEADER

struct	EFI_ACPI_3_0_FIXED_ACPI_DESCRIPTION_TABLE

struct	EFI_ACPI_3_0_FIRMWARE_ACPI_CONTROL_STRUCTURE

struct	EFI_ACPI_3_0_MULTIPLE_APIC_DESCRIPTION_TABLE_HEADER

struct	EFI_ACPI_3_0_PROCESSOR_LOCAL_APIC_STRUCTURE

struct	EFI_ACPI_3_0_IO_APIC_STRUCTURE

struct	EFI_ACPI_3_0_INTERRUPT_SOURCE_OVERRIDE_STRUCTURE

struct	EFI_ACPI_3_0_PLATFORM_INTERRUPT_APIC_STRUCTURE

struct	EFI_ACPI_3_0_NON_MASKABLE_INTERRUPT_SOURCE_STRUCTURE

struct	EFI_ACPI_3_0_LOCAL_APIC_NMI_STRUCTURE

struct	EFI_ACPI_3_0_LOCAL_APIC_ADDRESS_OVERRIDE_STRUCTURE

struct	EFI_ACPI_3_0_IO_SAPIC_STRUCTURE

struct	EFI_ACPI_3_0_PROCESSOR_LOCAL_SAPIC_STRUCTURE

struct	EFI_ACPI_3_0_PLATFORM_INTERRUPT_SOURCES_STRUCTURE

struct	EFI_ACPI_3_0_SMART_BATTERY_DESCRIPTION_TABLE

struct	EFI_ACPI_3_0_EMBEDDED_CONTROLLER_BOOT_RESOURCES_TABLE

struct	EFI_ACPI_3_0_SYSTEM_RESOURCE_AFFINITY_TABLE_HEADER

struct	EFI_ACPI_3_0_PROCESSOR_LOCAL_APIC_SAPIC_AFFINITY_STRUCTURE

struct	EFI_ACPI_3_0_MEMORY_AFFINITY_STRUCTURE

struct	EFI_ACPI_3_0_SYSTEM_LOCALITY_DISTANCE_INFORMATION_TABLE_HEADER

Macros
#define	ACPI_LARGE_EXTENDED_ADDRESS_SPACE_DESCRIPTOR_NAME 0x0B

#define	ACPI_EXTENDED_ADDRESS_SPACE_DESCRIPTOR 0x8B

#define	EFI_ACPI_MEMORY_TYPE_SPECIFIC_ATTRIBUTES_UC 0x0000000000000001

#define	EFI_ACPI_MEMORY_TYPE_SPECIFIC_ATTRIBUTES_WC 0x0000000000000002

#define	EFI_ACPI_MEMORY_TYPE_SPECIFIC_ATTRIBUTES_WT 0x0000000000000004

#define	EFI_ACPI_MEMORY_TYPE_SPECIFIC_ATTRIBUTES_WB 0x0000000000000008

#define	EFI_ACPI_MEMORY_TYPE_SPECIFIC_ATTRIBUTES_UCE 0x0000000000000010

#define	EFI_ACPI_MEMORY_TYPE_SPECIFIC_ATTRIBUTES_NV 0x0000000000008000

#define	EFI_ACPI_3_0_SYSTEM_MEMORY 0

#define	EFI_ACPI_3_0_SYSTEM_IO 1

#define	EFI_ACPI_3_0_PCI_CONFIGURATION_SPACE 2

#define	EFI_ACPI_3_0_EMBEDDED_CONTROLLER 3

#define	EFI_ACPI_3_0_SMBUS 4

#define	EFI_ACPI_3_0_FUNCTIONAL_FIXED_HARDWARE 0x7F

#define	EFI_ACPI_3_0_UNDEFINED 0

#define	EFI_ACPI_3_0_BYTE 1

#define	EFI_ACPI_3_0_WORD 2

#define	EFI_ACPI_3_0_DWORD 3

#define	EFI_ACPI_3_0_QWORD 4

#define	EFI_ACPI_3_0_ROOT_SYSTEM_DESCRIPTION_POINTER_REVISION 0x02
	ACPISpec (Revision 3.0b) says current value is 2.

#define	EFI_ACPI_3_0_ROOT_SYSTEM_DESCRIPTION_TABLE_REVISION 0x01

#define	EFI_ACPI_3_0_EXTENDED_SYSTEM_DESCRIPTION_TABLE_REVISION 0x01

#define	EFI_ACPI_3_0_FIXED_ACPI_DESCRIPTION_TABLE_REVISION 0x04

#define	EFI_ACPI_3_0_PM_PROFILE_UNSPECIFIED 0

#define	EFI_ACPI_3_0_PM_PROFILE_DESKTOP 1

#define	EFI_ACPI_3_0_PM_PROFILE_MOBILE 2

#define	EFI_ACPI_3_0_PM_PROFILE_WORKSTATION 3

#define	EFI_ACPI_3_0_PM_PROFILE_ENTERPRISE_SERVER 4

#define	EFI_ACPI_3_0_PM_PROFILE_SOHO_SERVER 5

#define	EFI_ACPI_3_0_PM_PROFILE_APPLIANCE_PC 6

#define	EFI_ACPI_3_0_PM_PROFILE_PERFORMANCE_SERVER 7

#define	EFI_ACPI_3_0_LEGACY_DEVICES BIT0

#define	EFI_ACPI_3_0_8042 BIT1

#define	EFI_ACPI_3_0_VGA_NOT_PRESENT BIT2

#define	EFI_ACPI_3_0_MSI_NOT_SUPPORTED BIT3

#define	EFI_ACPI_3_0_PCIE_ASPM_CONTROLS BIT4

#define	EFI_ACPI_3_0_WBINVD BIT0

#define	EFI_ACPI_3_0_WBINVD_FLUSH BIT1

#define	EFI_ACPI_3_0_PROC_C1 BIT2

#define	EFI_ACPI_3_0_P_LVL2_UP BIT3

#define	EFI_ACPI_3_0_PWR_BUTTON BIT4

#define	EFI_ACPI_3_0_SLP_BUTTON BIT5

#define	EFI_ACPI_3_0_FIX_RTC BIT6

#define	EFI_ACPI_3_0_RTC_S4 BIT7

#define	EFI_ACPI_3_0_TMR_VAL_EXT BIT8

#define	EFI_ACPI_3_0_DCK_CAP BIT9

#define	EFI_ACPI_3_0_RESET_REG_SUP BIT10

#define	EFI_ACPI_3_0_SEALED_CASE BIT11

#define	EFI_ACPI_3_0_HEADLESS BIT12

#define	EFI_ACPI_3_0_CPU_SW_SLP BIT13

#define	EFI_ACPI_3_0_PCI_EXP_WAK BIT14

#define	EFI_ACPI_3_0_USE_PLATFORM_CLOCK BIT15

#define	EFI_ACPI_3_0_S4_RTC_STS_VALID BIT16

#define	EFI_ACPI_3_0_REMOTE_POWER_ON_CAPABLE BIT17

#define	EFI_ACPI_3_0_FORCE_APIC_CLUSTER_MODEL BIT18

#define	EFI_ACPI_3_0_FORCE_APIC_PHYSICAL_DESTINATION_MODE BIT19

#define	EFI_ACPI_3_0_FIRMWARE_ACPI_CONTROL_STRUCTURE_VERSION 0x01

#define	EFI_ACPI_3_0_S4BIOS_F BIT0

#define	EFI_ACPI_3_0_DIFFERENTIATED_SYSTEM_DESCRIPTION_TABLE_REVISION 0x02

#define	EFI_ACPI_3_0_SECONDARY_SYSTEM_DESCRIPTION_TABLE_REVISION 0x02

#define	EFI_ACPI_3_0_MULTIPLE_APIC_DESCRIPTION_TABLE_REVISION 0x02

#define	EFI_ACPI_3_0_PCAT_COMPAT BIT0

#define	EFI_ACPI_3_0_PROCESSOR_LOCAL_APIC 0x00

#define	EFI_ACPI_3_0_IO_APIC 0x01

#define	EFI_ACPI_3_0_INTERRUPT_SOURCE_OVERRIDE 0x02

#define	EFI_ACPI_3_0_NON_MASKABLE_INTERRUPT_SOURCE 0x03

#define	EFI_ACPI_3_0_LOCAL_APIC_NMI 0x04

#define	EFI_ACPI_3_0_LOCAL_APIC_ADDRESS_OVERRIDE 0x05

#define	EFI_ACPI_3_0_IO_SAPIC 0x06

#define	EFI_ACPI_3_0_LOCAL_SAPIC 0x07

#define	EFI_ACPI_3_0_PLATFORM_INTERRUPT_SOURCES 0x08

#define	EFI_ACPI_3_0_LOCAL_APIC_ENABLED BIT0

#define	EFI_ACPI_3_0_POLARITY (3 << 0)

#define	EFI_ACPI_3_0_TRIGGER_MODE (3 << 2)

#define	EFI_ACPI_3_0_CPEI_PROCESSOR_OVERRIDE BIT0

#define	EFI_ACPI_3_0_SMART_BATTERY_DESCRIPTION_TABLE_REVISION 0x01

#define	EFI_ACPI_3_0_EMBEDDED_CONTROLLER_BOOT_RESOURCES_TABLE_REVISION 0x01

#define	EFI_ACPI_3_0_SYSTEM_RESOURCE_AFFINITY_TABLE_REVISION 0x02

#define	EFI_ACPI_3_0_PROCESSOR_LOCAL_APIC_SAPIC_AFFINITY 0x00

#define	EFI_ACPI_3_0_MEMORY_AFFINITY 0x01

#define	EFI_ACPI_3_0_PROCESSOR_LOCAL_APIC_SAPIC_ENABLED (1 << 0)

#define	EFI_ACPI_3_0_MEMORY_ENABLED (1 << 0)

#define	EFI_ACPI_3_0_MEMORY_HOT_PLUGGABLE (1 << 1)

#define	EFI_ACPI_3_0_MEMORY_NONVOLATILE (1 << 2)

#define	EFI_ACPI_3_0_SYSTEM_LOCALITY_DISTANCE_INFORMATION_TABLE_REVISION 0x01

#define	EFI_ACPI_3_0_ROOT_SYSTEM_DESCRIPTION_POINTER_SIGNATURE SIGNATURE_64('R', 'S', 'D', ' ', 'P', 'T', 'R', ' ')

#define	EFI_ACPI_3_0_MULTIPLE_APIC_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('A', 'P', 'I', 'C')

#define	EFI_ACPI_3_0_DIFFERENTIATED_SYSTEM_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('D', 'S', 'D', 'T')

#define	EFI_ACPI_3_0_EMBEDDED_CONTROLLER_BOOT_RESOURCES_TABLE_SIGNATURE SIGNATURE_32('E', 'C', 'D', 'T')

#define	EFI_ACPI_3_0_FIXED_ACPI_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('F', 'A', 'C', 'P')

#define	EFI_ACPI_3_0_FIRMWARE_ACPI_CONTROL_STRUCTURE_SIGNATURE SIGNATURE_32('F', 'A', 'C', 'S')

#define	EFI_ACPI_3_0_PERSISTENT_SYSTEM_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('P', 'S', 'D', 'T')

#define	EFI_ACPI_3_0_ROOT_SYSTEM_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('R', 'S', 'D', 'T')

#define	EFI_ACPI_3_0_SMART_BATTERY_SPECIFICATION_TABLE_SIGNATURE SIGNATURE_32('S', 'B', 'S', 'T')

#define	EFI_ACPI_3_0_SYSTEM_LOCALITY_INFORMATION_TABLE_SIGNATURE SIGNATURE_32('S', 'L', 'I', 'T')

#define	EFI_ACPI_3_0_SYSTEM_RESOURCE_AFFINITY_TABLE_SIGNATURE SIGNATURE_32('S', 'R', 'A', 'T')

#define	EFI_ACPI_3_0_SECONDARY_SYSTEM_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('S', 'S', 'D', 'T')

#define	EFI_ACPI_3_0_EXTENDED_SYSTEM_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('X', 'S', 'D', 'T')

#define	EFI_ACPI_3_0_SIMPLE_BOOT_FLAG_TABLE_SIGNATURE SIGNATURE_32('B', 'O', 'O', 'T')

#define	EFI_ACPI_3_0_CORRECTED_PLATFORM_ERROR_POLLING_TABLE_SIGNATURE SIGNATURE_32('C', 'P', 'E', 'P')

#define	EFI_ACPI_3_0_DEBUG_PORT_TABLE_SIGNATURE SIGNATURE_32('D', 'B', 'G', 'P')

#define	EFI_ACPI_3_0_EVENT_TIMER_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('E', 'T', 'D', 'T')

#define	EFI_ACPI_3_0_HIGH_PRECISION_EVENT_TIMER_TABLE_SIGNATURE SIGNATURE_32('H', 'P', 'E', 'T')

#define	EFI_ACPI_3_0_PCI_EXPRESS_MEMORY_MAPPED_CONFIGURATION_SPACE_BASE_ADDRESS_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('M', 'C', 'F', 'G')

#define	EFI_ACPI_3_0_SERIAL_PORT_CONSOLE_REDIRECTION_TABLE_SIGNATURE SIGNATURE_32('S', 'P', 'C', 'R')

#define	EFI_ACPI_3_0_SERVER_PLATFORM_MANAGEMENT_INTERFACE_TABLE_SIGNATURE SIGNATURE_32('S', 'P', 'M', 'I')

#define	EFI_ACPI_3_0_TRUSTED_COMPUTING_PLATFORM_ALLIANCE_CAPABILITIES_TABLE_SIGNATURE SIGNATURE_32('T', 'C', 'P', 'A')

#define	EFI_ACPI_3_0_WATCHDOG_RESOURCE_TABLE_SIGNATURE SIGNATURE_32('W', 'D', 'R', 'T')

#define	EFI_ACPI_3_0_WATCHDOG_ACTION_TABLE_SIGNATURE SIGNATURE_32('W', 'D', 'A', 'T')

#define	EFI_ACPI_3_0_WINDOWS_SPECIFIC_PROPERTIES_TABLE_SIGNATURE SIGNATURE_32('W', 'S', 'P', 'T')

#define	EFI_ACPI_3_0_ISCSI_BOOT_FIRMWARE_TABLE_SIGNATURE SIGNATURE_32('i', 'B', 'F', 'T')

Typedefs
struct {

ACPI_LARGE_RESOURCE_HEADER Header

UINT8 ResType

UINT8 GenFlag

UINT8 SpecificFlag

UINT8 RevisionId

UINT8 Reserved

UINT64 AddrSpaceGranularity

UINT64 AddrRangeMin

UINT64 AddrRangeMax

UINT64 AddrTranslationOffset

UINT64 AddrLen

UINT64 TypeSpecificAttribute

}	EFI_ACPI_EXTENDED_ADDRESS_SPACE_DESCRIPTOR

Detailed Description

ACPI 3.0 definitions from the ACPI Specification Revision 3.0b October 10, 2006

Copyright (c) 2006 - 2018, Intel Corporation. All rights reserved.
This program and the accompanying materials are licensed and made available under the terms and conditions of the BSD License which accompanies this distribution. The full text of the license may be found at http://opensource.org/licenses/bsd-license.php

THE PROGRAM IS DISTRIBUTED UNDER THE BSD LICENSE ON AN "AS IS" BASIS, WITHOUT WARRANTIES OR REPRESENTATIONS OF ANY KIND, EITHER EXPRESS OR IMPLIED.

Macro Definition Documentation

◆ ACPI_EXTENDED_ADDRESS_SPACE_DESCRIPTOR

#define ACPI_EXTENDED_ADDRESS_SPACE_DESCRIPTOR 0x8B

◆ ACPI_LARGE_EXTENDED_ADDRESS_SPACE_DESCRIPTOR_NAME

#define ACPI_LARGE_EXTENDED_ADDRESS_SPACE_DESCRIPTOR_NAME 0x0B

◆ EFI_ACPI_3_0_8042

#define EFI_ACPI_3_0_8042 BIT1

◆ EFI_ACPI_3_0_BYTE

#define EFI_ACPI_3_0_BYTE 1

◆ EFI_ACPI_3_0_CORRECTED_PLATFORM_ERROR_POLLING_TABLE_SIGNATURE

#define EFI_ACPI_3_0_CORRECTED_PLATFORM_ERROR_POLLING_TABLE_SIGNATURE SIGNATURE_32('C', 'P', 'E', 'P')

"CPEP" Corrected Platform Error Polling Table

◆ EFI_ACPI_3_0_CPEI_PROCESSOR_OVERRIDE

#define EFI_ACPI_3_0_CPEI_PROCESSOR_OVERRIDE BIT0

Platform Interrupt Source Flags. All other bits are reserved and must be set to 0.

◆ EFI_ACPI_3_0_CPU_SW_SLP

#define EFI_ACPI_3_0_CPU_SW_SLP BIT13

◆ EFI_ACPI_3_0_DCK_CAP

#define EFI_ACPI_3_0_DCK_CAP BIT9

◆ EFI_ACPI_3_0_DEBUG_PORT_TABLE_SIGNATURE

#define EFI_ACPI_3_0_DEBUG_PORT_TABLE_SIGNATURE SIGNATURE_32('D', 'B', 'G', 'P')

"DBGP" MS Debug Port Spec

◆ EFI_ACPI_3_0_DIFFERENTIATED_SYSTEM_DESCRIPTION_TABLE_REVISION

#define EFI_ACPI_3_0_DIFFERENTIATED_SYSTEM_DESCRIPTION_TABLE_REVISION 0x02

◆ EFI_ACPI_3_0_DIFFERENTIATED_SYSTEM_DESCRIPTION_TABLE_SIGNATURE

#define EFI_ACPI_3_0_DIFFERENTIATED_SYSTEM_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('D', 'S', 'D', 'T')

"DSDT" Differentiated System Description Table

◆ EFI_ACPI_3_0_DWORD

#define EFI_ACPI_3_0_DWORD 3

◆ EFI_ACPI_3_0_EMBEDDED_CONTROLLER

#define EFI_ACPI_3_0_EMBEDDED_CONTROLLER 3

◆ EFI_ACPI_3_0_EMBEDDED_CONTROLLER_BOOT_RESOURCES_TABLE_REVISION

#define EFI_ACPI_3_0_EMBEDDED_CONTROLLER_BOOT_RESOURCES_TABLE_REVISION 0x01

ECDT Version (as defined in ACPI 3.0 spec.)

◆ EFI_ACPI_3_0_EMBEDDED_CONTROLLER_BOOT_RESOURCES_TABLE_SIGNATURE

#define EFI_ACPI_3_0_EMBEDDED_CONTROLLER_BOOT_RESOURCES_TABLE_SIGNATURE SIGNATURE_32('E', 'C', 'D', 'T')

"ECDT" Embedded Controller Boot Resources Table

◆ EFI_ACPI_3_0_EVENT_TIMER_DESCRIPTION_TABLE_SIGNATURE

#define EFI_ACPI_3_0_EVENT_TIMER_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('E', 'T', 'D', 'T')

"ETDT" Event Timer Description Table

◆ EFI_ACPI_3_0_EXTENDED_SYSTEM_DESCRIPTION_TABLE_REVISION

#define EFI_ACPI_3_0_EXTENDED_SYSTEM_DESCRIPTION_TABLE_REVISION 0x01

XSDT Revision (as defined in ACPI 3.0 spec.)

◆ EFI_ACPI_3_0_EXTENDED_SYSTEM_DESCRIPTION_TABLE_SIGNATURE

#define EFI_ACPI_3_0_EXTENDED_SYSTEM_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('X', 'S', 'D', 'T')

"XSDT" Extended System Description Table

◆ EFI_ACPI_3_0_FIRMWARE_ACPI_CONTROL_STRUCTURE_SIGNATURE

#define EFI_ACPI_3_0_FIRMWARE_ACPI_CONTROL_STRUCTURE_SIGNATURE SIGNATURE_32('F', 'A', 'C', 'S')

"FACS" Firmware ACPI Control Structure

◆ EFI_ACPI_3_0_FIRMWARE_ACPI_CONTROL_STRUCTURE_VERSION

#define EFI_ACPI_3_0_FIRMWARE_ACPI_CONTROL_STRUCTURE_VERSION 0x01

FACS Version (as defined in ACPI 3.0 spec.)

◆ EFI_ACPI_3_0_FIX_RTC

#define EFI_ACPI_3_0_FIX_RTC BIT6

◆ EFI_ACPI_3_0_FIXED_ACPI_DESCRIPTION_TABLE_REVISION

#define EFI_ACPI_3_0_FIXED_ACPI_DESCRIPTION_TABLE_REVISION 0x04

FADT Version (as defined in ACPI 3.0 spec.)

◆ EFI_ACPI_3_0_FIXED_ACPI_DESCRIPTION_TABLE_SIGNATURE

#define EFI_ACPI_3_0_FIXED_ACPI_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('F', 'A', 'C', 'P')

"FACP" Fixed ACPI Description Table

◆ EFI_ACPI_3_0_FORCE_APIC_CLUSTER_MODEL

#define EFI_ACPI_3_0_FORCE_APIC_CLUSTER_MODEL BIT18

◆ EFI_ACPI_3_0_FORCE_APIC_PHYSICAL_DESTINATION_MODE

#define EFI_ACPI_3_0_FORCE_APIC_PHYSICAL_DESTINATION_MODE BIT19

◆ EFI_ACPI_3_0_FUNCTIONAL_FIXED_HARDWARE

#define EFI_ACPI_3_0_FUNCTIONAL_FIXED_HARDWARE 0x7F

◆ EFI_ACPI_3_0_HEADLESS

#define EFI_ACPI_3_0_HEADLESS BIT12

◆ EFI_ACPI_3_0_HIGH_PRECISION_EVENT_TIMER_TABLE_SIGNATURE

#define EFI_ACPI_3_0_HIGH_PRECISION_EVENT_TIMER_TABLE_SIGNATURE SIGNATURE_32('H', 'P', 'E', 'T')

"HPET" IA-PC High Precision Event Timer Table

◆ EFI_ACPI_3_0_INTERRUPT_SOURCE_OVERRIDE

#define EFI_ACPI_3_0_INTERRUPT_SOURCE_OVERRIDE 0x02

◆ EFI_ACPI_3_0_IO_APIC

#define EFI_ACPI_3_0_IO_APIC 0x01

◆ EFI_ACPI_3_0_IO_SAPIC

#define EFI_ACPI_3_0_IO_SAPIC 0x06

◆ EFI_ACPI_3_0_ISCSI_BOOT_FIRMWARE_TABLE_SIGNATURE

#define EFI_ACPI_3_0_ISCSI_BOOT_FIRMWARE_TABLE_SIGNATURE SIGNATURE_32('i', 'B', 'F', 'T')

"iBFT" iSCSI Boot Firmware Table

◆ EFI_ACPI_3_0_LEGACY_DEVICES

#define EFI_ACPI_3_0_LEGACY_DEVICES BIT0

◆ EFI_ACPI_3_0_LOCAL_APIC_ADDRESS_OVERRIDE

#define EFI_ACPI_3_0_LOCAL_APIC_ADDRESS_OVERRIDE 0x05

◆ EFI_ACPI_3_0_LOCAL_APIC_ENABLED

#define EFI_ACPI_3_0_LOCAL_APIC_ENABLED BIT0

Local APIC Flags. All other bits are reserved and must be 0.

◆ EFI_ACPI_3_0_LOCAL_APIC_NMI

#define EFI_ACPI_3_0_LOCAL_APIC_NMI 0x04

◆ EFI_ACPI_3_0_LOCAL_SAPIC

#define EFI_ACPI_3_0_LOCAL_SAPIC 0x07

◆ EFI_ACPI_3_0_MEMORY_AFFINITY

#define EFI_ACPI_3_0_MEMORY_AFFINITY 0x01

◆ EFI_ACPI_3_0_MEMORY_ENABLED

#define EFI_ACPI_3_0_MEMORY_ENABLED (1 << 0)

◆ EFI_ACPI_3_0_MEMORY_HOT_PLUGGABLE

#define EFI_ACPI_3_0_MEMORY_HOT_PLUGGABLE (1 << 1)

◆ EFI_ACPI_3_0_MEMORY_NONVOLATILE

#define EFI_ACPI_3_0_MEMORY_NONVOLATILE (1 << 2)

◆ EFI_ACPI_3_0_MSI_NOT_SUPPORTED

#define EFI_ACPI_3_0_MSI_NOT_SUPPORTED BIT3

◆ EFI_ACPI_3_0_MULTIPLE_APIC_DESCRIPTION_TABLE_REVISION

#define EFI_ACPI_3_0_MULTIPLE_APIC_DESCRIPTION_TABLE_REVISION 0x02

MADT Revision (as defined in ACPI 3.0 spec.)

◆ EFI_ACPI_3_0_MULTIPLE_APIC_DESCRIPTION_TABLE_SIGNATURE

#define EFI_ACPI_3_0_MULTIPLE_APIC_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('A', 'P', 'I', 'C')

"APIC" Multiple APIC Description Table

◆ EFI_ACPI_3_0_NON_MASKABLE_INTERRUPT_SOURCE

#define EFI_ACPI_3_0_NON_MASKABLE_INTERRUPT_SOURCE 0x03

◆ EFI_ACPI_3_0_P_LVL2_UP

#define EFI_ACPI_3_0_P_LVL2_UP BIT3

◆ EFI_ACPI_3_0_PCAT_COMPAT

#define EFI_ACPI_3_0_PCAT_COMPAT BIT0

Multiple APIC Flags All other bits are reserved and must be set to 0.

◆ EFI_ACPI_3_0_PCI_CONFIGURATION_SPACE

#define EFI_ACPI_3_0_PCI_CONFIGURATION_SPACE 2

◆ EFI_ACPI_3_0_PCI_EXP_WAK

#define EFI_ACPI_3_0_PCI_EXP_WAK BIT14

◆ EFI_ACPI_3_0_PCI_EXPRESS_MEMORY_MAPPED_CONFIGURATION_SPACE_BASE_ADDRESS_DESCRIPTION_TABLE_SIGNATURE

#define EFI_ACPI_3_0_PCI_EXPRESS_MEMORY_MAPPED_CONFIGURATION_SPACE_BASE_ADDRESS_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('M', 'C', 'F', 'G')

"MCFG" PCI Express Memory Mapped Configuration Space Base Address Description Table

◆ EFI_ACPI_3_0_PCIE_ASPM_CONTROLS

#define EFI_ACPI_3_0_PCIE_ASPM_CONTROLS BIT4

◆ EFI_ACPI_3_0_PERSISTENT_SYSTEM_DESCRIPTION_TABLE_SIGNATURE

#define EFI_ACPI_3_0_PERSISTENT_SYSTEM_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('P', 'S', 'D', 'T')

"PSDT" Persistent System Description Table

◆ EFI_ACPI_3_0_PLATFORM_INTERRUPT_SOURCES

#define EFI_ACPI_3_0_PLATFORM_INTERRUPT_SOURCES 0x08

◆ EFI_ACPI_3_0_PM_PROFILE_APPLIANCE_PC

#define EFI_ACPI_3_0_PM_PROFILE_APPLIANCE_PC 6

◆ EFI_ACPI_3_0_PM_PROFILE_DESKTOP

#define EFI_ACPI_3_0_PM_PROFILE_DESKTOP 1

◆ EFI_ACPI_3_0_PM_PROFILE_ENTERPRISE_SERVER

#define EFI_ACPI_3_0_PM_PROFILE_ENTERPRISE_SERVER 4

◆ EFI_ACPI_3_0_PM_PROFILE_MOBILE

#define EFI_ACPI_3_0_PM_PROFILE_MOBILE 2

◆ EFI_ACPI_3_0_PM_PROFILE_PERFORMANCE_SERVER

#define EFI_ACPI_3_0_PM_PROFILE_PERFORMANCE_SERVER 7

◆ EFI_ACPI_3_0_PM_PROFILE_SOHO_SERVER

#define EFI_ACPI_3_0_PM_PROFILE_SOHO_SERVER 5

◆ EFI_ACPI_3_0_PM_PROFILE_UNSPECIFIED

#define EFI_ACPI_3_0_PM_PROFILE_UNSPECIFIED 0

◆ EFI_ACPI_3_0_PM_PROFILE_WORKSTATION

#define EFI_ACPI_3_0_PM_PROFILE_WORKSTATION 3

◆ EFI_ACPI_3_0_POLARITY

#define EFI_ACPI_3_0_POLARITY (3 << 0)

◆ EFI_ACPI_3_0_PROC_C1

#define EFI_ACPI_3_0_PROC_C1 BIT2

◆ EFI_ACPI_3_0_PROCESSOR_LOCAL_APIC

#define EFI_ACPI_3_0_PROCESSOR_LOCAL_APIC 0x00

◆ EFI_ACPI_3_0_PROCESSOR_LOCAL_APIC_SAPIC_AFFINITY

#define EFI_ACPI_3_0_PROCESSOR_LOCAL_APIC_SAPIC_AFFINITY 0x00

◆ EFI_ACPI_3_0_PROCESSOR_LOCAL_APIC_SAPIC_ENABLED

#define EFI_ACPI_3_0_PROCESSOR_LOCAL_APIC_SAPIC_ENABLED (1 << 0)

Local APIC/SAPIC Flags. All other bits are reserved and must be 0.

◆ EFI_ACPI_3_0_PWR_BUTTON

#define EFI_ACPI_3_0_PWR_BUTTON BIT4

◆ EFI_ACPI_3_0_QWORD

#define EFI_ACPI_3_0_QWORD 4

◆ EFI_ACPI_3_0_REMOTE_POWER_ON_CAPABLE

#define EFI_ACPI_3_0_REMOTE_POWER_ON_CAPABLE BIT17

◆ EFI_ACPI_3_0_RESET_REG_SUP

#define EFI_ACPI_3_0_RESET_REG_SUP BIT10

◆ EFI_ACPI_3_0_ROOT_SYSTEM_DESCRIPTION_POINTER_REVISION

#define EFI_ACPI_3_0_ROOT_SYSTEM_DESCRIPTION_POINTER_REVISION 0x02

ACPISpec (Revision 3.0b) says current value is 2.

RSD_PTR Revision (as defined in ACPI 3.0b spec.)

◆ EFI_ACPI_3_0_ROOT_SYSTEM_DESCRIPTION_POINTER_SIGNATURE

#define EFI_ACPI_3_0_ROOT_SYSTEM_DESCRIPTION_POINTER_SIGNATURE SIGNATURE_64('R', 'S', 'D', ' ', 'P', 'T', 'R', ' ')

"RSD PTR " Root System Description Pointer

◆ EFI_ACPI_3_0_ROOT_SYSTEM_DESCRIPTION_TABLE_REVISION

#define EFI_ACPI_3_0_ROOT_SYSTEM_DESCRIPTION_TABLE_REVISION 0x01

RSDT Revision (as defined in ACPI 3.0 spec.)

◆ EFI_ACPI_3_0_ROOT_SYSTEM_DESCRIPTION_TABLE_SIGNATURE

#define EFI_ACPI_3_0_ROOT_SYSTEM_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('R', 'S', 'D', 'T')

"RSDT" Root System Description Table

◆ EFI_ACPI_3_0_RTC_S4

#define EFI_ACPI_3_0_RTC_S4 BIT7

◆ EFI_ACPI_3_0_S4_RTC_STS_VALID

#define EFI_ACPI_3_0_S4_RTC_STS_VALID BIT16

◆ EFI_ACPI_3_0_S4BIOS_F

#define EFI_ACPI_3_0_S4BIOS_F BIT0

Firmware Control Structure Feature Flags All other bits are reserved and must be set to 0.

◆ EFI_ACPI_3_0_SEALED_CASE

#define EFI_ACPI_3_0_SEALED_CASE BIT11

◆ EFI_ACPI_3_0_SECONDARY_SYSTEM_DESCRIPTION_TABLE_REVISION

#define EFI_ACPI_3_0_SECONDARY_SYSTEM_DESCRIPTION_TABLE_REVISION 0x02

◆ EFI_ACPI_3_0_SECONDARY_SYSTEM_DESCRIPTION_TABLE_SIGNATURE

#define EFI_ACPI_3_0_SECONDARY_SYSTEM_DESCRIPTION_TABLE_SIGNATURE SIGNATURE_32('S', 'S', 'D', 'T')

"SSDT" Secondary System Description Table

◆ EFI_ACPI_3_0_SERIAL_PORT_CONSOLE_REDIRECTION_TABLE_SIGNATURE

#define EFI_ACPI_3_0_SERIAL_PORT_CONSOLE_REDIRECTION_TABLE_SIGNATURE SIGNATURE_32('S', 'P', 'C', 'R')

"SPCR" Serial Port Concole Redirection Table

◆ EFI_ACPI_3_0_SERVER_PLATFORM_MANAGEMENT_INTERFACE_TABLE_SIGNATURE

#define EFI_ACPI_3_0_SERVER_PLATFORM_MANAGEMENT_INTERFACE_TABLE_SIGNATURE SIGNATURE_32('S', 'P', 'M', 'I')

"SPMI" Server Platform Management Interface Table

◆ EFI_ACPI_3_0_SIMPLE_BOOT_FLAG_TABLE_SIGNATURE

#define EFI_ACPI_3_0_SIMPLE_BOOT_FLAG_TABLE_SIGNATURE SIGNATURE_32('B', 'O', 'O', 'T')

"BOOT" MS Simple Boot Spec

◆ EFI_ACPI_3_0_SLP_BUTTON

#define EFI_ACPI_3_0_SLP_BUTTON BIT5

◆ EFI_ACPI_3_0_SMART_BATTERY_DESCRIPTION_TABLE_REVISION

#define EFI_ACPI_3_0_SMART_BATTERY_DESCRIPTION_TABLE_REVISION 0x01

SBST Version (as defined in ACPI 3.0 spec.)

◆ EFI_ACPI_3_0_SMART_BATTERY_SPECIFICATION_TABLE_SIGNATURE

#define EFI_ACPI_3_0_SMART_BATTERY_SPECIFICATION_TABLE_SIGNATURE SIGNATURE_32('S', 'B', 'S', 'T')

"SBST" Smart Battery Specification Table

◆ EFI_ACPI_3_0_SMBUS

#define EFI_ACPI_3_0_SMBUS 4

◆ EFI_ACPI_3_0_SYSTEM_IO

#define EFI_ACPI_3_0_SYSTEM_IO 1

◆ EFI_ACPI_3_0_SYSTEM_LOCALITY_DISTANCE_INFORMATION_TABLE_REVISION

#define EFI_ACPI_3_0_SYSTEM_LOCALITY_DISTANCE_INFORMATION_TABLE_REVISION 0x01

SLIT Version (as defined in ACPI 3.0 spec.)

◆ EFI_ACPI_3_0_SYSTEM_LOCALITY_INFORMATION_TABLE_SIGNATURE

#define EFI_ACPI_3_0_SYSTEM_LOCALITY_INFORMATION_TABLE_SIGNATURE SIGNATURE_32('S', 'L', 'I', 'T')

"SLIT" System Locality Information Table

◆ EFI_ACPI_3_0_SYSTEM_MEMORY

#define EFI_ACPI_3_0_SYSTEM_MEMORY 0

◆ EFI_ACPI_3_0_SYSTEM_RESOURCE_AFFINITY_TABLE_REVISION

#define EFI_ACPI_3_0_SYSTEM_RESOURCE_AFFINITY_TABLE_REVISION 0x02

SRAT Version (as defined in ACPI 3.0 spec.)

◆ EFI_ACPI_3_0_SYSTEM_RESOURCE_AFFINITY_TABLE_SIGNATURE

#define EFI_ACPI_3_0_SYSTEM_RESOURCE_AFFINITY_TABLE_SIGNATURE SIGNATURE_32('S', 'R', 'A', 'T')

"SRAT" System Resource Affinity Table

◆ EFI_ACPI_3_0_TMR_VAL_EXT

#define EFI_ACPI_3_0_TMR_VAL_EXT BIT8

◆ EFI_ACPI_3_0_TRIGGER_MODE

#define EFI_ACPI_3_0_TRIGGER_MODE (3 << 2)

◆ EFI_ACPI_3_0_TRUSTED_COMPUTING_PLATFORM_ALLIANCE_CAPABILITIES_TABLE_SIGNATURE

#define EFI_ACPI_3_0_TRUSTED_COMPUTING_PLATFORM_ALLIANCE_CAPABILITIES_TABLE_SIGNATURE SIGNATURE_32('T', 'C', 'P', 'A')

"TCPA" Trusted Computing Platform Alliance Capabilities Table

◆ EFI_ACPI_3_0_UNDEFINED

#define EFI_ACPI_3_0_UNDEFINED 0

◆ EFI_ACPI_3_0_USE_PLATFORM_CLOCK

#define EFI_ACPI_3_0_USE_PLATFORM_CLOCK BIT15

◆ EFI_ACPI_3_0_VGA_NOT_PRESENT

#define EFI_ACPI_3_0_VGA_NOT_PRESENT BIT2

◆ EFI_ACPI_3_0_WATCHDOG_ACTION_TABLE_SIGNATURE

#define EFI_ACPI_3_0_WATCHDOG_ACTION_TABLE_SIGNATURE SIGNATURE_32('W', 'D', 'A', 'T')

"WDAT" Watchdog Action Table

◆ EFI_ACPI_3_0_WATCHDOG_RESOURCE_TABLE_SIGNATURE

#define EFI_ACPI_3_0_WATCHDOG_RESOURCE_TABLE_SIGNATURE SIGNATURE_32('W', 'D', 'R', 'T')

"WDRT" Watchdog Resource Table

◆ EFI_ACPI_3_0_WBINVD

#define EFI_ACPI_3_0_WBINVD BIT0

◆ EFI_ACPI_3_0_WBINVD_FLUSH

#define EFI_ACPI_3_0_WBINVD_FLUSH BIT1

◆ EFI_ACPI_3_0_WINDOWS_SPECIFIC_PROPERTIES_TABLE_SIGNATURE

#define EFI_ACPI_3_0_WINDOWS_SPECIFIC_PROPERTIES_TABLE_SIGNATURE SIGNATURE_32('W', 'S', 'P', 'T')

"WSPT" Windows Specific Properties Table

◆ EFI_ACPI_3_0_WORD

#define EFI_ACPI_3_0_WORD 2

◆ EFI_ACPI_MEMORY_TYPE_SPECIFIC_ATTRIBUTES_NV

#define EFI_ACPI_MEMORY_TYPE_SPECIFIC_ATTRIBUTES_NV 0x0000000000008000

◆ EFI_ACPI_MEMORY_TYPE_SPECIFIC_ATTRIBUTES_UC

#define EFI_ACPI_MEMORY_TYPE_SPECIFIC_ATTRIBUTES_UC 0x0000000000000001

◆ EFI_ACPI_MEMORY_TYPE_SPECIFIC_ATTRIBUTES_UCE

#define EFI_ACPI_MEMORY_TYPE_SPECIFIC_ATTRIBUTES_UCE 0x0000000000000010

◆ EFI_ACPI_MEMORY_TYPE_SPECIFIC_ATTRIBUTES_WB

#define EFI_ACPI_MEMORY_TYPE_SPECIFIC_ATTRIBUTES_WB 0x0000000000000008

◆ EFI_ACPI_MEMORY_TYPE_SPECIFIC_ATTRIBUTES_WC

#define EFI_ACPI_MEMORY_TYPE_SPECIFIC_ATTRIBUTES_WC 0x0000000000000002

◆ EFI_ACPI_MEMORY_TYPE_SPECIFIC_ATTRIBUTES_WT

#define EFI_ACPI_MEMORY_TYPE_SPECIFIC_ATTRIBUTES_WT 0x0000000000000004

Typedef Documentation

◆ [struct]

typedef PACKED struct { ... } EFI_ACPI_EXTENDED_ADDRESS_SPACE_DESCRIPTOR

Extended Address Space Descriptor

Variable Documentation

◆ AddrLen

UINT64 AddrLen

◆ AddrRangeMax

UINT64 AddrRangeMax

◆ AddrRangeMin

UINT64 AddrRangeMin

◆ AddrSpaceGranularity

UINT64 AddrSpaceGranularity

◆ AddrTranslationOffset

UINT64 AddrTranslationOffset

◆ GenFlag

UINT8 GenFlag

◆ Header

ACPI_LARGE_RESOURCE_HEADER Header

◆ Reserved

UINT8 Reserved

◆ ResType

UINT8 ResType

◆ RevisionId

UINT8 RevisionId

◆ SpecificFlag

UINT8 SpecificFlag

◆ TypeSpecificAttribute

UINT64 TypeSpecificAttribute

Classes

Macros

Typedefs
